Page 3921 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 4 of 10 2. Using the Midtronics Update Wizard (MUW). A. Click on the latest version of production software. (Figure 3.) This wil

Page 3922 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 5 of 10 C. Enter the serial number of the battery tester then click ªOK.º (Figure 4.) FIGURE 4. C Operation Procedure (Continu

Page 3923 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 6 of 10 D. Connect the Midtronics Battery Tester to TIS as instructed (Figure 5), then click ªNext.º NOTE: Connecting the Mi

Page 3924 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 7 of 10 E. Follow the instructions to put the Midtronics Battery Tester into the correct mode (Figure 6), then click ªNext.º F

Page 3925 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 8 of 10 F. Confirm the software version and click ªNext.º (Figure 7.) FIGURE 7. F Figures 7±1 and 7±2 are confirmation dialo

Page 3926 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 9 of 10 G. The Midtronics Update Wizard (MUW) will now update the Midtronics Battery Tester software. (Figure 8.) NOTE: Do not i

Page 3927 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MIDTRONICS BATTERY TESTER SOFTWARE UPDATE ± SS002-02June 7, 2002 Page 10 of 10 H. Upon successful completion, the Update Results screen will display ªNo errorsº and the update is now complete. Cl

Page 3928 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1 SS003±98Title: RIVET NUT TOOL Models: All Models Technical Service BULLETIN December 11, 1998 Toyota Motor Sales is making available a tool suitable fo
