Page 4361 of 4592

TOYOTA CAMRY 1999 Service Repair Manual TAILLIGHT
12X 4 3
X89X11X
13
X5X
34 13
X5X
34 GRAY
L3 R8 R9 R10 R11 L2

Page 4362 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MEMO

Page 4363 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BACK±UP LIGHT
10A
GAUGE FROM POWER SOURCE SY STEM (
SEE PAGE 50)
1J 1
II2 2II33
1V 5
1S 13
B 9 B 8
3 1
3 1
BL B 2(
M/T) A 2(
A/T)
B 1(
M/T) A 8(
A/T) A A
A A AF FCC
R±B W± B W±BR±B R±BR±BR±LR�

Page 4364 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P1 (A) BACK±UP LIGHT SW [PARK/NEUTRAL POSITION SW] (A/T)
(A) 2±(A) 8 : Closed with the shift lever at R position
B1 (B) BACK±UP LIGHT SW (M/T)
(B) 2±(B) 1 : Closed with the shift lever at R posi

Page 4365 of 4592

TOYOTA CAMRY 1999 Service Repair Manual WIPER AND WASHER
M
IG1C 4
OFF
INT
LO
HI
25A
WIPER FROM POWER SOURCE SY STEM (
SEE PAGE 50)
11
16 2
8 7
17
W± B
FRONT WIPER
MOTOR F 3 L±W
EB
W±B W± B+B +2 +1 +S INT1 INT2 B1
OFF
ONWF EW
WIPER SW
WA

Page 4366 of 4592

TOYOTA CAMRY 1999 Service Repair Manual With the ignition SW turned on, the current flows to TERMINAL 17 of the wiper and washer SW, TERMINAL 2 of the washer
motor and TERMINAL 2 of the front wiper motor through the WIPER fuse.
1. LOW SPEED

With the ignition SW turned on, the current flows to TERMINAL 17 of the wiper and washer SW, TERMINAL 2 of the washer
motor and TERMINAL 2 of the front wiper motor through the WIPER fuse.
1. LOW SPEED POSITION
With the wiper and washer SW turned to LO position, the current flows from TERMINAL 17 of the wiper and washer SW to
TERMINAL 7 to TERMINAL 5 of the front wiper motor to TERMINAL 4 to GROUND and causes the front wiper motor to run
at low speed.
2. HIGH SPEED POSITION
With the wiper and washer SW turned to HI position, the current flows from TERMINAL 17 of the wiper and washer SW to
TERMINAL 8 to TERMINAL 3 of the front wiper motor to TERMINAL 4 to GROUND and causes the front wiper motor to run
at high speed.
3. INT POSITION
With the wiper and washer SW turned to INT position, the wiper relay operates and current flows from TERMINAL 17 of the
wiper and washer SW to TERMINAL 2 to GROUND. This activates the intermittent circuit and the current flows from
TERMINAL 17 of the wiper and washer SW to TERMINAL 7 to TERMINAL 5 of the front wiper motor to TERMINAL 4 to
GROUND and the wiper operates. Intermittent operation is controlled by a condenser charge and discharge function in the
relay.
4. WASHER CONTINUOUS OPERATION
With the wiper and washer SW pulled to WASHER position (Washer SW ON position), the current flows from the WIPER
fuse to TERMINAL 2 of the washer motor to TERMINAL 1 to TERMINAL 11 of the wiper and washer SW to TERMINAL 2 to
GROUND and causes the washer motor to run and the window washer to spray. Simultaneously, current flows from the
WIPER fuse to TERMINAL 17 of the wiper and washer SW to TERMINAL 7 to TERMINAL 5 of the front wiper motor to
TERMINAL 4 to GROUND, causing the wiper to function.
C11 WIPER AND WASHER SW [COMB. SW]
2±GROUND : Always continuity
17±GROUND : Approx. 12 volts with the ignition SW at ON position
7±GROUND : Approx. 12 volts with the ignition SW on and the wiper and washer SW at LO position
Approx. 12 volts every approx. 1 to 10 seconds intermittently with the ignition SW on
and the wiper and washer SW at INT position
16±GROUND : Approx. 12 volts with the ignition SW on and unless the front wiper motor at STOP position
8±GROUND : Approx. 12 volts with the ignition SW on and the wiper and washer SW at HI position
F3 FRONT WIPER MOTOR
1±2 : Closed unless the front wiper motor at STOP position
: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
C1130J1131J36B31
F326 (1MZ±FE)J1531W227 (1MZ±FE)F328 (5S±FE)J35A31W229 (5S±FE)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee PageJunction Block and Wire Harness (Connector Location)
1A20Cowl Wire and Instrument Panel J/B (Lower Finish Panel)1C20Cowl Wire and Instrument Panel J/B (Lower Finish Panel)
2F22Engine Room Main Wire and Engine Room J/B No.2 (Engine Compartment Left)
2J22Cowl Wire and Engine Room J/B No.2 (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
IK142Engine Room Main Wire and Cowl Wire (Right Kick Panel)
SYSTEM OUTLINE
SERVICE HINTS

Page 4367 of 4592

TOYOTA CAMRY 1999 Service Repair Manual WIPER AND WASHER
: GROUND POINTS
CodeSee PageGround Points Location
EB36 (1MZ±FE)Left Radiator Side SupportEB38 (5S±FE)Left Radiator Side Support
IG40Instrument Panel Brace LH
X 2 X XXX 7 8 X
X 11 X

Page 4368 of 4592
