Page 2313 of 4592

TOYOTA CAMRY 1999 Service Repair Manual D02260 1 Shift Solenoid Valve SLECM Transaxle E1P8 E6SL ± DIAGNOSTICSAUTOMATIC TRANSAXLE DI±161 DTC P0773 Shift Solenoid E Electrical Malfunction (Shift Solenoid Valve SL) CIRCUIT DESCRIPTION The sh

Page 2314 of 4592

TOYOTA CAMRY 1999 Service Repair Manual D05155 SL D05154 SL SL 1 2 DI±162 ± DIAGNOSTICSAUTOMATIC TRANSAXLE INSPECTION PROCEDURE 1 Measure resistance between terminal SL of ECM and body ground. PREPARATION: Disconnect the connector from E

Page 2315 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q07749 ± DIAGNOSTICSAUTOMATIC TRANSAXLE DI±163 3 Check shift solenoid valve SL. PREPARATION: (a) Jack up the vehicle. (b) Remove the oil pan. (c) Disconnect the shift solenoid valve SL connector. (d

Page 2316 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±164 ± DIAGNOSTICSAUTOMATIC TRANSAXLE DTC P1520 Stop Light Switch Signal Malfunction CIRCUIT DESCRIPTION The purpose of this circuit is to prevent the engine from stalling, while driving in lock±

Page 2317 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± DIAGNOSTICSAUTOMATIC TRANSAXLE DI±165 DTC P1780 Park/Neutral Position Switch Malfunction CIRCUIT DESCRIPTION The park/neutral position switch detects the shift lever position and sends signals to

Page 2318 of 4592

TOYOTA CAMRY 1999 Service Repair Manual D06504 Combination Meter R C10 2 L8 11 6 C10 C10R±B 13 O Y16IF1 IF1L±W YInstrument Panel J/BECM 1H 1V10 5 19 18 17 6 E4 E4 E4 E7R2 L B + NSW Y L±W R±B A J23J27 J24 CC R±B Park/Neutral Position Sw

Page 2319 of 4592

TOYOTA CAMRY 1999 Service Repair Manual D06387 (+)NSW (±)2R L Position P, N R D 2 LNSW±Body groundR±Body ground2±Body groundL±Body ground 0 V 0 V0 V0 V 0 V 0 V 0 V 0 V 0 V 0 V 0 V 0 V 0 V 9 ± 14 V* 9 ± 14 V 9 ± 14 V 9 ± 14 V 9 ±

Page 2320 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q07657 DI±168 ± DIAGNOSTICSAUTOMATIC TRANSAXLE 2 Check park/neutral position switch. PREPARATION: (a) Jack up the vehicle. (b) Remove the park/neutral position switch. CHECK: Check continuity betwee
