TOYOTA LAND CRUISER 1998 Factory Repair Manual INSTALLATION Butt Weld Butt Weld Lift-Up Type Back Door Only: Lift-Up Type Back Door Only: Butt Weld Butt Weld 1. Temporarily install the new parts and check the fit of the tail gate or back door. B

Page 642 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual mm in. 220 908.66 3.54 BODY LOWER BACK PANEL (CUT) REMOVAL (With the quarter panel rear extension removed.) Lift-Up Type Back Door Only: 220 mm Cut and Join Location 90 mm Cut and Join Location 1.

Page 643 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BODY PANEL REPLACEMENTRE-49

Page 644 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual INSTALLATION Butt Weld Lift-Up Type Back Door Only: Butt Weld BODY PANEL REPLACEMENTRE-50

Page 645 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual Back Door Opening Lower Reinforcement BODY PANEL REPLACEMENTRE-51

Page 646 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual mmin. 2208.66 BODY LOWER BACK OUTER PANEL (CUT) Door Only: REMOVAL Swing Type Back Cut and Join Location Cut and Join Location 220 mm 220 mm Lift-Up Type Back Door Only: Lift-Up Type Back Door Only:

Page 647 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual INSTALLATION Swing Type Back Door Only: Butt Weld Butt Weld Lift-Up Type Back Door Only: Lift-Up Type Back Door Only: 1. Temporarily install the new parts and check the fit of the tail gate or back

Page 648 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual mm in. 220 8.66 BODY LOWER BACK OUTER PANEL (CUT) REMOVAL (With the quarter panel rear extension removed.) Swing Type Back Door Only: Cut and Join Location 220 mm Lift-Up Type Back Door Only: Lift-Up
