Page 817 of 3115
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-565
758 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
Start the inspection from step1 in case of using the hand-held tester and start from step 2 in case of not using
the hand-held tester.
1 Check output value of the yaw rate (deceleration) sensor.
PREPARATION:
(a) Connect the hand-held tester to the DLC3.
(b) Turn the ignition switch ON and push the hand-held tester main switch ON.
(c) Select the DATALIST mode on the hand-held tester.
CHECK:
Check that the deceleration value of the deceleration sensor displayed on the hand-held tester is changing
when tilting the vehicle.
OK:
Deceleration value must be changing.
OK Check and replace skid control ECU.
NG
Page 818 of 3115

F12707
GL1GL2
VYSGYAW
Front
Rearward
Forward
DI-566- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
759 Author: Date:
2004 LAND CRUISER (RM1071U)
2 Check yaw rate (deceleration) sensor.
PREPARATION:
(a) Connect 3 dry batteries of 1.5 V in series.
(b) Connect VYS terminal to the batteries' positive (+) termi-
nal, and GYAW terminal to the batteries' negative (-) ter-
minal. Apply about 4.5 V between VYS and GYAW termi-
nals.
NOTICE:
Do not apply voltage of 6 V or more to terminals VYS and
GYAW.
CHECK:
Check the output voltage of GL1 and GL2 terminals when the
sensor is tilted forward and rearward.
OK:
SymbolsConditionStandard Value
GL1HorizontalAbout 2.3 V
GL1Lean rearward1.0 V to about 2.3 V
GL1Lean forwardAbout 2.3 V to 3.5 V
GL2HorizontalAbout 2.3 V
GL2Lean rearwardAbout 2.3 V to 3.5 V
GL2Lean forward1.0 V to about 2.3 V
HINT:
If the sensor is tilted too much, it may show the wrong val-
ue.
If dropped, the sensor should be replaced with a new one.
The sensor removed from the vehicle should not be
placed upside down.
NG Replace yaw rate sensor.
OK
3 Check for open or short circuit in harness and connector between yaw rate (de-
celeration) sensor and skid control ECU (See page IN-36).
NG Repair or replace harness or connector.
OK
Check and replace skid control ECU.
Page 819 of 3115

F17752
ABS & BA & TRAC
& VSC Sensor
ShieldedGL1
GL2
YD
VYS
YAW
GYAW
YSS A43
1827 289 191022
G
Y
L
B
W
R 4
2
6
8
1
5A43
A43
A43
A43
A43
A42 IG4
IG4
IG4
IG4
IG4
IG4
IG416
17
21
19
20
18
22
ShieldedG
Y
L
B
W
R GL1
GL2
YD
VYS
YAW 2
GYAWABS & BA & TRAC
& VSC ECU
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-567
760 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC C1244 / 44 Deceleration Sensor Circuit
CIRCUIT DESCRIPTION
This sensor detects vehicle deceleration. The sensor signal is used in ABS & BA & TRAC & VSC control.
If the sensor functions abnormally, the ABS warning light comes on.
DTC No.DTC Detecting ConditionTrouble Area
C1244 / 44
Either of the following 1., 2., 3. or 4. is detected:
1. The condition that ECU terminals GL1 and GL2 values are
-1.5 G or less or 1.5 G or more continues for 1.2 sec. or
more.
2. The condition that the deceleration sensor terminal VGS
voltage is 4.4 V or less or 5.6 V or more continues for 1.2
sec. or more.
3. At a vehicle speed of 0 mph (0 km/h), after the difference of
output value between deceleration sensor terminals GL1
and GL2 becomes 0.6 G or more, and the condition that
does not become 0.4 G or less continues for 60 sec. or
more.
4. Deceleration sensor signal momentary open occurs for 7
times or more.
Deceleration sensor
Deceleration sensor circuit
WIRING DIAGRAM
DIC9Q-01
Page 820 of 3115
DI-568- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
761 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check for open and short circuit in harness and connector between yaw rate
(deceleration) sensor and skid control ECU (See page IN-36).
NG Repair or replace harness or connector.
OK
Page 821 of 3115

