Page 2817 of 3115

SR0LY-05
R00427
R11229
Normal
Abnormal
R11562Engine Idling
Engine Stopped 5 mm (0.2 in.)
or less
- STEERINGPOWER STEERING FLUID
SR-5
2214 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. CHECK FLUID LEVEL
(a) Keep the vehicle level.
(b) With the engine stopped, check the fluid level in the oil
reservoir.
If necessary, add fluid.
Fluid: ATF DEXRON® II or III
HINT:
Check that the fluid level is within the HOT LEVEL range on the
reservoir.
If the fluid is cold, check that it is within the COLD LEVEL range.
(c) Start the engine and run it at idle.
(d) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80°C (176°F)
(e) Check for foaming or emulsification.
If there is foaming or emulsification, bleed power steering sys-
tem (See page SR-4).
(f) With the engine idling, measure the fluid level in the oil
reservoir.
(g) Stop the engine.
(h) Wait a few minutes and remeasure the fluid level in the oil
reservoir.
Maximum fluid level rise: 5 mm (0.20 in.)
If a problem is found, bleed power steering system
(See page SR-4).
(i) Check the fluid level.
Page 2818 of 3115
F04813
SST
IN
OUT Attachment
AttachmentPressure Feed Tube
SR-6
- STEERINGPOWER STEERING FLUID
2215 Author: Date:
2004 LAND CRUISER (RM1071U)
2. CHECK STEERING FLUID PRESSURE
(a) Remove the air cleaner assembly with air cleaner hose
(See page SR-40).
(b) Disconnect the pressure feed tube from the PS vane
pump (See page SR-40).
(c) Connect SST, as shown below.
SST 09640-10010 (09641-01010, 09641-01030,
09641-01060)
NOTICE:
Check that the valve of the SST is in the open position.
(d) Bleed the power steering system (See page SR-4).
(e) Start the engine and run it at idle.
(f) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80 °C (176 °F)
Page 2819 of 3115

