Page 649 of 3115
INSTALLATION
Swing Type Back Door Only:
Butt Weld
Lift-Up Type Back Door Only:
Lift-Up Type Back Door Only:
Back Door Opening
Lower Reinforcement
BODY PANEL REPLACEMENTRE-45
Page 650 of 3115
mm in.
50
140
1501.97
5.51
5.91
CENTER BODY PILLAR (CUT)
REMOVAL
Cut and Join Location
(Cut Location for Supply Parts)
[Cut and Join Location]
50 mm
150 mm
140 mm
Cut and Join Location
Cut and Join Location
[Cut and Join Locations]
50 mm
50 mm
1. Cut and join the parts at the locations as shown
above.
2. Cut and join the outer pillar and pillar reinforce-
ment at position shifted about 50 mm (1.97
in.)3. Cut and join the rocker outer panel and rocker
panel reinforcement at position shifted about
50 mm (1.97 in.)
BODY PANEL REPLACEMENTRE-18
Page 651 of 3115
INSTALLATION
Butt Weld
Pillar Reinforcement
Inner Pillar
Rocker Panel
Reinforcement
Butt Weld
Butt Weld
Foamed Material
Application Area
Butt Weld
Butt Weld
Butt Weld
1. Temporarily install the new parts and mea-
sure each part in accordance with the body
dimension diagram.
2. Temporarily install the new parts and check
the fit of the front door and rear door.3. After welding inner pillar and rocker panel
reinforcement and pillar reinforcement to the
vehicle install the outer pillar.
4. After installing the new parts, apply foamed
materials.
BODY PANEL REPLACEMENTRE-19
Page 652 of 3115
COWL TOP SIDE PANEL (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-10
Page 653 of 3115
INSTALLATION
BODY PANEL REPLACEMENTRE-11
Page 654 of 3115
mm in.
4.5
5.0
5.50.177
0.197
0.217
FIT STANDARDS
After doors and the engine hood are installed, be sure to perform fit adjustment to prevent abnormal wind
noise and ensure a good appearance.
4.5 mm
5.5 mm
5.5 mm
5.0 mm
5.5 mm
5.0 mm
APPENDIXAP-2
Page 655 of 3115
mm in.
5.5
10.50.217
0.413 10.5 mm
5.5 mm
5.5 mm
10.5 mm
5.5 mm
10.5 mm
5.5 mm
5.5 mm
APPENDIXAP-3
Page 656 of 3115
FLOOR SIDE INNER REAR MEMBER (ASSY)
REMOVAL (With the center body pillar removed.)
BODY PANEL REPLACEMENTRE-20