F12707
GL1GL2
VYSGYAW
Front
Rearward
Forward
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-569
762 Author: Date:
2004 LAND CRUISER (RM1071U)
2 Check yaw rate (deceleration) sensor.
PREPARATION:
(a) Connect 3 dry batteries of 1.5 V in series.
(b) Connect VYS terminal to the batteries' positive (+) termi-
nal, and GYAW terminal to the batteries' negative (-) ter-
minal. Apply about 4.5 V between VYS and GYAW termi-
nals.
NOTICE:
Do not apply voltage of 6 V or more to terminals VYS and
GYAW.
CHECK:
Check the output voltage of GL1 and GL2 terminals when the
sensor is tilted forward and rearward.
OK:
SymbolsConditionStandard Value
GL1HorizontalAbout 2.3 V
GL1Lean rearward1.0 V to about 2.3 V
GL1Lean forwardAbout 2.3 V to 3.5 V
GL2HorizontalAbout 2.3 V
GL2Lean rearwardAbout 2.3 V to 3.5 V
GL2Lean forward1.0 V to about 2.3 V
HINT:
If the sensor is tilted too much, it may show the wrong val-
ue.
If dropped, the sensor should be replaced with a new one.
The sensor removed from the vehicle should not be
placed upside down.
NG Replace yaw rate sensor.
OK
Check and replace skid control ECU.
Page 822 of 3115

F02870
Master Cylinder
Pressure Sensor
(Shielded)ABS & BA & TRAC
& VSC ECU
MSS VCM
E2 22
VOUT10
3 21
23 VCC
PMC
GND M4
A41 B
WR
A4112 A41
A41 DI-570
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
763 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC C1246 / 46 Master Cylinder Pressure Sensor
Circuit
CIRCUIT DESCRIPTION
DTC No.DTC Detecting ConditionTrouble Area
C1246 / 46
Either of the following 1., 2., 3., 4. or 5. is detected:
1. At a vehicle speed of 4 mph (7 km/h) or more, PMC ter-
minal voltage does not change by more than 0.005 V
once it exceeds 0.86 V continues for at least 30 secs.
2. Interference occurs to ECU terminal PMC 7 times or
more for 5 sec.
3. ECU terminal STP is OFF, and the condition that termi-
nal PMC voltage becomes more than 0.86 V or less than
0.3 V continues for 5 sec. or more.
4. The condition that ECU terminal IG1 voltage is 9.5 V to
17.0 V, and terminal VCM voltage other than the range
from 4.4 V to 5.6 V continues for 1.2 sec. or more.
5. The condition that ECU terminal VCM voltage is 4.4 V to
5.6 V, and terminal PMC voltage other than the range
from 0.14 V to 4.85 V continues for 1.2 sec. or more.
Master cylinder pressure sensor
Master cylinder pressure sensor circuit
WIRING DIAGRAM
DIC9R-01
Page 823 of 3115

- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-571
764 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
Start the inspection from step 1 in case of using the hand-held tester and start from step 2 in case of not
using the hand-held tester.
1 Check output value of the master cylinder pressure sensor.
PREPARATION:
(a) Connect the hand-held tester to the DLC3.
(b) Turn the ignition switch ON and push the hand-held tester main switch ON.
(c) Select the DATA LIST mode on the hand-held tester.
CHECK:
Check that the brake fluid pressure value of the master cylinder pressure sensor displayed on the hand-held
tester is changing when depressing the brake pedal.
OK:
Brake fluid pressure value must be changing.
OK Go to step 4.
NG
2 Check master cylinder pressure sensor.
PREPARATION:
(a) Install the LSPV gauge to the front caliper bleeder plug portion, and bleed the LSPV gauge.
SST 09709-29018
(b) Remove the air cleaner inlet and battery clamp cover.
CHECK:
Start the engine and depress the brake pedal, then check the relation between the fluid pressure and voltage
of PMC and E2 terminals of the skid control ECU with connectors still connected.
OK:
Front brake caliper fluid pressureVoltage
0 kPa (0 Kgf/cm2, 0 psi)0.37 to 0.63 V
5,883 kPa (60 kgf/cm2, 853 psi)1.57 to 1.83 V
11,768 kPa (120 kgf/cm2, 1,706 psi)2.77 to 3.03 V
HINT:
Voltage between terminals VCM and E2: 4.7 to 5.3 V
NG Replace master cylinder pressure sensor.
OK
Page 824 of 3115
DI-572- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
765 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check for open and short circuit in harness and connector between master cyl-
inder pressure sensor and skid control ECU (See page IN-36).
NG Repair or replace harness or connector.
OK
Replace master cylinder pressure sensor.
4 Check whether or not the ECU terminal STP input voltage is changed when the
stop light switch is turned on and off.
NO Check the stop light switch circuit (See page
DI-573).
YES
Check and replace skid control ECU.
