Page 1713 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H21249
Airbag Sensor
Assembly
Cowl Side J/B RH
C2619
TC 3F10
2D18 P-B
W-BP-B D7
DLC3
3E 14
7B5
W-B 13
4 CGTC
IF 7B4 J/B No. 7
P-B DI-932
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1125 Author: Date:

Page 1714 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AB0117AB0119H20916H21240
ON LOCK
AB0119H10688H10654
ON
CG
TC
(+) (-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-933
1126 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
If the DT

Page 1715 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AB0119H10689H10656
ON
TC
(+)
(-)
AB0117 AB0119H01302H12918
LOCK
ON
Airbag Sensor Assembly
TC
DI-934
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1127 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Chec

Page 1716 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AB0119H01304H01305
LOCKAirbag Sensor Assembly
TC
(+)
(-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-935
1128 Author: Date:
2004 LAND CRUISER (RM1071U)
If the DTC is displayed without a DTC chec

Page 1717 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI6OX-09
Supplemental Restraint System Check Sheet
Date Problem Occurred
Customer s Name
Registration No.
Registration Year
Frame No.
Odometer Reading
Weather
Temperature
Vehicle Operation
Road Condi

Page 1718 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI6OZ-25
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-701
894 Author: Date:
2004 LAND CRUISER (RM1071U)
DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, chec

DI6OZ-25
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-701
894 Author: Date:
2004 LAND CRUISER (RM1071U)
DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, check the circuit listed for that code in the table
below (Proceed to the page given for that circuit.).
DTC No.
(See Page)Detection ItemTrouble AreaSRS
Warning Light
B0100/13
(DI-71 1)
Short in D squib circuitSteering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B0101/14
(DI-717)
Open in D squib circuitSteering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B0102/11
(DI-722)
Short in D squib circuit (to ground)Steering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B0103/12
(DI-727)
Short in D squib circuit (to B+)Steering wheel pad (squib)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B0105/53
(DI-732)Short in P squib circuitFront passenger airbag assembly (squib)
Airbag sensor assembly
Dash wire
ON
B0106/54
(DI-736)Open in P squib circuitFront passenger airbag assembly (squib)
Airbag sensor assembly
Dash wire
ON
B0107/51
(DI-739)Short in P squib circuit (to ground)Front passenger airbag assembly (squib)
Airbag sensor assembly
Dash wire
ON
B0108/52
(DI-742)Short in P squib circuit (to B+)Front passenger airbag assembly (squib)
Airbag sensor assembly
Dash wire
ON
B0110/43
(*1)
(DI-745)Short in side squib RH circuitSide airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0111/44
(*1)
(DI-749)Open in side squib RH circuitSide airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0112/41
(*1)
(DI-752)Short in side squib RH circuit
(to ground)Side airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0113/42
(*1)
(DI-755)Short in side squib RH circuit
(to B+)Side airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0115/47
(*1)
(DI-758)Short in side squib LH circuitSide airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink

Page 1719 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI-702
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
895 Author: Date:
2004 LAND CRUISER (RM1071U)B0116/48
(*1)
(DI-762)
Open in side squib LH circuitSide airbag assembly LH (squib)
Airbag sensor

