Page 1193 of 3115

A20870
E1 +B
OX
+BHT
OX E1HT H5
H7
H6
H8
Components Side:
Bank1 Sensor1, Bank2 Sensor1
Bank1 Sensor2, Bank2 Sensor2
DI-144
- DIAGNOSTICSENGINE
337 Author: Date:
2004 LAND CRUISER (RM1071U)
2 Check output voltage of heated oxygen sensor.
PREPARATION:
(a) Connect the OBD II scan tool or the hand-held tester to the DLC3.
(b) After warming up the engine, run the engine at 2,500 rpm for 3 minutes.
(c) When using hand-held tester, enter the following menu: DIAGNOSIS / ENHANCED OBD II / DATA
LIST / ALL / O2S B2 S1 or B2 S2.
CHECK:
Read the voltage output of the heated oxygen sensor when the engine speed is suddenly increased.
HINT:
Quickly accelerate the engine to 4,000 rpm 3 minutes by using the accelerator pedal.
OK:
Heated oxygen sensor output voltage: Alternates from 0.4 V or less to 0.5 V or more.
OK Go to step 6.
NG
3 Check resistance of heated oxygen sensor heater.
PREPARATION:
Disconnect the H5, H6, H7 or H8 heated oxygen sensor con-
nector.
CHECK:
Measure resistance between terminals of the heated oxygen
sensor.
OK:
Tester ConnectionSpecified Condition
HT (H5-1) - +B (H5-2)11 to 16 W (20°C)
HT (H6-1) - +B (H6-2)11 to 16 W (20°C)
HT (H7-1) - +B (H7-2)11 to 16 W (20°C)
HT (H8-1) - +B (H8-2)11 to 16 W (20°C)
NG Replace heated oxygen sensor.
OK
Page 1194 of 3115

A21543
1
23
4 EFI or ECD Relay
A21341
+B
OX
E1HT
H6
H8
Components Side:
Bank1 Sensor2, Bank2 Sensor2
A21340
OX2B
HT1BE6
ECM ConnectorOX1B
HT2B
- DIAGNOSTICSENGINE
DI-145
338 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check EFI or ECD relay.
PREPARATION:
Remove the EFI or ECD relay from the engine room R/B.
CHECK:
Inspect the EFI or ECD relay.
OK:
Terminal No.ConditionSpecified Condition
2 - 4ConstantContinuity
UsuallyNo Continuity
1 - 3Apply B+ between
terminals 2 and 4Continuity
NG Replace EFI or ECD relay.
OK
5 Check for open and short in harness and connector between ECM and heated
oxygen sensor.
PREPARATION:
(a) Disconnect the H6 or H8 heated oxygen sensor connec-
tor.
(b) Disconnect the E6 ECM connector.
CHECK:
Measure the resistance between the wire harness side connec-
tors.
OK:
Tester ConnectionSpecified Condition
OX (H6-3) - OX1B (E6-29)Below 1 W
HT (H6-1) - HT1B (E6-5)Below 1 W
OX (H8-3) - OX2B (E6-21)Below 1 W
HT (H8-1) - HT2B (E6-25)Below 1 W
OX (H6-3) or OX1B (E6-29) -
Body ground10 kW or higher
HT (H6-1) or HT1B (E6-5) -
Body ground10 kW or higher
OX (H8-3) or OX2B (E6-21) -
Body ground10 kW or higher
HT (H8-1) or HT2B (E6-25) -
Body ground10 kW or higher
Page 1195 of 3115
A21040
Reference (Bank 1 Sensor 1 System Drawing)
From
BatteryEFI or ECD
No. 1 FuseEFI or ECD
RelayEFI or ECD
No. 2 FuseHeater Oxygen
Sensor
Heater
SensorHT1A
OX1A
E2
MRELECM
DI-146
- DIAGNOSTICSENGINE
339 Author: Date:
2004 LAND CRUISER (RM1071U)
NG Repair or replace harness or connector.
OK
Replace heated oxygen sensor.
6 Perform confirmation driving pattern.
HINT:
Clear all DTCs prior to performing the confirmation driving pattern.
Go
7 Is the DTC P0136 or P0156 being output again?
NO Check for intermittent problems.
YES
Replace heated oxygen sensor.
Page 1196 of 3115

