Page 2457 of 3115
B04485
Oil Pump
Crankshaft Position
Sensor Connector Crankshaft
Position Sensor
Oil Filter, Oil Cooler and
Filter Bracket AssemblyOil Cooler HoseClamp
Oil StrainerOil Dipstick
Guide and
Dipstick O-Ring
Gasket
No.1 Oil Pan
No.2 Oil Pan Oil Pan Baffle PlateClamp
Gasket
Drain Plugx 20
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part Gasket
30.5 (310, 22)
15.5 (160, 11)
O-Ring
15.5 (160, 11)
x 4
x 8
28 (290, 21)
7.5 (80, 66 in.´lbf)
7.5 (80, 66 in.´lbf)
7.5 (80, 66 in.´lbf)
7.5 (80, 66 in.´lbf)
39 (400, 29)
7.5 (80, 66 in.´lbf)
18 (185,13)
15 (153,11)
LU-6
- LUBRICATIONOIL PUMP
1787 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2458 of 3115
B03735
Crankshaft
Front Oil Seal
Compression Spring Relief Valve Driven RotorDrive Rotor
Oil Pump Body Coverx 10
Non-reusable partSnap RingRetainer
Oil Pump Body
- LUBRICATIONOIL PUMP
LU-7
1788 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2459 of 3115
LU08R-07
B03740
B03741
- LUBRICATIONOIL PUMP
LU-1 1
1792 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE RELIEF VALVE
(a) Using snap ring pliers, remove the snap ring.
(b) Remove the retainer, spring and relief valve.
2. REMOVE DRIVE AND DRIVEN ROTORS
Remove the 10 screws, pump body cover, the drive and driven
rotors.
Page 2460 of 3115

LU08S-05
B04454
B04455
Mark
B04456
B04457
B04458
LU-12
- LUBRICATIONOIL PUMP
1793 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT RELIEF VALVE
Coat the valve with engine oil and check that it falls smoothly
into the valve hole by its own weight.
If it doesn't, replace the relief valve. If necessary, replace the oil
pump assembly.
2. INSPECT DRIVE AND DRIVEN ROTORS INTO OIL
PUMP BODY
Place the drive and driven rotors into the oil pump body with the
mark facing upward.
3. INSPECT ROTORS FOR TIP CLEARANCE
Using a feeler gauge, measure the clearance between the drive
and driven rotor tips.
Standard tip clearance:
0.110 - 0.240 mm (0.0043 - 0.0094 in.)
Maximum tip clearance: 0.35 mm (0.0138 in.)
If the tip clearance is greater than maximum, replace the rotors
as a set.
4. INSPECT ROTORS FOR SIDE CLEARANCE
Using a feeler gauge and precision straight edge, measure the
clearance between the rotors and precision straight edge.
Standard side clearance:
0.030 - 0.090 mm (0.0012 - 0.0035 in.)
Maximum side clearance: 0.15 mm (0.0059 in.)
If the side clearance is greater than maximum, replace the ro-
tors as a set. If necessary, replace the oil pump assembly.
5. INSPECT ROTOR FOR BODY CLEARANCE
Using a feeler gauge, measure the clearance between the driv-
en rotor and body.
Standard body clearance:
0.100 - 0.175 mm (0.0039 - 0.0069 in.)
Maximum body clearance: 0.30 mm (0.0118 in.)
If the body clearance is greater than maximum, replace the ro-
tors as a set. If necessary, replace the oil pump assembly.
6. REMOVE DRIVE AND DRIVE ROTORS
Page 2461 of 3115

B00960
Seal Width
2 - 3 mmA
B
A
B
LU08V-03
P21388
New O-Ring
Engage
B00950
A
B C
DE
AAA
- LUBRICATIONOIL PUMP
LU-15
1796 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL OIL PUMP
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the oil pump
and cylinder block.
Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket sur-
faces and sealing groove.
Thoroughly clean all components to remove all the
loose material.
Using a non-residue solvent, clean both sealing
surfaces.
(b) Apply seal packing to the oil pump as shown in the illustra-
tion.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
Avoid applying an excessive amount to the surface. Be par-
ticularly careful near oil passage.
Install a nozzle that has been cut to a 2 - 3 mm (0.08
- 0.12 in.) opening.
Parts must be assembled within 5 minutes of ap-
plication. Otherwise the material must be removed
and reapplied.
Immediately remove nozzle from the tube and rein-
stall cap.
(c) Install a new O-ring to the cylinder block.
(d) Engage the spline teeth of the oil pump drive gear with the
large teeth of the crankshaft, and slide the oil pump on the
crankshaft.
(e) Install the oil pump with the 8 bolts. Uniformly tighten the
bolts in several passes.
Torque:
15.5 N´m (160 kgf´cm, 11 ft´lbf)
for 12 mm head and 6 mm hexagon head
30.5 N´m (310 kgf´cm, 22 ft´lbf) for 14 mm head
HINT:
Use a 6 mm hexagon wrench for the hexagon head bolt.
Each bolt length is indicated in the illustration.
Page 2462 of 3115

