Page 3089 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0H9±01 PP±64 ± PREPARATIONMANUAL TRANSAXLE (E153) 11 6 Author: Date: EQUIPMENT Dial indicator with magnetic base Feeler gauge Micrometer Torque wrench Precision straight edge Magnetic finger

Page 3090 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0HA±01 ± PREPARATIONMANUAL TRANSAXLE (E153) PP±65 11 7 Author: Date: LUBRICANT ItemCapacityClassification Manual transaxle oil (w/ Differential oil)4.2 liters (4.4 US qts, 3.7 Imp. qts)API GL±

Page 3091 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0H2±04 PP±66 ± PREPARATIONMANUAL TRANSAXLE (S51) 11 8 Author: Date: MANUAL TRANSAXLE (S51) SST (Special Service Tools) 09308±00010Oil Seal PullerInput shaft front bearing Output shaft front be

Page 3092 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± PREPARATIONMANUAL TRANSAXLE (S51) PP±67 11 9 Author: Date: 09608±00081Differential Side Bearing Cone ReplacerInput shaft front oil seal 09612±22011Tilt Handle Bearing ReplacerOutput shaft rear

Page 3093 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0H3±01 PP±68 ± PREPARATIONMANUAL TRANSAXLE (S51) 120 Author: Date: RECOMMENDED TOOLS 09025±00010Torque Wrench (30 kgf±cm)Differential preload 09031±00030Pin Punch . 09040±00010Hexagon Wren

Page 3094 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0H4±01 ± PREPARATIONMANUAL TRANSAXLE (S51) PP±69 121 Author: Date: EQUIPMENT Dial indicator Torque wrench Feeler gauge Magnetic finger Micrometer

Page 3095 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0H5±01 PP±70 ± PREPARATIONMANUAL TRANSAXLE (S51) 122 Author: Date: LUBRICANT ItemCapacityClassification Manual transaxle oil (w/ Differential oil)2.6 liters (2.7 US qts, 2.3 lmp. qts)API GL±4

Page 3096 of 4592

TOYOTA CAMRY 1999 Service Repair Manual PP0KG±01 ± PREPARATIONAUTOMATIC TRANSAXLE (A140E) PP±71 123 Author: Date: AUTOMATIC TRANSAXLE (A140E) SST (Special Service Tools) 09308±00010Oil Seal Puller 09350±32014TOYOTA Automatic Transmis