- DIAGNOSTICSENGINE
DI-147
340 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC P0171 System too Lean (Bank 1)
DTC P0172 System too Rich (Bank 1)
DTC P0174 System too Lean (Bank 2)
DTC P0175 System too Rich (Bank 2)
CIRCUIT DESCRIPTION
The fuel trim is related to the feedback compensation value, not to the basic injection time. The fuel trim in-
cludes the short-term fuel trim and the long-term fuel trim.
The short-term fuel trim is the short-term fuel compensation used to maintain the air-fuel ratio at stoichio-
metric air-fuel ratio. The signal from the heated oxygen sensor indicates whether the air-fuel ratio is RICH
or LEAN compared to the stoichiometric air-fuel ratio. This variance triggers a reduction in the fuel volume
if the air-fuel ratio is RICH, and an increase in the fuel volume if it is LEAN.
The long-term fuel trim is the overall fuel compensation carried out in long-term to compensate for a continu-
al deviation of the short-term fuel trim from the central value, due to individual engine differences, wear over-
time and changes in the operating environment.
If both the short-term fuel trim and the long-term fuel trim are LEAN or RICH beyond a certain value, it is
detected as a malfunction and the MIL is illuminated and a DTC is set.
DTC No.DTC Detecting ConditionTrouble Area
P0171
P0174When air-fuel ratio feedback is stable after warming up engine,
fuel trim is considerably in error on LEAN side
(2 trip detection logic)
Air induction system
Injector blockage
Mass air flow meter
Engine coolant temperature sensor
Fuel pressure
Gas leakage in exhaust system
Open or short in heated oxygen sensor (bank 1, 2 sensor 1)
circuit
Heated oxygen sensor (bank 1, 2 sensor 1)
Heated oxygen sensor heater (bank 1, 2 sensor 1)
EFI or ECD relay
PCV piping
ECM
P0172
P0175When air-fuel ratio feedback is stable after warming up engine,
fuel trim is considerably in error on RICH side
(2 trip detection logic)
Injector leak, blockage
Mass air flow meter
Engine coolant temperature sensor
Ignition system
Fuel pressure
Gas leakage in exhaust system
Open or short in heated oxygen sensor (bank 1, 2 sensor 1)
circuit
Heated oxygen sensor (bank 1, 2 sensor 1)
ECM
DIC2A-01
Page 1197 of 3115

A20489A21204
Fuel compensation
amount1.40
1.0
0.65+40 (%): Thershold at LEAN
-35 (%): Thershold at RICH DI-148
- DIAGNOSTICSENGINE
341 Author: Date:
2004 LAND CRUISER (RM1071U)
HINT:
When DTC P0171 or P0174 is recorded, the actual air-fuel ratio is on the LEAN side. When DTC
P0172 or P0175 is recorded, the actual air-fuel ratio is on the RICH side.
If the vehicle runs out of fuel, the air-fuel ratio is LEAN and DTC P0171 or P0174 may be recorded.
The MIL then comes on.
If the total of the short-term fuel trim value and long-term fuel trim value is within 35 % (engine cool-
ant temperature is more than 75 C (167F)), the system is functioning normally.
MONITOR DESCRIPTION
Under closed-loop fuel control, fuel injection amounts that deviate from the ECM's estimated fuel amount
will cause a change in the long-term fuel trim compensation value. This long-term fuel trim is adjusted when
there are persistent deviations in the short-term fuel trim values. And the deviation from a simulated fuel
injection amount by the ECM affects a smoothed fuel trim learning value. The smoothed fuel trim learning
value is the combination of smoothed short term fuel trim (fuel feedback compensation value) and smoothed
long term fuel trim (learning value of the air-fuel ratio). When the smoothed fuel trim learning value exceeds
the DTC threshold, the ECM interprets this as a fault in the fuel system and sets a DTC.
Example:
If the smoothed fuel trim learning value is more than +40% or less than -35% the ECM interprets this as a
malfunction in the fuel system.
Page 1198 of 3115

