± BODYFRONT BUMPER
BO±5
2353 Author: Date:
REMOVAL
1. REMOVE THESE PARTS:
(a) Engine under cover
(b) Fender liner
(c) Turn signal light assembly
HINT:
Remove the light assembly as shown.
2. REMOVE BUMPER COVER
(a) Remove the 2 bolts and 3 clips.
Torque: 5.5 N´m (55 kgf´cm, 49 in.´lbf)
(b) Remove the bolt holding the bumper end to the fender.
(c) Pull the bumper cover forward to remove the bumper cov-
er from the clip under the turn signal light area.
(d) Pull the bumper cover forward to remove it.
HINT:
At the time of installation, please refer to the refer to the follow-
ing item.
Align the holes of the bumper cover with the 2 bumper stays of
the reinforcement.
3. REMOVE THESE PARTS:
(a) Front bumper energy absorber
(b) Front bumper reinforcement
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
(c) Front bumper upper reinforcement subassembly
Page 850 of 4592
BO0KX±01
BO±6
± BODYFRONT BUMPER
2354 Author: Date:
INSTALLATION
Installation is in the reverse order of removal (See page BO±5).
Page 851 of 4592
BO0KY±01
H01713
Left Side Luggage Trim
Right Side Luggage Trim
Rear Bumper
Side Retainer Rear Bumper Energy Absorber Rear Bumper Reinforcement
Quarter Air Duct
Rear Bumper
Side Retainer
Rear Bumper Cover
5.0 (50, 43 in.´lbf)
5.0 (50, 43 in.´lbf)
N´m (kgf´cm, ft´lbf) : Specified Torque
34 (350, 25)
± BODYREAR BUMPER
BO±7
2355 Author: Date:
REAR BUMPER
COMPONENTS
Page 852 of 4592
BO0KZ±01
H01714
H01715
BO±8
± BODYREAR BUMPER
2356 Author: Date:
REMOVAL
1. REMOVE THESE PARTS:
(a) Right side luggage trim
(b) Left side luggage trim
2. REMOVE REAR BUMPER COVER
(a) Remove the 7 clips, 2 bolts and 6 nuts from the bumper
cover.
Torque: 5.0 N´m (50 kgf´cm, 43 in.´lbf)
(b) Pull the bumper cover rearward to remove it.
HINT:
With a plastic hammer, tap the ends of the bumper end bolts.
(c) Using a screwdriver, slide the rear bumper side retainers
from the bumper ends.
(d) Remove the 2 gaskets from the side retainers.
HINT:
Use 2 new gaskets.
3. REMOVE THESE PARTS:
(a) Rear bumper energy absorber
(b) Rear bumper reinforcement
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
Page 853 of 4592
BO0L0±01
± BODYREAR BUMPER
BO±9
2357 Author: Date:
INSTALLATION
Installation is in the reverse order of removal (See page BO±8).
Page 854 of 4592
BO5235
Centering Bolt Bolt with Washer
BO0L1±01
N20963
N20964
N20965
BO±10
± BODYHOOD
2358 Author: Date:
HOOD
ADJUSTMENT
HINT:
Since the centering bolt is used as the hood hinge and lock set
bolt, the hood and lock can not be adjusted with it on. Substitute
a bolt and washer for the centering bolt.
1. ADJUST HOOD IN FORWARD/REARWARD AND
LEFT/RIGHT DIRECTIONS
Adjust the hood by loosening the hood side hinge bolts.
Torque: 26 N´m (260 kgf´cm, 19 ft´lbf)
2. ADJUST FRONT EDGE OF HOOD IN VERTICAL
DIRECTIONS
Adjust the hood by turning the cushions.
3. ADJUST HOOD LOCK
(a) Replace each centering bolt with a regular bolt and wash-
er.
Torque: 8.0 N´m (80 kgf´cm, 71 in.´lbf)
HINT:
Remove the anti±theft bolt cover, then remove the lower hood
lock bolt. You may have to remove the front bumper to access
this bolt.
(b) Adjust the lock by loosening the bolts.
Page 855 of 4592
BO0L2±01
H01975
Door Lock
Cylinder
Outside Handle Front Door Belt Moulding
Door Glass
Door FrameFront Door Upper Moulding
Outside
Rear View
Mirror
Door Glass
Run
5.5 (55, 49 in.´lbf)
5.5 (55, 49 in.´lbf)
5.0 (50, 43 in.´lbf)
Door Lock
23 (230, 17)
Window Regulator
8.0 (80, 69 in.´lbf)
Door Hinge
X6
7.5 (75, 66 in.´lbf)
Regulator
Motor
X3
31 (310, 22)
26 (260, 19)
8.0 (80, 71 in.´lbf)
30 (300, 22)
31 (310, 22)
Door
Check
Door Hinge
26 (260, 19)
Speaker
Power Window Switch Rear Lower
FrameFront Lower
FrameFront Window Upper
Garnish
Inside Handle Bezel
3.5 (35, 31 in.´lbf)
Driver's Side:
Regulator
Motor
Ptdt
N´m (kgf´cm, ft´lbf) : Specified torqueInside Handle
Door Trim
Precoated part Door Lock StrikerService Hole Cover
± BODYFRONT DOOR
BO±11
2359 Author: Date:
FRONT DOOR
COMPONENTS
Page 856 of 4592

BO0L3±01
H01738
N20968
N210034 Clips
N20969
(c)
(b)(a)
BO±12
± BODYFRONT DOOR
2360 Author: Date:
DISASSEMBLY
1. w/o Power Window:
REMOVE REGULATOR HANDLE
Pull off the snap ring with a shop rag and remove the regulator
handle and plate.
HINT:
At the time of assembly, please refer to the following item.
With the door window fully closed, install the plate and the regu-
lator handle with the snap ring.
2. REMOVE INSIDE HANDLE BEZEL
(a) Using a screwdriver, pry open the screw cover and re-
move the screw.
HINT:
Tape the screwdriver tip before use.
(b) Using a screwdriver, pry out the bezel.
HINT:
Tape the screwdriver tip before use.
3. REMOVE FRONT WINDOW UPPER GARNISH
4. REMOVE DOOR TRIM
(a) Using a screwdriver, remove the screw caps.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 2 clips, 2 screws and 2 bolts.
(c) Insert a screwdriver between the door and door trim to pry
out.
(d) Pull the trim upward to remove it, then remove the power
window switch and disconnect the harness connector.
5. REMOVE THESE PARTS:
(a) Outside rear view mirror
Torque: 5.5 N´m (55 kgf´cm, 49 in.´lbf)
(b) Speaker
6. REMOVE DOOR INSIDE HANDLE
(a) Remove the screw and pull the handle forward.
Torque: 3.5 N´m (35 kgf´cm, 31 in.´lbf)
(b) Remove the link from the clamp.
(c) Remove the inside handle from the ends of the 2 links.
7. REMOVE SERVICE HOLE COVER
Remove the grommet, then remove the service hole cover.
