Page 2681 of 3115
SF14A-06
B13023
Ohmmeter
Continuity
B13024
Ohmmeter
No Continuity
B13025
AirAB
B13026
Battery AirB
A SF-48
- SFIVSV FOR CANISTER CLOSED VALVE (CCV)
1747 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. REMOVE VSV
2. INSPECT VSV FOR OPEN CIRCUIT
Using an ohmmeter, check that there is a continuity between
the terminals.
Resistance: 24 - 30 W at 20°C (68°F)
If there is no continuity, replace VSV.
3. INSPECT VSV FOR GROUND
Using an ohmmeter, check that there is no continuity between
each terminal and the body.
If there is a continuity, replace VSV.
4. INSPECT VSV OPERATION
(a) Check that air flows from the ports A to B.
(b) Apply the battery positive voltage across the terminals.
(c) Check that air does not flow from the ports A to B.
If operation is not as specified, replace VSV.
5. REINSTALL VSV
Page 2682 of 3115
SF0Y8-09
B16464
Vacuum HoseVSV for Vapor Pressure Sensor VSV Connector for Vapor Pressure Sensor
Vacuum Hose
- SFIVSV FOR VAPOR PRESSURE SENSOR
SF-45
1744 Author: Date:
2004 LAND CRUISER (RM1071U)
VSV FOR VAPOR PRESSURE SENSOR
COMPONENTS
Page 2683 of 3115
B08661
Ohmmeter
Continuity
SF0PM-1 1
B08662
Ohmmeter
No Continuity
B08663
Air E F
B08664Battery Air F
E SF-46
- SFIVSV FOR VAPOR PRESSURE SENSOR
1745 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. REMOVE VSV
2. INSPECT VSV
(a) Inspect VSV for open circuit.
Using an ohmmeter, check that there is continuity be-
tween the terminals.
Resistance: 30 - 36 W at 20°C (68°F)
If there is no continuity, replace the VSV.
(b) Inspect the VSV for ground.
Using an ohmmeter, check that there is no continuity be-
tween each terminal and the body.
If there is a continuity, replace the VSV.
(c) Inspect the VSV operation.
(1) Check that air flows from the ports E to F.
(2) Apply the battery positive voltage across the termi-
nals.
(3) Check that air flows from the ports E to F.
If operation is not as specified, replace VSV.
3. REINSTALL VSV
Page 2684 of 3115
SF0PP-10
B16451
Vapor Pressure Sensor ConnectorVapor Pressure Sensor
Joint Clip
- SFIVAPOR PRESSURE SENSOR
SF-51
1750 Author: Date:
2004 LAND CRUISER (RM1071U)
VAPOR PRESSURE SENSOR
COMPONENTS
Page 2685 of 3115
SF0PQ-10
B16452
13
Voltmeter
B09192
2
3Voltmeter SF-52
- SFIVAPOR PRESSURE SENSOR
1751 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT POWER SOURCE VOLTAGE OF VAPOR
PRESSURE SENSOR
(a) Disconnect the vapor pressure sensor connector.
(b) Turn the ignition switch ON.
(c) Using a voltmeter, measure the voltage between connec-
tor terminal 1 and 3 of the wiring harness side.
Voltage: 4.5 - 5.5 V
(d) Turn the ignition switch OFF.
(e) Reconnect the vapor pressure sensor connector.
2. INSPECT POWER OUTPUT OF VAPOR PRESSURE
SENSOR
(a) Turn the ignition switch ON.
(b) Remove the fuel tank cap.
(c) Connect a voltmeter to terminal 2 and 3, and measure the
output voltage.
Voltage: 3.0 - 3.6 V
(d) Reinstall the fuel tank cap.
(e) Turn the ignition switch OFF.
Page 2686 of 3115
RS0BK-08
H20939
Center Lower Cluster Finish Panel
17.5 (178, 13)Airbag Sensor Assembly
Front Console Box
Transfer Shift Lever Knob Front Seat LH
Upper Console Panel
Rear Console Box
Front Seat RH
N´m (kgf´cm, ft´lbf) : Specified torque
17.5 (178, 13)
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-69
2344 Author: Date:
2004 LAND CRUISER (RM1071U)
AIRBAG SENSOR ASSEMBLY
COMPONENTS
Page 2687 of 3115
RS0BM-03
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-71
2346 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. Vehicle not involved in collision:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Do a diagnostic system check (See page DI-692).
2. Vehicle involved in collision and airbag is not deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Do a diagnostic system check (See page DI-692).
3. Vehicle involved in collision and airbag is deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Replace the airbag sensor assembly (See page RS-69).
Page 2688 of 3115

RS0BO-08
H20940
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-73
2348 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
NOTICE:
Never use SRS parts from another vehicle. When re-
placing parts, replace them with new parts.
Never reuse the airbag sensor assembly involved in
a collision when the airbag has deployed.
Never repair a sensor in order to reuse it.
HINT:
For step 2 to 6, refer to page BO-91.
1. INSTALL AIRBAG SENSOR ASSEMBLY
(a) Install the airbag sensor assembly with the 3 bolts.
Torque: 17.5 N´m (178 kgf´cm, 13 ft´lbf)
(b) Connect the airbag sensor connectors.
NOTICE:
Connection of the connector is done after the sensor
assembly has been installed.
Make sure the sensor assembly is installed with the
specified torque.
If the sensor assembly has been dropped, or there are
cracks, dents or other defects in the case, bracket or
connector, replace the sensor assembly with a new
one.
When installing the sensor assembly, take care that
the SRS wiring does not interfere with other parts and
is not pinched between other parts.
After installing, shake the sensor assembly to check
that there is no looseness.
2. INSTALL CENTER LOWER INSTRUMENT CLUSTER
FINISH PANEL ASSEMBLY
3. INSTALL FRONT CONSOLE BOX
4. INSTALL REAR CONSOLE BOX WITH CONSOLE
REAR END PANEL
5. INSTALL UPPER CONSOLE PANEL
6. INSTALL TRANSFER SHIFT LEVER KNOB
7. INSTALL FRONT SEAT (See page BO-1 17)
8. INSPECT SRS WARNING LIGHT (See page DI-692)