- DIAGNOSTICSENGINE
DI-149
342 Author: Date:
2004 LAND CRUISER (RM1071U)
MONITOR STRATEGY
P0171Fuel system lean (Bank 1)
RltdDTCP0172Fuel system rich (Bank 1)Related DTCsP0174Fuel system lean (Bank 2)
P0175Fuel system rich (Bank 2)
Main sensors/componentsFront oxygen sensor
Required sensors/componentsRelated sensors/componentsEngine coolant temperature sensor, Mass air flow
meter, Crankshaft position sensor
Frequency of operationContinuous
Duration10 sec.
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever the follow-
ing DTCs are not presentSee ºList of disable a monitorº (on page DI-3)
Battery voltage11 V-
Fuel system: Closed loop13 sec.-
One of the following conditions is met:A or B
A. Engine speed-1,000 rpm
B. Intake air amount per revolution0.26 g/sec.-
Warm up condition to enable air fuel ratio
learning controlConditions are met
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Following condition is continue for 3 sec.A or B
A. Smoothed fuel trim learning value (Lean)40% or more
B. Smoothed fuel trim learning value (Rich)-35% or less
WIRING DIAGRAM
Refer to DTC P0031 on page DI-49.
Page 1199 of 3115

+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Case 1
Case 2
Case 3
Case 4
Output voltage of heated oxygen
sensor (sensor 1: front sensor)
Injection volume
Output voltage
Output voltage of heated oxygen
sensor (sensor 2: rear sensor)Mainly suspect
trouble area
OK
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
Sensor 1: front sensor
(sensor 1, heater, sensor 1
circuit)
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NGExtremely rich or lean of the
actual air-fuel ratio
(Injector, fuel pressure, gas
leakage in exhaust system,
etc.) OK
OK
OK
Almost no reaction
'
Sensor 2: rear sensor
(sensor 2, heater, sensor 2
circuit)
Almost no reactionAlmost no reaction
Almost no reaction
DI-150
- DIAGNOSTICSENGINE
343 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
Hand-held tester only:
The narrowing down the trouble area is possible by performing ACTIVE TEST of the following ºA/F CON-
TROLº (Heated oxygen sensor or another can be distinguished).
(a) Perform ACTIVE TEST by hand-held tester (A/F CONTROL).
HINT:
ºA/F CONTROLº is the ACTIVE TEST which changes the injection volume to -12.5 % or +25 %.
(1) Connect the hand-held tester to the DLC3 on the vehicle.
(2) Turn the ignition switch ON.
(3) Warm up the engine with the engine speed at 2,500 rpm for approximately 90 seconds.
(4) Select the item ºDIAGNOSIS / ENHANCED OBD II / ACTIVE TEST / A/F CONTROLº.
(5) Perform ºA/F CONTROLº with the engine in an idle condition (press the right or left button).
RESULT:
Heated oxygen sensor reacts in accordance with increase and decrease of injection volume
+25 % " rich output: More than 0.5 V
-12.5 % " lean output: Less than 0.4 V
NOTICE:
However, there is a few seconds delay in the sensor 1 (front sensor) output. And there is about 20
seconds delay in the sensor 2 (rear sensor).
Page 1200 of 3115

- DIAGNOSTICSENGINE
DI-151
344 Author: Date:
2004 LAND CRUISER (RM1071U)
The following A/F CONTROL procedure enables the technician to check and graph the voltage output of
the heated oxygen sensors (sensor 1 and 2).
For displaying the graph indication, enter ºACTIVE TEST / A/F CONTROL / USER DATAº then select ºO2S
B1S1 and O2S B1S2º by pressing ºYESº button and push ºENTERº button before pressing ºF4º button.
HINT:
If different DTCs related to different systems that have terminal E2 as the ground terminal, terminal
E2 may be open.
Read freeze frame data using the hand-held tester or the OBD II scan tool. Freeze frame data records
the engine conditions when a malfunction is detected. When troubleshooting, it is useful for determin-
ing whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio
was lean or rich, etc. at the time of the malfunction.
A high heated oxygen sensor (sensor 1) voltage (0.5 V or more) could be caused by a rich air fuel mix-
ture. Check for conditions that would cause the engine to run rich.
A low heated oxygen sensor (sensor 1) voltage (0.4 V or less) could be caused by a lean air fuel mix-
ture. Check for conditions that would cause the engine to run lean.
1 Check air induction system (See page SF-1).
CHECK:
Check the air induction system for vacuum leaks.
NG Repair or replace air induction system.
OK
2 Check connection of PCV piping.
NG Repair or replace PCV piping.
OK
3 Check injector injection (See page SF-24).
NG Replace injector.
OK
