Page 337 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE-4
- BODY ELECTRICALTROUBLESHOOTING
2377 Author: Date:
2004 LAND CRUISER (RM1071U) Turn signal does not light up in one direction.
1. Turn Signal Switch
2. Wire HarnessBE-40
-
Only one bulb does

BE-4
- BODY ELECTRICALTROUBLESHOOTING
2377 Author: Date:
2004 LAND CRUISER (RM1071U) Turn signal does not light up in one direction.
1. Turn Signal Switch
2. Wire HarnessBE-40
-
Only one bulb does not light up.1. Bulb
2. Wire Harness-
-
INTERIOR LIGHT SYSTEM:
This system uses the body control system, so check the body control system before you proceed with trou-
bleshooting(See page DI-1038).
SymptomSuspect AreaSee page
All the lights do not come ON.
1. DOME Fuse
2. Body ECU
3. DOME Relay(Cowl Side J/B LH)-
DI-1038
-
The light does not come ON when the driver's door is opened.1. Driver's Door Courtesy Switch
2. Wire HarnessBE-44
-
The light does not come ON when the passenger's door is
opened.1. Passenger's Door Courtesy Switch
2. Wire HarnessBE-44
-
The light does not come on when the rear-right door is opened.1. Rear-Right Door Courtesy Switch
2. Wire HarnessBE-44
-
The light does not come on when the rear-left door is opened.1. Rear-Left Door Courtesy Switch
2. Wire HarnessBE-44
-
Only one of the bulbs comes ON.1. Bulb-
The illumination does not fade out when all the doors are closed.
1. Courtesy Switch
2. Wire Harness
3. Boby ECUBE-44
-
DI-1038
The illumination does not fade out immediately when the ignition
switch is turned to ACC or ON within 15 seconds after all the
doors are closed.
1. Ignition Switch
2. ACC Fuse
3. ECU-IG1 Fuse
4. Body ECU
5. Wire HarnessBE-29
-
-
DI-1038
-
The illumination does not fade out immediately when all the doors
are locked within 15 seconds after they are closed.1. Door Unlock Detection Switch
2. Wire HarnessBE-88
-
Room light does not light up.
1. Bulb
2. Room Light
3. Rear Personal Light
4. Wire Harness-
BE-44
BE-44
-
Front personal light does not light up.
1. Bulb
2. Front Personal Light
3. Room Light
4. Wire Harness-
BE-44
BE-44
-
Rear Room light does not light up.
1. Bulb
2. Rear Room Light
3. Wire Harness-
BE-44
-
Vanity light does not light up.
1. Bulb
2. Vanity Light
3. Wire Harness-
BE-44
-
Glove compartment light does not light up.
1. Bulb
2. Glove Compartment Courtesy Switch
3. Wire Harness-
BE-44
-
Courtesy light does not light up.
1. Bulb
2. Door Courtesy Switch
3. Wire Harness-
BE-44
-

Page 338 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BODY ELECTRICALTROUBLESHOOTING
BE-5
2378 Author: Date:
2004 LAND CRUISER (RM1071U)
BACK-UP LIGHT SYSTEM:
SymptomSuspect AreaSee page
Back-up Light does not light up.
1. GAUGE2 Fuse
2. Ignition

Page 339 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE-6
- BODY ELECTRICALTROUBLESHOOTING
2379 Author: Date:
2004 LAND CRUISER (RM1071U) Rear washer motor does not operate.
1. Rear Washer Motor
2. Rear Washer Switch
3. Wire HarnessBE-52
BE-52
-
Was

Page 340 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BODY ELECTRICALTROUBLESHOOTING
BE-7
2380 Author: Date:
2004 LAND CRUISER (RM1071U) Seat belt warning light does not light up.
1. LED
2. Seat Belt Buckle Switch
3. Wire Harness
4. Body ECU-
BE-63

Page 341 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE-8
- BODY ELECTRICALTROUBLESHOOTING
2381 Author: Date:
2004 LAND CRUISER (RM1071U) ECT PWR indicator light does not light up.
1. LED
2. ECT Pattern Select Switch
3. Combination Meter
4. Wire Har

BE-8
- BODY ELECTRICALTROUBLESHOOTING
2381 Author: Date:
2004 LAND CRUISER (RM1071U) ECT PWR indicator light does not light up.
1. LED
2. ECT Pattern Select Switch
3. Combination Meter
4. Wire Harness
5. ECT System-
-
BE-58
-
DI-358
2nd start ETCS indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. ECM-
BE-58
-
DI-1
Center Diff. lock indicator light does not light up.
1. LED
2. Combination Meter
3. Transfer 4WD Position Detection Switch
4. Wire Harness-
BE-58
TR-49
-
Indicator lights do not light up. (Except Turn, Hi-beam and
security)1. GAUGE2 Fuse
2. Wire Harness-
-
DEFOGGER SYSTEM:
SymptomSuspect AreaSee page
All defogger systems do not operate.
1. DEFOG Fuse
2. DEFOG Relay
3. Defogger Switch (Integration Control Panel Assembly)
4. Wire Harness-
-
BE-75
-
Rear window defogger does not operate.
1. Defogger Wire
2. Choke Coil
3. Wire HarnessBE-75
-
-
Mirror defogger does not operate.
1. MIR HTR Fuse
2. Engine Room J/B Relay Circuit
3. Mirror Defogger
4. Wire Harness-
BE-15
BE-75
-
POWER WINDOW CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power Door Lock System is normal.)1. P/W (FL, FR, RL, RR) Fuse
2. Power Window Master Switch
3. Wire Harness-
BE-79
-
Only the driver's window does not operate.
1. Power Window Master Switch
2. Body ECU
3. Power Window Motor
4. Wire HarnessBE-79
DI-1038
BE-79
-
ºWindow lock functionº does not operate.1. Power Window Master SwitchBE-79
POWER DOOR LOCK CONTROL SYSTEM:
This system uses the body control system, so check diagnosis system of the body control system before
you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the doors cannot be locked or unlocked.
(Power Window Control System is normal.)
1. DOOR Fuse
2. Door Lock Control Switch
3. Wire Harness
4. Body ECU-
BE-88
-
DI-1038
Only one side door lock control does not operate.1. Door Lock Motor
2. Wire HarnessBE-88
-

Page 342 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BODY ELECTRICALTROUBLESHOOTING
BE-9
2382 Author: Date:
2004 LAND CRUISER (RM1071U) Door key related function does not operate.
1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Body ECUBE-88

Page 343 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE-10
- BODY ELECTRICALTROUBLESHOOTING
2383 Author: Date:
2004 LAND CRUISER (RM1071U) Passengers seat heater does not operate.
1. Seat Heater Switch (D, P)
2. Wire HarnessBE-121
-
Seat heater tem

Page 344 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE0RV-03
I06375
Right turn
Left turn
I25048
BE-40
- BODY ELECTRICALTURN SIGNAL AND HAZARD WARNING SYSTEM
2413 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT TURN SIGNAL SWITCH CON
