Page 969 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0NG±01 BO0632 BO0633 15° 45° BO±124 ± BODYSEAT BELT 2472 Author: Date: INSPECTION CAUTION: Replace the seat belt assembly (outer belt, inner belt, bolts, nuts or sill±bar) if it has been use

Page 970 of 4592

TOYOTA CAMRY 1999 Service Repair Manual N10070 Full Belt Length Minus 200 mm (7.87 in.) BO0633 15° 45° ± BODYSEAT BELT BO±125 2473 Author: Date: (e) Retract the whole belt, then pull out the belt until 200 mm (7.87 in.) of belt remain

Page 971 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0NH±01 H01346 BO±126 ± BODYSEAT BELT PRETENSIONER 2474 Author: Date: SEAT BELT PRETENSIONER REMOVAL NOTICE: If the wiring connector of the supplemental restraint system is disconnected with th

Page 972 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0NI±01 H00563 H01878 ± BODYSEAT BELT PRETENSIONER BO±127 2475 Author: Date: INSPECTION 1. PRETENSIONER IS NOT ACTIVATED (a) Perform a diagnostic system check. (See page DI±626) (b) Perform a v

Page 973 of 4592

TOYOTA CAMRY 1999 Service Repair Manual BO0NJ±01 AB0152 SST BO±128 ± BODYSEAT BELT PRETENSIONER 2476 Author: Date: DISPOSAL HINT: When scrapping vehicles equipped with a supplemental re- straint system or disposing of a front seat oute

Page 974 of 4592

TOYOTA CAMRY 1999 Service Repair Manual AB0158 SSTBattery AB0152 SST AB0158 SSTBattery H01580 SST H01346 ± BODYSEAT BELT PRETENSIONER BO±129 2477 Author: Date: 1. SEAT BELT PRETENSIONER DEPLOYMENT WHEN SCRAPPING VEHICLE HINT: Have a bat

Page 975 of 4592

TOYOTA CAMRY 1999 Service Repair Manual H01880 SST SST R13455 10 m (33 ft) or more BO±130 ± BODYSEAT BELT PRETENSIONER 2478 Author: Date: (5) Connect the 2 SST, then connect them to the seat belt pretensioner. SST 09082±00700, 09082±0

Page 976 of 4592

TOYOTA CAMRY 1999 Service Repair Manual AB0158 SSTBattery H01880 SST SST H01881SST SST ± BODYSEAT BELT PRETENSIONER BO±131 2479 Author: Date: 2. DEPLOYMENT WHEN DISPOSING OF FRONT SEAT OUTER BELT ONLY NOTICE: When disposing of the fron
