TOYOTA CAMRY 1999 Service Repair Manual POWER OUTLET 15A POWER± OUTLET FROM POWER SOURCE SYSTEM ( SEE PAGE 44) 1J 5 1V 4 1V 3 ID 1 2 POWER OUTLET P 4 V W±B W±B

Page 4138 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P4 POWER OUTLET 2±GROUND : Approx. 12 volts with the ignition SW at ACC or ON position 1±GROUND : Always continuity : PARTS LOCATION CodeSee PageCodeSee PageCodeSee Page P431 ������ ���: JUNCTION

Page 4139 of 4592

TOYOTA CAMRY 1999 Service Repair Manual REMOTE CONTROL MIRROR 1T 1 ID1 16 ID114 ID115 IL116 IL114 IL115 IE 58 17 6 10A A 9 A A MM MM15A CIG OPERATION SW SELECT SW JUNCTION CONNECTOR JUNCTION CONNECTOR REMOTE CONTROL MIRROR SW P±L P±L BR±

Page 4140 of 4592

TOYOTA CAMRY 1999 Service Repair Manual R5 REMOTE CONTROL MIRROR SW 9±GROUND : Approx. 12 volts with the ignition SW at ACC or ON position 6±10 : Continuity with the operation SW at UP or LEFT position 9±6 : Continuity with the operatio

Page 4141 of 4592

TOYOTA CAMRY 1999 Service Repair Manual REAR WINDOW DEFOGGER AND MIRROR HEATER 1R 31J13 ID II 1V 31G 7A A 10A HEATER40A DEF DEFOGGER RELAY JUNCTION CONNECTOR FROM POWER SOURCE SYSTEM ( SEE PAGE 44) W±B W± BB W±B 13 25 IB1 8 2 IFID1 20 IL

Page 4142 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DEFOGGER RELAY 5±3 : Closed with the ignition SW at ON or ST position and the rear window defogger SW on R4 REAR WINDOW DEFOGGER SW 4±GROUND : Approx. 12 volts with the ignition SW at ON or ST posi

Page 4143 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RADIO AND PLAYER 2K 11 1H3 1G 61W 5 A 4A3 B 3 B 1 A 6 A 2 A 7A1A5B2B6 ID1 9ID11IL19IL11IC19IC13IC110 IC14 111 1222 2 IG L±Y L±Y L±Y GR BR P V LG L B Y R W WRY BL LGV P BR 20A RADIO NO. 17. 5A RAD±

Page 4144 of 4592

TOYOTA CAMRY 1999 Service Repair Manual R3 (A) RADIO AND PLAYER (A) 4±GROUND : Always approx. 12 volts (A) 3±GROUND : Approx. 12 volts with the ignition SW at ACC or ON position (A) 7±GROUND : Always continuity : PARTS LOCATION CodeSee
