1999 TOYOTA CAMRY Service Repair Manual

fusesbrake rotordeactivate passenger airbagservice scheduletiming beltcenter console
Popular search:
wheel bolt torqueair conditionlow beamcheck engine lightsunroofrear view mirrorsport mode
Previous
Next
Load previous 8 pages

Page 1497 of 4592

TOYOTA CAMRY 1999 Service Repair Manual FI6510FI6607A00113 KNK Signal Waveforms 0.5 V /Division 5 msec./Division 100 msec./Division 0 V 200 mV /Division 0 V ± DIAGNOSTICSENGINE (1MZ±FE) DI±285 520 Author: Date: Reference INSPECTION US

Page 1498 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±286 ± DIAGNOSTICSENGINE (1MZ±FE) 521 Author: Date: 3 Check for open and short in harness and connector between EC1 connector and knock sensor (See page IN±31). HINT: If DTC P0325 has changed

Page 1499 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P25474 Camshaft Position Sensor 1 2 1 2B±W B±RL BR LECM G22+ NE+ NE± E2 E10 E10E11 2410 Crankshaft Position SensorB±R16 ± DIAGNOSTICSENGINE (1MZ±FE) DI±287 522 Author: Date: DTC P0335 Cranksh

Page 1500 of 4592

TOYOTA CAMRY 1999 Service Repair Manual FI7059 FI7060 A00069 G22, NE Signal Waveforms G22 G22NE NE5 V /Division 5 V /Division 20 msec./Division (Idling) 10 msec./Division (Idling) DI±288 ± DIAGNOSTICSENGINE (1MZ±FE) 523 Author: Date: 1

Page 1501 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± DIAGNOSTICSENGINE (1MZ±FE) DI±289 524 Author: Date: 3 Inspect sensor installation and teeth of crankshaft timing pulley. NG Tighten the sensor. Replace crankshaft timing pulley. OK Check and

Page 1502 of 4592

TOYOTA CAMRY 1999 Service Repair Manual DI±290 ± DIAGNOSTICSENGINE (1MZ±FE) 525 Author: Date: DTC P0340 Camshaft Position Sensor Circuit Malfunction CIRCUIT DESCRIPTION Camshaft position sensor (G22 signal) consist of a signal plate an

Page 1503 of 4592

TOYOTA CAMRY 1999 Service Repair Manual ± DIAGNOSTICSENGINE (1MZ±FE) DI±291 526 Author: Date: 2 Check for open and short in harness and connector between ECM and camshaft position sensor (See page IN±31). NG Repair or replace harness

Page 1504 of 4592

TOYOTA CAMRY 1999 Service Repair Manual A00199 ECM Mass Air Flow MeterVSV for EGR EGR Valve Position Sensor EGR Valve EGR Gas Temp. Sensor Crankshaft Position Sensor Engine Coolant Temp. SensorIntake Air Chamber Throttle ValveVacuum Contro
