AC1JK-02
AC-106
- AIR CONDITIONINGAIR CONDITIONING CONTROL ASSEMBLY
2831 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse of disassembly (See page AC-102).
Page 10 of 3115
AC3OZ-01
I2519412 Clips
I25522
I24447
I24448
I24449
AC-100
- AIR CONDITIONINGAIR CONDITIONING CONTROL ASSEMBLY
2825 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE CENTER RESISTORS
Disengage the 12 clips and remove the center resistors, then
disconnect the connectors.
2. REMOVE INTEGRATION CONTROL PANEL AS-
SEMBLY
(a) Remove the 4 bolts.
(b) Remove the integration control panel assembly, then dis-
connect the connectors.
3. w/ navigation system:
REMOVE A/C AMPLIFIER
(a) Disconnect the connector clamp.
(b) Remove the 3 screws, the 4 bolts and the radio receiver
bracket LH.
(c) Remove the 2 screws and the A/C amplifier.
4. w/ LEXUS navigation system:
REMOVE EMV
Remove the 3 screws, the 2 bolts and the EMV.
Page 11 of 3115
I24450
I25157
I25184
- AIR CONDITIONINGAIR CONDITIONING CONTROL ASSEMBLY
AC-101
2826 Author: Date:
2004 LAND CRUISER (RM1071U)
5. w/ navigation system:
REMOVE INTEGRATION CONTROL PANEL
6. Disconnect the connector clamps.
(a) Remove the screw, the 2 bolts and the radio receiver
bracket RH.
(b) Remove the integration control panel from the radio re-
ceiver.
7. w/o navigation system:
REMOVE INTEGRATION CONTROL PANEL
(a) Disconnect the connector clamp.
(b) Remove the 2 screws, 4 bolts and the radio receiver
bracket LH.
(c) Disconnect the connector clamp.
(d) Remove the 2 screws, 4 bolts and the radio receiver
bracket RH.
(e) Remove the integration control panel.
Page 12 of 3115
AC22D-03
I06876
AC-1 10
- AIR CONDITIONINGAIR CONDITIONING AMPLIFIER (for Rear A/C)
2835 Author: Date:
2004 LAND CRUISER (RM1071U)
AIR CONDITIONING AMPLIFIER
(for Rear A/C)
INSPECTION
1. REMOVE REAR DOOR SCUFF PLATE RH
2. REMOVE REAR FLOOR MAT SUPPORT PLATE
3. REMOVE QUARTER TRIM PANEL RH
4. REMOVE A/C AMPLIFIER
(a) Disconnect the connectors.
(b) Remove the 2 screws and the A/C amplifier.
5. INSPECT REAR A/C AMPLIFIER CIRCUIT
(See page DI-1309)
Page 13 of 3115

AC1HN-04
N13793
Charging Cylinder High Pressure
Service Valve Low Pressure
Service ValvePush
Air
N13792
Gas Leak
Detector
- AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC-1 1
2736 Author: Date:
2004 LAND CRUISER (RM1071U)
CHARGING
1. INSTALL CHARGING CYLINDER
HINT:
When handling the charging cylinder, always follow the direc-
tions given in the instruction manual.
(a) Charge the proper amount of refrigerant into the charging
cylinder.
(b) Connect the center hose to the charging cylinder.
CAUTION:
Do not open both high and low hand valves of manifold
gauge set.
(c) Open the valve of the charging cylinder.
(d) Press the valve core on the side of manifold gauge and
expel the air inside the center hose.
2. INSPECT REFRIGERATION SYSTEM FOR LEAKS
(a) Open the high pressure hand valve and the charge refrig-
erant.
(b) When the low pressure gauge indicates 98 kPa
(1 kgf/cm
2, 14 psi), close the high pressure hand valve.
(c) Using a gas leak detector, check the system for any leak-
age.
If leaks are found, repair the faulty component or connection.
CAUTION:
Use the refrigerant recovery/ recycling machine to recover
the refrigerant whenever replacing parts.
Page 14 of 3115

N13790
Low Pressure
Service Valve
High Pressure
Service Valve
I08298
Properly
Charged
Insufficiently
Charged
AC-12
- AIR CONDITIONINGAIR CONDITIONING SYSTEM
2737 Author: Date:
2004 LAND CRUISER (RM1071U)
3. CHARGE REFRIGERANT INTO REFRIGERATION
SYSTEM
If there is no leak after refrigerant leak check, charge the proper
amount of refrigerant into the refrigeration system.
CAUTION:
Do not run the engine when charging the system
through the high pressure side.
Do not open the low pressure hand valve when the
system is being charged with liquid refrigerant.
(a) Open the high pressure hand valve fully.
(b) Charge specified amount of refrigerant, then close the
high pressure hand valve.
HINT:
No bubbles in the sight glass indicates that the system is fully
charged.
(c) Partially charge the refrigeration system with refrigerant.
(1) Start engine and race engine at 1,500 rpm.
(2) Set fan speed selector to ºHIº.
(3) Set temperature control to ºMAX. COOLº.
(4) Set air inlet control to ºRECIRCº.
(5) Fully open doors (Sliding roof: closed).
(6) Open the low pressure hand valve.
CAUTION:
Do not open the high pressure hand valve.
(d) Charge refrigerant until bubbles disappear and check the
pressure on the gauge through the sight glass.
Page 15 of 3115

AC1HM-04
N13795
Quick Disconnect
Adapter
Charging
Service ValveHose
N13794
Vacuum Pump
Vacuum Pump Adapter
N13791
Low Pressure
Service Valve
Vacuum Pump Adapter High Pressure
Service ValveManifold
Gauge
Set
AC-10
- AIR CONDITIONINGAIR CONDITIONING SYSTEM
2735 Author: Date:
2004 LAND CRUISER (RM1071U)
EVACUATING
1. CONNECT QUICK DISCONNECT ADAPTER TO
CHARGING HOSES
2. REMOVE CAPS FROM SERVICE VALVES ON RE-
FRIGERANT LINES
3. SET ON MANIFOLD GAUGE SET
(a) Close both the hand valves of the manifold gauge set.
(b) Connect the quick disconnect adapters to the service
valves.
4. EVACUATE AIR FROM REFRIGERATION SYSTEM
(a) Connect the vacuum pump adapter to the vacuum pump.
(b) Connect the center hose of the manifold gauge set to the
vacuum pump adapter.
(c) Open both the high and low hand valves and run the vacu-
um pump.
(d) After 10 minutes or later, check that the low pressure
gauge indicates 750 mmHg (30 in. Hg) minimum.
HINT:
If the reading is 750 mmHg (30 in. Hg) close both hand valves
of the manifold gauge set and stop the vacuum pump.
Check the system for leaks and repair if necessary.
(e) Close both the high and low hand valves and stop the vac-
uum pump.
(f) Leave the system in this condition for at least 5 minutes
and check that there is no gauge indicator.
Page 16 of 3115
AC1HO-05
I24786
Pressure Switch Compressor and Magnetic Clutch
Ambient Temperature Sensor
CondenserNo.1 Junction Block
HTR Relay
RR HTR Relay
MG CLT Relay
- AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC-13
2738 Author: Date:
2004 LAND CRUISER (RM1071U)
LOCATION
