Page 945 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0N0±01 BO±100 ± BODYFRONT SEAT (Manual Seat for TMC Made) 2448 Author: Date: REMOVAL REMOVE FRONT SEAT (a) Using a screwdriver, remove the seat track outer cover. HINT: Tape the screwdriver tip

Page 946 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0N1±01 H01870 ± BODYFRONT SEAT (Manual Seat for TMC Made) BO±101 2449 Author: Date: DISASSEMBLY 1. REMOVE THESE PARTS: (a) Release handle (b) Front seat cushion shield (c) Vertical Seat Adjuste

Page 947 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0N2±01 BO±102 ± BODYFRONT SEAT (Manual Seat for TMC Made) 2450 Author: Date: INSPECTION INSPECT RECLINING LOCK POSITION AND SLIDING LOCK POSITION SLIPPING OFF (a) When reclining the seat, inspe

Page 948 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0N3±01 ± BODYFRONT SEAT (Manual Seat for TMC Made) BO±103 2451 Author: Date: REASSEMBLY 1. Vertical Seat Adjuster: INSTALL FRONT SEAT OUTER ADJUSTER Install front seat outer adjuster to front s

Page 949 of 4592

TOYOTA CAMRY 1999 Service Repair Manual H01870 BO±104 ± BODYFRONT SEAT (Manual Seat for TMC Made) 2452 Author: Date: (d) w/ Side Airbag Assembly: Hang the hook on to the seatback frame. CAUTION: Take care to hung the hook securely. Othe

Page 950 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0N4±01 ± BODYFRONT SEAT (Manual Seat for TMC Made) BO±105 2453 Author: Date: INSTALLATION INSTALL FRONT SEAT (a) Slide the front seat to the most front position. NOTICE: Make sure that seat adj

Page 951 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0MO±01 H01872  Hog Ring Front Seatback Cover Front Seatback Pad Headrest Headrest Support  Hog Ring Front Seatback Hinge Cover Front Seatback Frame w/ Lumber Support: Lumber Support Lever Front S

Page 952 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0MP±01 ± BODYFRONT SEAT (Manual Seat for TMMK Made) BO±107 2455 Author: Date: REMOVAL REMOVE FRONT SEAT (a) Using a screwdriver, remove the seat track covers. HINT: Tape the screwdriver tip bef