B03739
B04488
A
B
Seal Width
2 - 3 mm A
B LU-16
- LUBRICATIONOIL PUMP
1797 Author: Date:
2004 LAND CRUISER (RM1071U)
Bolt length:
35 mm (1.38 in.) for A of 12 mm head
50 mm (1.97 in.) for B of 12 mm head
106 mm (4.17 in.) for C of 12 mm head
40 mm (1.57 in.) for D of 14 mm head
30 mm (1.18 in.) for E of 6 mm hexagon head
2. INSTALL OIL STRAINER
Install a new gasket and the oil strainer with the 2 bolts and 2
nuts.
Torque: 7.5 N´m (80 kgf´cm, 66 in.´lbf)
HINT:
Use bolt 12 mm (0.47 in.) in length.
3. INSTALL NO.1 OIL PAN
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the No.1 oil
pan, cylinder block, oil pump and rear oil seal retainer.
Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket sur-
faces and sealing groove.
Thoroughly clean all components to remove all the
loose material.
Using a non-residue solvent, clean both sealing
surfaces.
(b) Apply seal packing to the No.1 oil pan as shown in the il-
lustration.
Seal packing: Part No. 08826-00080 or equivalent
Install a nozzle that has been cut to a 2 - 3 mm (0.08
- 0.12 in.) opening.
Parts must be assembled within 5 minutes of ap-
plication. Otherwise the material must be removed
and reapplied.
Immediately remove nozzle from the tube and rein-
stall cap.
Page 2463 of 3115

B04459
A
B
A
A
A
D
BBBC
BBBB
C
CC
D
B03737
B04489
A
B
Seal Width
2 - 3 mm A
B
- LUBRICATIONOIL PUMP
LU-17
1798 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Temporarily install the No.1 oil pan with the 19 bolts, stud
bolt and 2 nuts.
HINT:
Each bolt length is indicated in the illustration.
Bolt length:
20 mm (0.79 in.) for A of 10 mm head
25 mm (0.98 in.) for B of 12 mm head
60 mm (2.36 in.) for C of 12 mm head
35 mm (1.38 in.) for D of 10 mm head
(d) Set the No.1 oil pan as shown in the illustration.
NOTICE:
Make sure the clearance between the rear ends of the No.1
oil pan and cylinder block is 0.2 mm (0.008 in.) or less. If the
clearance is more than 0.2 mm (0.008 in.), the No.1 oil pan
will be stretched.
(e) Uniformly tighten the bolts, and nuts in several passes.
Torque:
7.5 N´m (80 kgf´cm, 66 in.´lbf) for 10 mm head
28 N´m (290 kgf´cm, 21 ft´lbf) for 12 mm head
4. INSTALL OIL PAN BAFFLE PLATE
Install the baffle plate with the 4 bolts and 2 nuts.
Torque: 7.5 N´m (80 kgf´cm, 66 in.´lbf)
HINT:
Use bolts 12 mm (0.55 in.) in length.
5. INSTALL NO.2 OIL PAN
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the No.1 and
No.2 oil pans.
Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket sur-
faces and sealing groove.
Thoroughly clean all components to remove all the
loose material.
Using a non-residue solvent, clean both sealing
surfaces.
NOTICE:
Do not use a solvent which will affect the painted surfaces.
(b) Apply seal packing to the No.2 oil pan as shown in the il-
lustration.
Seal packing: Part No. 08826-00080 or equivalent
Install a nozzle that has been cut to a 3 - 4 mm (0.12
- 0.16 in.) opening.
Page 2464 of 3115

B04486
Push New O-Ring
LU-18
- LUBRICATIONOIL PUMP
1799 Author: Date:
2004 LAND CRUISER (RM1071U)
Parts must be assembled within 5 minutes of ap-
plication. Otherwise the material must be removed
and reapplied.
Immediately remove nozzle from the tube and rein-
stall cap.
(c) Install the No.2 oil pan with the 20 bolts and 2 nuts. Uni-
formly tighten the bolts and nuts in several passes.
Torque: 7.5 N´m (80 kgf´cm, 66 in.´lbf)
HINT:
Use bolts 14 mm (0.55 in.) in length.
6. INSTALL CRANKSHAFT POSITION SENSOR
(See page IG-13)
7. INSTALL OIL FILTER, OIL COOLER AND FILTER
BRACKET ASSEMBLY
(a) Install the a new gasket to the oil filter bracket.
(b) Install the oil filter, oil cooler and filter bracket assembly
with the 2 bolts and nut.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(c) Connect the oil pressure switch connector.
8. INSTALL OIL DIPSTICK GUIDE AND DIPSTICK
(a) Install a new O-ring to the dipstick guide.
(b) Apply soapy water to the O-ring.
(c) Push in the dipstick guide end into the guide hole of the
No.1 oil pan.
(d) Install the dipstick guide with the bolt.
Torque: 15 N´m, (155 kgf´cm, 11 ft´lbf)
(e) Install the dipstick.
9. INSTALL CRANKSHAFT TIMING PULLEY
(See page EM-22)
10. INSTALL NO.1 IDLER PULLEY (See page EM-22)
11. INSTALL NO.2 IDLER PULLEY (See page EM-22)
12. INSTALL TIMING BELT (See page EM-22)
13. DISCONNECT ENGINE FROM ENGINE STAND
14. INSTALL ENGINE TO VEHICLE (See page EM-81)
