Page 3817 of 4592

TOYOTA CAMRY 1999 Service Repair Manual M.I.L. ªONº P0440, P0441 & P0446 ± EG013-02July 12, 2002
Page 4 of 5
8. Using a DVOM test at Pin 2 to a known good ground. The ECM provides ground
when the VSV is switched ON. (White and red wire

Page 3818 of 4592

TOYOTA CAMRY 1999 Service Repair Manual M.I.L. ªONº P0440, P0441 & P0446 ± EG013-02July 12, 2002
Page 5 of 5
5. Locate the vacuum hose going from charcoal canister to Port P of the Vapor Pressure
Sensor VSV (see Figure 4).
Vapor Pressur

Page 3819 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 2
EG013±99
Title:
SINGLE CYLINDER MISFIRES
Models:
99 Avalon, Camry, Sienna & Solara
Technical Service
BULLETIN
December 17, 1999

Some 1999 Avalon, Camr

Page 3820 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Production
Date
Part Number
SINGLE CYLINDER MISFIRE ± EG013±99 December 17, 1999
Page 2 of 2
1. Remove all six fuel injectors for
verification of production information.
Affected injectors will be l

Page 3821 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
EG009±99
Title:
M.I.L. ON" DTC P1133
Models:
97±99 Camry and 99 Solara: 5S±FE CA Spec.
Technical Service
BULLETIN
October 1, 1999

Under certain d

Toyota Supports ASE CertificationPage 1 of 1
EG009±99
Title:
M.I.L. ON" DTC P1133
Models:
'97±'99 Camry and '99 Solara: 5S±FE CA Spec.
Technical Service
BULLETIN
October 1, 1999

Under certain driving conditions, some 5S±FE equipped 1997±1999 Camry and 1999
Solara California emission specification vehicles may exhibit a M.I.L. ªONº DTC P1133.
An improved Air Fuel Ratio Sensor has been developed to correct this condition.
1997 ± 1999 Camry & 1999 Solara (5S±FE) with California emission
specification.
MODEL YEARORIGINENGINESTARTING VIN
JPNJT2BG2#K*X0363615
1999 Camry
NAP(5S±FE)4T1BG2#K*XU603913
4T1BG2#K*XU918675
2000 Solara±±
* # May be a 2 or an 8.
* * May be any number from 0 to 9 or an X.
PREVIOUS PART NUMERCURRENT PART NUMBERPART NAME
89467±3301089467±33011Sensor, Air Fuel
Should a M.I.L. ªONº condition with DTC P1133 be encountered, perform diagnostic
procedures as described in the Repair Manual.
If the problem source cannot be identified after checking all affected areas according
to the Repair Manual, the cause may be an Air/Fuel Ratio Sensor malfunction. In this
case, replace the Air/Fuel Ratio Sensor with the updated part.
If the Exhaust Manifold threads are damaged by removal of the sensor, they can be
repaired by the proper use of a M18 x 1.5 tap.
OPCODEDESCRIPTIONTIMEOPNT1T2
EL9006Sensor, Air Fuel Ratio0.389467±330109999
Applicable Warranty*:
This repair is covered under the Toyota Basic Warranty. This warranty is in effect for
36 months or 36,000 miles, whichever occurs first, from the vehicle's in±service date.
Coverage is extended to 36 months or 50,000 miles, which ever occurs first, in the
states of California and Massachusetts due to state emissions warranty legislation.
NOTE:
Please enter the DTC in the condition/Cause/Remedy section when applying for
warranty reimbursement.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
ENGINE
Introduction
Applicable
Vehicles
Production
Change
Information
Parts
Information
Repair
Procedure
Warranty
Information

Page 3822 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 2
EL002±98Title:
CIGARETTE LIGHTER SERVICE
Models:
All Models
Technical Service
BULLETIN
Apirl 10, 1998

When receiving customer complaints to repair the

Page 3823 of 4592

TOYOTA CAMRY 1999 Service Repair Manual CIGARETTE LIGHTER SERVICE ± EL002-98 April 10, 1998
Page 2 of 2
2. If the lighter element is original
equipment and the lighter socket is
bent or pulled out of the dash, please
ask the customer about

Page 3824 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 2
EL003±00Title:
SPEEDOMETER/TACHOMETER
NEEDLE MOVEMENT
Models:
99 ± 00 Camry, Corolla, Sienna, & Solara
& 00 Avalon
Technical Service
BULLETIN
February