DI-702
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
895 Author: Date:
2004 LAND CRUISER (RM1071U)B0116/48
(*1)
(DI-762)
Open in side squib LH circuitSide airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0117/45
(*1)
(DI-765)Short in side squib LH circuit
(to ground)Side airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0118/46
(*1)
(DI-768)Short in side squib LH circuit
(to B+)Side airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0126/B0127/
27
(DI-771)Seat belt buckle switch LH
malfunctionFront seat inner belt LH
Airbag sensor assembly
Floor No. 1 wire
Front seat wire LH
ON
B0130/63
(DI-777)Short in P/T squib RH circuitSeat belt pretensioner RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0131/64
(DI-781)Open in P/T squib RH circuitSeat belt pretensioner RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0132/61
(DI-784)Short in P/T squib RH circuit
(to ground)Seat belt pretensioner RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0133/62
(DI-787)Short in P/T squib RH circuit
(to B+)Seat belt pretensioner RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B0135/73
(DI-790)Short in P/T squib LH circuitSeat belt pretensioner LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0136/74
(DI-794)Open in P/T squib LH circuitSeat belt pretensioner LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0137/71
(DI-797)Short in P/T squib LH circuit
(to ground)Seat belt pretensioner LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B0138/72
(DI-800)Short in P/T squib LH circuit
(to B+)Seat belt pretensioner LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B1100/31
(DI-803)Airbag sensor assembly malfunctionAirbag sensor assemblyON
B1135/24
(DI-805)
Half connection in airbag sensor
assembly connectorAirbag sensor assembly
Dash wire
Floor No. 1 wire
Floor No. 2 wire
ON
B1140/32
(*1)
(DI-807)Side and curtain shield airbag sensor
assembly RH malfunctionSide and curtain shield airbag sensor assembly RH
Airbag sensor assembly
Floor No. 2 wire
Blink
B1141/33
(*1)
(DI-813)Side and curtain shield airbag sensor
assembly LH malfunctionSide and curtain shield airbag sensor assembly LH
Airbag sensor assembly
Floor No. 1 wire
Blink
B1148/36
(DI-819)
Front airbag sensor RH malfunctionFront airbag sensor RH
Airbag sensor assembly
Dash wire
Engine room No. 2 wire
Engine room main wire
ON

Page 1720 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-703
896 Author: Date:
2004 LAND CRUISER (RM1071U)B1149/37
(DI-828)
Front airbag sensor LH malfunctionFront airbag sensor LH
Airbag sensor assembly

- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-703
896 Author: Date:
2004 LAND CRUISER (RM1071U)B1149/37
(DI-828)
Front airbag sensor LH malfunctionFront airbag sensor LH
Airbag sensor assembly
Dash wire
Engine room No. 2 wire
Engine room main wire
ON
B1153/25
(DI-836)
Seat position sensor malfunctionSeat position sensor assembly
Airbag sensor assembly
Floor No. 1 wire
Front seat wire LH
ON
B1154/38
(*1)
(DI-844)Curtain shield airbag sensor assembly
RH malfunctionCurtain shield airbag sensor assembly RH
Airbag sensor assembly
Floor No. 2 wire
Blink
B1155/39
(*1)
(DI-850)Curtain shield airbag sensor assembly
LH malfunctionCurtain shield airbag sensor assembly LH
Airbag sensor assembly
Floor No. 1 wire
Blink
B1160/83
(*1)
(DI-856)Short in curtain shield squib RH circuitCurtain shield airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B1161/84
(*1)
(DI-860)Open in curtain shield squib RH circuitCurtain shield airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B1162/81
(*1)
(DI-863)Short in curtain shield squib RH circuit
(to ground)Curtain shield airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B1163/82
(*1)
(DI-866)Short in curtain shield squib RH circuit
(to B+)Curtain shield airbag assembly RH (squib)
Airbag sensor assembly
Floor No. 2 wire
Blink
B1165/87
(*1)
(DI-869)Short in curtain shield squib LH circuitCurtain shield airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B1166/88
(*1)
(DI-873)Open in curtain shield squib LH circuitCurtain shield airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B1167/85
(*1)
(DI-876)Short in curtain shield squib LH circuit
(to ground)Curtain shield airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B1168/86
(*1)
(DI-879)Short in curtain shield squib LH circuit
(to B+)Curtain shield airbag assembly LH (squib)
Airbag sensor assembly
Floor No. 1 wire
Blink
B1180/17
(DI-882)
Short in D squib (2nd step) circuitSteering wheel pad (D squib, 2nd step)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B1181/18
(DI-888)
Open in D squib (2nd step) circuitSteering wheel pad (D squib, 2nd step)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
B1182/19
(DI-893)
Short in D squib (2nd step) circuit
(to ground)Steering wheel pad (D squib, 2nd step)
Spiral cable
Airbag sensor assembly
Dash wire
Column wire
ON
