AIR CONDITIONING AMPLIFIER
ON±VEHICLE INSPECTION
1. REMOVE GLOVE COMPARTMENT
(See page BO±75)
2. INSPECT AMPLIFIER CIRCUIT
(a) Disconnect the amplifier connector and inspect the con-
nector on wire harness side, as shown in the chart below.
Test conditions:
Ignition switch ON
Blower speed switch HI
Temperature control lever Max. Cool
Tester connectionConditionSpecified condition
5 ± GroundConstantContinuity
9 ± 13Evaporator temperature at 25°C (77°F)Approx. 1.5 kW
14 ± 13Constant65 ± 125 W at 25°C (77°F)
8 ± GroundA/C switch ONBattery positive voltage
8 ± GroundA/C switch OFFNo voltage
8 ± GroundMode switch DEF. positionBattery positive voltage
10 ± GroundA/C switch ONBelow 4.0 V
10 ± GroundA/C switch OFFNo voltage
If circuit is as specified, try replacing the amplifier with a new
one. If the circuit is not as specified, inspect the circuits con-
nected to other parts.
Page 90 of 4592

Z13473
From back side:
± AIR CONDITIONINGAIR CONDITIONING AMPLIFIER
AC±89
2571 Author: Date:
(b) Connect the connector to amplifier and inspect wire har-
ness side connector from the back side, as shown in the
chart below.
Test conditions:
Running engine at idle speed
Blower speed switch HI
A/C switch ON
Temperature control lever Max Cool
Set on manifold gauge set
Tester connectionConditionSpecified condition
1 ± GroundMagnetic clutch is not engagedBelow 1.0 V
1 ± GroundMagnetic clutch is engagedNo voltage
7 ± GroundMagnetic clutch is not engagedBelow 1.0 V
7 ± GroundMagnetic clutch is engagedBattery positive voltage
2 ± GroundRefrigerant pressure 196 ± 1,340 kPaBattery positive voltage
2 ± GroundRefrigerant pressure
less than 196 or more than 3,140 kPaNo voltage
12 ± GroundRefrigerant pressure 196 ± 1,340 kPaBelow 1.0 V
12 ± GroundRefrigerant pressure
less than 196 or more than 3,140 kPaBattery positive voltage
12 ± GroundEngine coolant temp. 83°C (181°F) or belowBattery positive voltage
12 ± GroundEngine coolant temp. 93°C (199°F) or aboveBelow 1.0 V
If circuit is as specified, try replacing the amplifier with a new
one. If the circuit is not as specified, inspect the circuits con-
nected to other parts.
Page 91 of 4592
AC0NK±02
N20285
AC±90
± AIR CONDITIONINGAIR CONDITIONING AMPLIFIER
2572 Author: Date:
REMOVAL
1. REMOVE GLOVE COMPARTMENT
(See page BO±75)
2. REMOVE A/C AMPLIFIER
(a) Disconnect the connector.
(b) Release the 2 claws and pull out the amplifier.
Page 92 of 4592
AC0NL±01
± AIR CONDITIONINGAIR CONDITIONING AMPLIFIER
AC±91
2573 Author: Date:
INSTALLATION
Installation is in the reverse order of removal (See page AC±90).
Page 93 of 4592

AC227±01
P15233
5S±FE:
ECT Switch
P19584
1MZ±FE:No. 1 ECT Switch
No. 2 ECT Switch
P01924
P01924
AC±92
± AIR CONDITIONINGENGINE COOLANT TEMPERATURE (ECT) SWITCH
2574 Author: Date:
ENGINE COOLANT
TEMPERATURE (ECT) SWITCH
INSPECTION
1. DRAIN ENGINE COOLANT FROM RADIATOR
HINT:
It is not necessary to drain out all the coolant.
2. REMOVE ECT SWITCHES
(a) Disconnect the connector.
(b) Remove the ECT switch.
3. 5S±FE engine:
INSPECT ECT SWITCH CONTINUITY
(a) Using an ohmmeter, check that no continuity exists be-
tween the terminals when the coolant temperature is
above 93°C (199°F).
If continuity exists, replace the switch.
(b) Using an ohmmeter, check that continuity exists between
the terminals when the coolant temperature is below
83°C (181°F).
If no continuity exists, replace the switch.
4. 1MZ±FE engine:
INSPECT No. 1 SWITCH CONTINUITY
(a) Using an ohmmeter, check that no continuity exists be-
tween the terminals when the coolant temperature is
above 98°C (208°F).
If continuity exists, replace the switch.
(b) Using an ohmmeter, check that continuity exists between
the terminals when the coolant temperature is below
88°C (190°F).
If no continuity exists, replace the switch.
Page 94 of 4592
P06722
P15233
5S± FE:
ECT Switch
P19584
1MZ±FE:
No. 1 ECT Switch
No. 2 ECT Switch
± AIR CONDITIONINGENGINE COOLANT TEMPERATURE (ECT) SWITCH
AC±93
2575 Author: Date:
5. 1MZ±FE engine:
INSPECT No. 2 SWITCH CONTINUITY
(a) Using an ohmmeter, check that no continuity exists be-
tween the terminal and switch body when the coolant
temperature is above 93°C (199°F).
If continuity exists, replace the switch.
(b) Using an ohmmeter, check that continuity exists between
the terminals when the coolant temperature is below
83°C (181°F).
If no continuity exists, replace the switch.
6. INSTALL ECT SWITCHES
(a) Install the ECT switch.
HINT:
Lubricate a new O±ring with soapy water and install the switch.
(b) Connect the connector.
Page 95 of 4592
AX034±01
± AUTOMATIC TRANSAXLE (A140E)AUTOMATIC TRANSAXLE SYSTEM
AX±1
1894 Author: Date:
AUTOMATIC TRANSAXLE SYSTEM
PRECAUTION
If the vehicle is equipped with a mobile communication system, refer to the precautions in the IN section.
