Page 4009 of 4592

TOYOTA CAMRY 1999 Service Repair Manual REPAIR MANUAL CORRECTIONS INDEX ± PG003-04May 18, 2004
Page 5 of 5
Publication Number Page(s) Part Number
2002 Tacoma RM921±U2 BE±40 00400±RM921±3084B. . . . . . . . . . . . . . . . . . . . . .

REPAIR MANUAL CORRECTIONS INDEX ± PG003-04May 18, 2004
Page 5 of 5
Publication Number Page(s) Part Number
2002 Tacoma RM921±U2 BE±40 00400±RM921±3084B. . . . . . . . . . . . . . . . . . . . . . . . .
RM921±U1 DI±323 00400±RM921±3218 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2003 Tacoma RM1002±U2 BE±40 00400±RM100±3085B. . . . . . . . . . . . . . . . . . . . . . . .
2002 Tundra RM885±U2 BE±52 to BE±56 00400±RM885±3105B. . . . . . . . . . . . . . . . .
2003 Tundra EWD491±U 139, 240, 00400±EWD49±12136. . . . . . . . . . . . . . . . . . . . . . .
Overall M:30O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31, 33, 235, 261, 00400±EWD49±2216 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overall M:29O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
176, Overall M:18±5 00400±EWD49±3210 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RM956±U1 SS±79 00400±RM956±3258 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DI±115, DI±117, 00400±RM956±3282 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DI±316, DI±318O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RM956±U2 BE±57 to BE±60 00400±RM956±3106B . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2004 Tundra EWD567±U 230, 446, 00400±EWD56±3209. . . . . . . . . . . . . . . . . . . . . . . .
Overall M:19±5, M:49±4O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21, 94, 210, 515 00400±EWD56±3298 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tacoma
Tundra

Page 4010 of 4592

TOYOTA CAMRY 1999 Service Repair Manual NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and

Page 4011 of 4592

TOYOTA CAMRY 1999 Service Repair Manual A INTRODUCTION
This manual consists of the following 13 sections:
No.
SectionDescription
A
INDEXIndex of the contents of this manual.
A
INTRODUCTIONBrief explanation of each section.
BHOW TO USE THIS

Page 4012 of 4592

TOYOTA CAMRY 1999 Service Repair Manual HOW TO USE THIS MANUAL B
This manual provides information on the electrical circuits installed on vehicles by
dividing them into a circuit for each system.
The actual wiring of each system circuit is

Page 4013 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ��
@@@@ @
@@@ @@@@ @@@@ @@@@ @@@@ @@@@
€€€€ €
€€€ €€€€ €€€€ €€€€ €€€€ €€€€
ÀÀÀÀ À
ÀÀÀ ÀÀÀÀ ÀÀÀÀ

Page 4014 of 4592

TOYOTA CAMRY 1999 Service Repair Manual B
[A]: System Title
[B]: Indicates a Relay Block. No shading is used and
only the Relay Block No. is shown to distinguish it
from the J/B
Example: Indicates Relay Block No.1
[C]: ( ) is use

B
[A]: System Title
[B]: Indicates a Relay Block. No shading is used and
only the Relay Block No. is shown to distinguish it
from the J/B
Example: Indicates Relay Block No.1
[C]: ( ) is used to indicate different wiring and
connector, etc. when the vehicle model, engine
type, or specification is different.
[D]: Indicates related system.
[E]: Indicates the wiring harness and wiring harness
connector. The wiring harness with male terminal is
shown with arrows (
).
Outside numerals are pin numbers.
Female Male ( )
The first letter of the code for each wiring harness
and wiring harness connector(s) indicates the
component's location, e.g, ºEº for the Engine
Compartment, ºIº for the Instrument Panel and
Surrounding area, and ºBº for the Body and
Surrounding area.
When more than one code has the first and second
letters in common, followed by numbers (e.g, IH1,
IH2), this indicates the same type of wiring harness
and wiring harness connector.
[F]: Represents a part (all parts are shown in sky blue).
The code is the same as the code used in parts
position.
[G]: Junction Block (The number in the circle is the J/B
No. and the connector code is shown beside it).
Junction Blocks are shaded to clearly separate
them from other parts.
3C indicates
that it is inside
Junction Block
No.3 Example:

[H]: When 2 parts both use one connector in common,
the parts connector name used in the wire routing
section is shown in square brackets [ ].[I]: Indicates the wiring color.
Wire colors are indicated by an alphabetical code.
B = Black W = White BR = Brown
L = Blue V = Violet SB = Sky Blue
R = Red G = Green LG = Light Green
P = Pink Y = Yellow GR = Gray
O = Orange
The first letter indicates the basic wire color and the
second letter indicates the color of the stripe.
Example: L ± Y
L
(Blue)Y
(Yellow)
[J]: Indicates a wiring Splice Point (Codes are ºEº for the
Engine Room, ºIº for the Instrument Panel, and ºBº
for the Body).
The Location of splice Point I 5 is indicated by the
shaded section.
[K]: Indicates a shielded cable.
[L]: Indicates the pin number of the connector.
The numbering system is different for female and
male connectors.
Example:
Numbered in order
from upper left to
lower rightNumbered in order
from upper right to
lower left
Female
Male
[M]: Indicates a ground point.
The first letter of the code for each ground point(s)
indicates the component's location, e.g, ºEº for the
Engine Compartment, ºIº for the Instrument Panel
and Surrounding area, and ºBº for the Body and
Surrounding area.
[N]: Page No.

Page 4015 of 4592

TOYOTA CAMRY 1999 Service Repair Manual [O]
[P]
[Q]
[R]
[S]
[T]
[U]
[V]
B HOW TO USE THIS MANUAL
Current is applied at all times through the STOP fuse to TERMINAL 2 of the stop light SW.
When the ignition SW is turned on, current flows fro

[O]
[P]
[Q]
[R]
[S]
[T]
[U]
[V]
B HOW TO USE THIS MANUAL
Current is applied at all times through the STOP fuse to TERMINAL 2 of the stop light SW.
When the ignition SW is turned on, current flows from the GAUGE fuse to TERMINAL 8 of the light failure sensor, and also flows
through the rear lights warning light to TERMINAL 4 of the light failure sensor.
STOP LIGHT DISCONNECTION WARNING
When the ignition SW is turned on and the brake pedal is pressed (Stop light SW on), if the stop light circuit is open, the current
flowing from TERMINAL 7 of the light failure sensor to TERMINALS 1, 2 changes, so the light failure sensor detects the
disconnection and the warning circuit of the light failure sensor is activated.
As a result, the current flows from TERMINAL 4 of the light failure sensor to TERMINAL 11 to GROUND and turns the rear lights
warning light on. By pressing the brake pedal, the current flowing to TERMINAL 8 of the light failure sensor keeps the warning
circuit on and holds the warning light on until the ignition SW is turned off.
S6 STOP LIGHT SW
2±1 : Closed with the brake pedal depressed
L4 LIGHT FAILURE SENSOR
1, 2, 7±GROUND : Approx. 12 volts with the stop light SW on
4, 8±GROUND : Approx. 12 volts with the ignition SW at ON position
11±GROUND : Always continuity
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
C734L436R737
H1736R637S635
: RELAY BLOCKS
CodeSee PageRelay Blocks (Relay Block Location)
118R/B No.1 (Instrument Panel Left)

@@@ @@@ @@@
€€€ €€€ €€€
ÀÀÀ ÀÀÀ ÀÀÀ
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee PageJunction Block and Wire Harness (Connector Location)
IB20Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
3C22Instrument Panel Wire and J/B No.3 (Instrument Panel Left Side)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
IE142Floor Wire and Instrument Panel Wire (Left Kick Panel)
BV150Luggage Room Wire and Floor Wire (Luggage Compartment Left)
: GROUND POINTS
CodeSee PageGround Points Location
BL50Under the Left Quarter Pillar
BO50Back Panel Center
: SPLICE POINTS
CodeSee PageWire Harness with Splice PointsCodeSee PageWire Harness with Splice Points
I544Cowl WireB1850Luggage Room Wire
SYSTEM OUTLINE
SERVICE HINTS

Page 4016 of 4592

TOYOTA CAMRY 1999 Service Repair Manual B
[O]: Explains the system outline.
[P]: Indicates values or explains the function for reference during troubleshooting.
[Q]: Indicates the reference page showing the position on the vehicle of the pa
