Page 1521 of 3115

AB0118H01023
H01075
H10600H16855H17091
P Squib
Airbag
Sensor
Assembly
P+
P-
DLC3
ON " u
DTC B0107/51
TC CG
Dash Wire
DI-740
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
933 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect P+ and P- of the dash wire
connector on the front passenger airbag assembly (P
squib) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0107/51 is not output.
HINT:
Codes other than code B0107/51 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1522 of 3115

AB0119H01024
H01075 H10600H10616
"u
ON
DTC B0107/51
DLC3Airbag
Sensor
Assembly P Squib
TC CG
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-741
934 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check P squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the front passenger airbag assembly (P squib)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0107/51 is not output.
HINT:
Codes other than code B0107/51 may be output at this time, but
they are not relevant to this check.
NG Replace front passenger airbag assembly
(P squib).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1523 of 3115

H01022AB0119H16857H17092
P SquibAirbag
Sensor
Assembly
(-)
(+)P+
ONDash Wire
DI-742
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
935 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B0108/52 Short in P Squib Circuit (to B+)
CIRCUIT DESCRIPTION
The P squib circuit consists of the airbag sensor assembly and the front passenger airbag assembly.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0108/52 is recorded when a B+ short is detected in the P squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0108/52
Short in P squib circuit (to B+)
P squib malfunction
Airbag sensor assembly malfunctionFront passenger airbag assembly (P squib)
Airbag sensor assembly
Dash wire
WIRING DIAGRAM
See page DI-732.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check dash wire (P squib circuit).
PREPARATION:
Connect the negative (-) terminal cable to the battery, and wait
at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the body ground and P+ of
the dash wire connector on the front passenger airbag as-
sembly (P squib) side.
OK:
Voltage: Below 1 V
NG Repair or replace dash wire.
OK
DI6PA-13
Page 1524 of 3115

AB0118H01023
H01076
H10600H16855H17093
P Squib
Airbag
Sensor
Assembly
P+
P-
DTC B0108/52
DLC3
ON " u
TC CG
Dash Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-743
936 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the connector to the airbag sensor assembly.
(d) Using a service wire, connect P+ and P- of the dash wire
connector on the front passenger airbag assembly (P
squib) side.
(e) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0108/52 is not output.
HINT:
Codes other than code B0108/52 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1525 of 3115

AB0119H01024
H01076
H10600H10618
"u
ON
DTC B0108/52
DLC3Airbag
Sensor
Assembly P Squib
TC CG
DI-744
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
937 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check P squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the front passenger airbag assembly (P squib)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0108/52 is not output.
HINT:
Codes other than code B0108/52 may be output at this time, but
they are not relevant to this check.
NG Replace front passenger airbag assembly
(P squib).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1526 of 3115
H01454
S19
Side Squib RHAirbag Sensor Assembly
SFR+
SFR- Y-R
Y-G 1
26 5
C27
C27 (*1)
(*1)
*1: w/ Side Airbag
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-745
938 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B0110/43 Short in Side Squib RH Circuit
CIRCUIT DESCRIPTION
The side squib RH circuit consists of the airbag sensor assembly and the side airbag assembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0110/43 is recorded when a short is detected in the side squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0110/43
Short in side squib RH circuit
Side squib RH malfunction
Airbag sensor assembly malfunctionSide airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B0110/43 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
DI6PB-33
Page 1527 of 3115
H01019H16275H16616
Side Squib RHAirbag
Sensor
Assembly
SFR+
(-) (+)SFR-
Floor No. 2 Wire
DI-746
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
939 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (side squib RH circuit).
PREPARATION:
Release the airbag activation prevention mechanism built in the
connector of the floor No. 2 wire on the airbag sensor assembly
side (See page DI-692).
CHECK:
Measure the resistance between SFR+ and SFR- of the floor
No. 2 wire connector on the side airbag assembly RH (side
squib RH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 2 wire.
OK
Page 1528 of 3115
H10600 H01020
H01069 AB0119H11017
Side Squib RHAirbag
Sensor
Assembly
DTC B0110/43
" u
ON
DLC3
TC CG
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-747
940 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
