Page 2761 of 4592

TOYOTA CAMRY 1999 Service Repair Manual S06042 MAHLE Made RH Piston 41.2 mm LH Piston P12504 P12583 105 mm EM7639 EM±96 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK 1382 Author: Date: (b) MAHLE made: (1) Using a micrometer, measure the p

Page 2762 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12506 Z04012 Z04011 EM6525 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK EM±97 1383 Author: Date: If the end gap is greater than maximum, replace the piston ring. If the end gap is greater than max

Page 2763 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM0227 EM6347 P12406 P12493 EM±98 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK 1384 Author: Date: (b) Using a micrometer, measure the piston pin diameter. Piston pin diameter: 21.997 ± 22.006 mm (

Page 2764 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM0YT±01 EM6363 SST EM6364 Oil Hole EM6535 P00326 P12589 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK EM±99 1385 Author: Date: REPLACEMENT 1. REPLACE CONNECTING ROD BUSHING (a) Using SST and a pre

Page 2765 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12570 SST P12808 Cut Position P12810 SST EM±100 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK 1386 Author: Date: (2) Using SST and a hammer, tap in a new oil seal until its surface is flush with th

Page 2766 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM053±04 A05260 P12417 60°C S06044 Front Mark AISIN Made RH Piston LH Piston(2 Cavities) Front Mark (Mold Mark) Front Mark (1 Cavity) Front Mark (Mold Mark) ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BL

Page 2767 of 4592

TOYOTA CAMRY 1999 Service Repair Manual S06043 Front Mark MAHLE Made RH Piston LH Piston(1 Cavity) Front Mark (Mold Mark) Front Mark (1 Cavity) Front Mark (Mold Mark) Z09179 Code Mark Code Mark No.1 No.2 S06058 RH Piston Lower Side Rail No.

Page 2768 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12402 Z09177 No.1 and No.4 No.2 and No.3 Upper Lower 22.4 mm 19.0 mm P12599 A05263 Mark 1, 2, 3 or 4 P12600 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK EM±103 1389 Author: Date: 3. INSTALL CONNEC
