Page 1089 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19976 Engine Room J/B: EFI or ECD No. 1 Fuse - DIAGNOSTICSENGINE DI-349 542 Author: Date: 2004 LAND CRUISER (RM1071U) 7 Check EFI or ECD No. 1 fuse of engine room J/B. PREPARATION: Remove the EF

Page 1090 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI-350 - DIAGNOSTICSENGINE 543 Author: Date: 2004 LAND CRUISER (RM1071U) Fuel Pump Control Circuit CIRCUIT DESCRIPTION Refer to DTC P0230 on page DI-162. WIRING DIAGRAM Refer to DTC P0230 on page

Page 1091 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - DIAGNOSTICSENGINE DI-351 544 Author: Date: 2004 LAND CRUISER (RM1071U) 4 Check fuel pump (See page SF-7). NG Repair or replace fuel pump. OK 5 Check circuit opening relay (See page SF-39). NG Re

Page 1092 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19521A19629 FC(+) ECM ConnectorE9 DI-352 - DIAGNOSTICSENGINE 545 Author: Date: 2004 LAND CRUISER (RM1071U) 7 Check voltage between terminal FC and E1 of ECM connector. PREPARATION: Turn the ignit

Page 1093 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - DIAGNOSTICSENGINE DI-353 546 Author: Date: 2004 LAND CRUISER (RM1071U) OBD II scan tool (excluding hand-held tester): 1 Check operation of fuel pump (See page SF-7). OK Go to step 7. NG 2 Check

Page 1094 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19521A19629 FC(+) ECM ConnectorE9 DI-354 - DIAGNOSTICSENGINE 547 Author: Date: 2004 LAND CRUISER (RM1071U) 6 Check voltage between terminal FC of ECM connector and body ground. PREPARATION: Turn

Page 1095 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A21366 Engine Room R/B11ECM W E9 11 C13 C12 SB10 Battery7 4I18 Ignition Switch 73E 3Q 6 B-R MET Combination Meter Malfunction Indicator Lamp AM2IG2 AM2 W B-RSB 2Q 2D32 78 Cowl Side J/B RHA AJ4

Page 1096 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A21033ECM ConnectorW E9 DI-356 - DIAGNOSTICSENGINE 549 Author: Date: 2004 LAND CRUISER (RM1071U) INSPECTION PROCEDURE HINT: Troubleshoot each trouble symptom in accordance with the chart below .
