Page 385 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1JD-01 - BODYFRONT DOOR BO-13 2587 Author: Date: 2004 LAND CRUISER (RM1071U) REASSEMBLY Reassembly is in the reverse order of disassembly (See page BO-9).

Page 386 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1KT-04 H18928 Headrest Headrest Support Seatback Board Lumber Support Seatback Frame Seatback Pad Armrest Seat Cushion Cover Seat Cushion Pad Seat Cushion Frame Seat Cushion Inner Shield Front Seat

Page 387 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO4J1-01 H03731 A B H03732 H03733 H03734 BO-106 - BODYFRONT SEAT 2680 Author: Date: 2004 LAND CRUISER (RM1071U) DISASSEMBLY 1. REMOVE HEADREST 2. REMOVE SEATBACK BOARD Remove the seatback board as

Page 388 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H03735 H03736 H04737 H04738 H20959 - BODYFRONT SEAT BO-107 2681 Author: Date: 2004 LAND CRUISER (RM1071U) 4. REMOVE FRONT SEAT INNER BELT (a) Remove the clamp, then disconnect the connector. (b) R

Page 389 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H20963 H19941 H21292 H20961 BO-108 - BODYFRONT SEAT 2682 Author: Date: 2004 LAND CRUISER (RM1071U) 12. REMOVE SEATBACK ASSEMBLY (a) Remove the hog rings. (b) Disengage the hook as shown in the ill

Page 390 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H04468 H04785 H18929 - BODYFRONT SEAT BO-109 2683 Author: Date: 2004 LAND CRUISER (RM1071U) 16. REMOVE LUMBER SUPPORT Remove the 2 bolts, the lumber support and the spacer. 17. REMOVE SEATBACK COV

Page 391 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1KX-02 - BODYFRONT SEAT BO-1 17 2691 Author: Date: 2004 LAND CRUISER (RM1071U) INSTALLATION Installation is in the reverse order of removal (See page BO-105).

Page 392 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO4J3-01 H18929 H04785 H04468 H21292 BO-1 14 - BODYFRONT SEAT 2688 Author: Date: 2004 LAND CRUISER (RM1071U) REASSEMBLY 1. Driver s Side: INSTALL SEAT POSITION SENSOR Install the seat position se
