TOYOTA CAMRY 1999 Service Repair Manual P20186
± DIAGNOSTICSENGINE (1MZ±FE)
DI±205
440 Author: Date:
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Connect the TOYOTA hand±held tester to the DLC3.

Page 1418 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P23917
DI±206
± DIAGNOSTICSENGINE (1MZ±FE)
441 Author: Date:
8 Check for spark.
PREPARATION:
(a) Remove the ignition coil or disconnect the high±tension
cord from the spark plug.
(b) Remove the

Page 1419 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± DIAGNOSTICSENGINE (1MZ±FE)
DI±207
442 Author: Date:
7. ENGINE OPERATING CONDITION
NOTICE:
The values given below for ºNormal Conditionº are representative values, so a vehicle may still be
no

Page 1420 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±208
± DIAGNOSTICSENGINE (1MZ±FE)
443 Author: Date:
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*1
O2S B1, S1Voltage Output of Oxygen Sensor
Bank 1 Sensor 1Idling: 0.1 ~ 0

Page 1421 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± DIAGNOSTICSENGINE (1MZ±FE)
DI±209
444 Author: Date:
(b) TOYOTA Enhanced Signals.
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire rangeM

Page 1422 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±210
± DIAGNOSTICSENGINE (1MZ±FE)
445 Author: Date:
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*1
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of b

Page 1423 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI07B±07
± DIAGNOSTICSENGINE (1MZ±FE)
DI±211
446 Author: Date:
DIAGNOSTIC TROUBLE CODE CHART
1. SAE CONTROLLED
HINT:
Parameters listed in the chart may not be exactly the same as your reading du

DI07B±07
± DIAGNOSTICSENGINE (1MZ±FE)
DI±211
446 Author: Date:
DIAGNOSTIC TROUBLE CODE CHART
1. SAE CONTROLLED
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, check the circuit for that code listed
in the table below. For details of each code, turn to the page referred to under the ''See page '' for the respec-
tive ''DTC No.'' in the DTC chart.
DTC No.
(See Page)Detection ItemTrouble AreaMIL*1Memory
P0100
(DI±222)Mass Air Flow Circuit
MalfunctionOpen or short in mass air flow meter circuit
Mass air flow meter
ECM

P0101
(DI±227)Mass Air Flow Circuit
Range/Performance
Problem
Mass air flow meter
P0110
(DI±228)Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
Intake air temp. sensor (built into mass air flow meter)
ECM

P0115
(DI±233)Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
Engine coolant temp. sensor
ECM

P0116
(DI±237)Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
Cooling system
P0120
(DI±239)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
MalfunctionOpen or short in throttle position sensor circuit
Throttle position sensor
ECM

P0121
(DI±243)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
Range/Performance Problem
Throttle position sensor
*2
P0125
(DI±244)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Except California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in heated oxygen sensor circuit
(bank 1, 2 sensor 1)
Heated oxygen sensor (bank 1, 2 sensor 1)
ECM

*3
P0125
(DI±249)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Only for California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in A/F sensor circuit (bank 1, 2 sensor 1)
A/F sensor (bank 1, 2 sensor 1)
ECM

*2
P0130
(DI±255)Heated Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
*1: MIL lights up
*
2: Except California specification vehicles
*
3: Only for California specification vehicle

Page 1424 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±212
± DIAGNOSTICSENGINE (1MZ±FE)
447 Author: Date:
DTC No.
(See Page)Detection ItemTrouble AreaMILMemory
*2
P0133
(DI±259)
Heated Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)Heated

DI±212
± DIAGNOSTICSENGINE (1MZ±FE)
447 Author: Date:
DTC No.
(See Page)Detection ItemTrouble AreaMILMemory
*2
P0133
(DI±259)
Heated Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
*2
P0135
(DI±263)
Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 1)Open or short in heater circuit of heated oxygen sensor
Heated oxygen sensor heater
ECM

P0136
(DI±265)Heated Oxygen Sensor Circuit
Malfunction
(Bank 1 Sensor 2)
Heated oxygen sensor
P0141
(DI±263)Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 2)
Same as DTC No. P0135*1
*3
P0150
(DI±255)
Heated Oxygen Sensor
Circuit Malfunction
(Bank 2 Sensor 1)
Same as DTC No. P0130*1
*3
P0153
(DI±259)
Heated Oxygen Sensor
Circuit Slow Response
(Bank 2 Sensor 1)Same as DTC No. P0133
Fuel trim malfunction*1
*3
P0155
(DI±263)Heated Oxygen Sensor
Circuit Malfunction
(Bank 2 Sensor 1)
Same as DTC No. P0135*1
*3
P0171
(DI±272)System too Lean
(Fuel Trim)
(Except California Spec.)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Heated oxygen sensor (bank 1, 2 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor
Gas leakage on exhaust system
*1
*3
P0172
(DI±272)System too Rich
(Fuel Trim)
(Except California Spec.)
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor (bank 1, 2 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor
Gas leakage on exhaust system
*1
*4
P0171
(DI±267)System too Lean
(Fuel Trim)
(Only for California Spec.)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Mass air flow meter
Engine coolant temp. sensor
A/F sensor (bank 1, 2 sensor 1)
Gas leakage on exhaust system
*1
*4
P0172
(DI±267)System too rich
(Fuel Trim)
(Only for California Spec.)
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor malfunction
Mass air flow meter
Engine coolant temp. sensor
A/F sensor (bank 1, 2 sensor 1)
Gas leakage on exhaust system
*1
*1: MIL lights up
*2: MIL light up or blinking
*3: Except California specification vehicles
*4: Only for California specification vehicle