Z15498
PS Gear
Closed
SSTPS Vane
Pump Oil
Reservoir
Z15499
PS Gear
SSTPS Vane
Pump Oil
Reservoir
Open
Z15500
PS Gear
SSTPS Vane
Pump Oil
Reservoir
Open Lock Position
- STEERINGPOWER STEERING FLUID
SR-7
2216 Author: Date:
2004 LAND CRUISER (RM1071U)
(g) With the engine idling, close the valve of the SST and ob-
serve the reading on the SST.
Minimum fluid pressure:
10,000 kPa (102 kgf/cm
2, 1,451 psi)
NOTICE:
Do not keep the valve closed for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(h) With the engine idling, open the valve fully.
(i) Measure the fluid pressure at engine speeds of 1,000 rpm
and 3,000 rpm.
Difference fluid pressure:
490 kPa (5 kgf/cm
2, 71 psi) or less
NOTICE:
Do not turn the steering wheel.
(j) With the engine idling and valve fully opened, turn the
steering wheel to full lock.
Minimum fluid pressure:
10,000 kPa (102 kgf/cm
2, 1,451 psi)
NOTICE:
Do not maintain lock position for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(k) Disconnect the SST.
SST 09640- 10010 (09641- 01010, 09641- 01030,
09641-01060)
(l) Connect the pressure feed tube (See page SR-47).
(m) Install the air cleaner assembly with air cleaner hose
(See page SR-47).
(n) Bleed the power steering system (See page SR-4).
Page 2820 of 3115
SR0MJ-06
F06125
Cotter Pin
72 (730, 53)
Intermediate Shaft Assembly
34 (350, 25)
120 (1,250, 89)
18 (184, 13)
Tube ClampPressure Feed
Tube
44 (450, 32)
*40 (409, 29)
Gasket
72 (730, 53)
PS Gear Assembly
Return Tube
42 (430, 31)
Clip
Engine Oil Filter Assembly
No. 2 Engine Under Cover
x 6
x 7
No. 1 Engine Under CoverN´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
* For use with SST
Clip O-Ring
18 (180, 13)
Bracket
SR-48
- STEERINGPOWER STEERING GEAR
2257 Author: Date:
2004 LAND CRUISER (RM1071U)
POWER STEERING GEAR
COMPONENTS
Page 2821 of 3115
F06126
Tie Rod End
Lock Nut
55 (560, 41)
Clip
Rack Boot
Clamp
Claw WasherRack End
132 (1,350, 98)
*99 (1,014, 74)
Cylinder End
Stopper
O-Ring
Bushing
Spacer
Oil Seal
Steering Rack
O-Ring
Teflon Ring
Rack Housing
Claw Washer
Clamp
Rack Boot
Lock Nut
55 (560, 41)
Clip
Tie Rod End
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Molybdenum disulfide lithium base grease
Power steering fluid
*For use with SST
145 (1,480, 107)
*110 (1,122, 81)
Rack End132 (1,350, 98)
*99 (1,014, 74)
- STEERINGPOWER STEERING GEAR
SR-49
2258 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2822 of 3115
F06127
24.5 (250, 18)
*23 (230, 17)
24.5 (250, 18)
*23 (230, 17)Turn Pressure TubeControl Valve
Housing
Dust Cover
18 (180, 13)
Union Seat
O-Ring
Oil Seal
Bearing
Control Valve
Assembly
Teflon Ring
Oil Seal
O-Ring
Bearing Guide Nut
24.5 (250, 18)
Rack Guide Sub-assembly
Rack Guide Spring
Rack Guide Spring
Cap
Rack Guide Spring Cap
Lock Nut
70 (700, 51)
*51 (520, 38)
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Precoated part
Molybdenum disulfide lithium base grease
Power steering fluid
* For use with SST
SR-50
- STEERINGPOWER STEERING GEAR
2259 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2823 of 3115
SR0ML-07
F06129
SST
F06130
SST
F04816
F06131
- STEERINGPOWER STEERING GEAR
SR-53
2262 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
NOTICE:
When using a vise, do not overtighten it.
1. SECURE PS GEAR ASSEMBLY IN VISE
Using SST, secure the gear assembly in a vise, as shown in the
illustration.
SST 09630-00014 (09631-00142)
2. REMOVE 2 TURN PRESSURE TUBES
Using SST, remove the tube.
SST 09023-38200
3. REMOVE RH AND LH CLIPS, RACK BOOTS AND
CLAMPS
(a) Using pliers, loosen the clamp, as shown in the illustra-
tion.
NOTICE:
Be careful not to damage the boot.
(b) Remove the clip, rack boot and clamp.
(c) Employ the same manner described above to the other
side.
HINT:
Mark the RH and LH rack boots.
4. REMOVE RH AND LH RACK ENDS AND CLAW WASH-
ERS
(a) Using a screwdriver and hammer, stake back the washer.
NOTICE:
Avoid and impact to the steering rack.
Page 2824 of 3115

F06132
SST
F10798
SST
F10799
Matchmarks
F04822
SST
SR-54
- STEERINGPOWER STEERING GEAR
2263 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Using a spanner to hold the steering rack steady, and us-
ing SST, remove the rack end.
SST 09922-10010
NOTICE:
Use SST 09922-10010 in the direction shown in the illustra-
tion.
(c) Remove the claw washer.
(d) Employ the same manner described above to the other
side.
HINT:
Mark the RH and LH rack ends.
5. REMOVE RACK GUIDE SPRING CAP LOCK NUT
Using SST, remove the nut.
SST 09922-10010
NOTICE:
Use SST 09922-10010 in the direction shown in the illustra-
tion.
6. REMOVE RACK GUIDE SPRING CAP
7. REMOVE RACK GUIDE SPRING AND RACK GUIDE
SUB-ASSEMBL Y
8. REMOVE DUST COVER
9. REMOVE CONTROL VALVE HOSING WITH CONTROL
VALVE ASSEMBLY
(a) Place matchmarks on the valve housing and rack hous-
ing.
(b) Remove the 2 bolts.
(c) Pull out the control valve assembly with the valve hous-
ing.
(d) Remove the O-ring from the valve housing.
10. REMOVE CONTROL VALVE ASSEMBLY
(a) Using SST, loosen the bearing guide nut.
SST 09631-20060
