1999 TOYOTA CAMRY diagnostic menu

Toyota Supports ASE CertificationPage 1 of 23
EG003-02Title:
READINESS MONITOR DRIVE PATTERNS
Models:
All '96 ± '02
Technical Service
BULLETIN
March 29, 2002

TSB REVISION NOTICE:
The information updated in this TSB is red
and underlined.
The On±Board Diagnostic (OBDII) system is designed to monitor the performance of
emission±related components and report any detected abnormalities in the form of
Diagnostic Trouble Codes (DTCs). Since the various components need to be monitored
during different driving conditions, the OBDII system is designed to run separate
monitoring programs called Readiness Monitors. Many state Inspection and
Maintenance (I/M) programs require that vehicles complete their Readiness Monitors
prior to beginning an emissions test.
The current status of the Readiness Monitors can be seen by using the Toyota Diagnostic
Tester with version 9.0 software (or newer), or a generic OBDII Scantool.
To view the Readiness Monitor status using the Toyota Diagnostic Tester, select ªMonitor
Statusº from the Enhanced OBDII Menu.
A status of ªcompleteº indicates that the necessary conditions have been met to run the
performance tests for the related Readiness Monitor.
The Readiness Monitor will be reset to ªincompleteº if:

ECU has lost power (battery or fuse).

DTCs have been cleared.

The conditions for running the Readiness Monitor have not been met.
In the event that any Readiness Monitor shows ªincomplete,º follow the appropriate
Readiness Monitor Drive Pattern to change the readiness status to ªcomplete.º
Refer to the Readiness Monitor Drive Pattern Application Table to determine which
drive pattern should be followed.
SECTIONPAGE(S)
Readiness Monitor Drive Pattern Application Tables3±9
Readiness Monitor Drive Patterns
1EGR Monitor (All Except 1FZ±FE Engine)10
2EGR Monitor (For 1FZ±FE Engine)11
3Catalyst Monitor (O2S Type)12
4Catalyst Monitor (AF Sensor Type)13
5EVAP Monitor (Internal Pressure Monitor/Non±Intrusive Type)14±15
6EVAP Monitor (Vacuum Pressure Monitor/Intrusive Type)16±17
7EVAP Monitor (Without Leak Detection)18
8EVAP Monitor (For Prius)19±20
9Oxygen Sensor Monitor (Front and Rear O2S System)21
10Oxygen/AF Sensor Monitor (Front AF Sensor and Rear O2S System)22
11Oxygen/AF Sensor Heater Monitor23

All 1996 ± 2002 model year Toyota vehicles.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty±±±±
ENGINE
Introduction
Contents
Applicable
Vehicles
Warranty
Information

EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 11 of 14
Diagnostic Process Flow Chart
(Continued on following page)
PRELIMINARY CHECK
Fuel level should be between
1/4 and 3/4
Visually inspect for presence
of Fuel/Gas Cap
DO NOT TIGHTEN OR REMOVE!
PRESSURIZE EVAP SYSTEM (System Integrity Check)
This test checks for leaks in the canister and fuel tank sides. The CCV and Air Inlet Lines will be checked
separately.
A) Clamp the air drain hose on the charcoal canister with the supplied hose pliers from the EVAP System
Pressure Test Kit.
B) Locate the vapor pressure sensor. If the vapor pressure sensor has two hoses connected to it,
disconnect the hose between the air drain hose fitting at the vapor pressure sensor and plug the hose.
C) Connect the pressure supply hose from the Pressure Test Kit to the Green EVAP System Service Port
located on the EVAP Purge VSV line in the engine compartment.
D) Using the directions on the inside of the EVAP System Pressure Test Kit lid, pressurize the EVAP
system. Once pressurized, turn off the pump and seal the system (Pressure Hold Switch to ªClosedº
and Vent Switch to ªClosed).
E) After 30 seconds, note the pump pressure gauge reading and the Scan Tool vapor pressure
sensor reading.
F) Compare the readings to one of the four conditions listed below and proceed as directed.
DO NOT PROCEED! NG
OK
SCAN TOOL SETUP
A) Connect Scan Tool to DLC3 on vehicle.
B) Go to the SETUP menu and select UNIT CONVERSION.
C) Under VAPOR PRESSURE, Select ABS for absolute pressure, and mmHg for millimeters of mercury.
This is to match the Repair Manual specifications.
D) Go back to FUNCTION SELECT menu and select ENHANCED OBD II.
E) Select NORMAL MODE. Then select CURRENT DATA and USER SELECT.
F) Using the arrow key, select VAPOR PRESS from the DATA LIST and select YES.
G) Press ENTER. You will now be able to monitor the Vapor Pressure Sensor reading.
START
If vehicle is ECHO, go directly to ªECHO Canister and Tank Leak Checkº on page 14.
If vehicle is not ECHO, follow the flow chart below.
Diagnostic
Tips for Late
Type EVAP
System
(Continued)

M.I.L. ªONº P0440, P0441 & P0446 ± EG013-02July 12, 2002
Page 2 of 5
Test VSV Operation Using ACTIVE TEST on the Toyota Diagnostic Tester
1. Test operation of the Vapor Pressure Sensor VSV using the Toyota Diagnostic Tester
in ACTIVE TEST (see screen flow in Figure 1).
INJECTOR 0.0ms
IGN ADVANCE 5.0deg
CALC LOAD 0%
MAF 0gm/s
ENGINE SPD 0rpm
COOLANT TEMP 77.0F
INTAKE AIR 87.8F
THROTTLE POS 16%
CTP SW ON
VEHICLE SPD 0MPH
02S B1 S1 0.00V
2: CUSTOMIZE
3: ECU REPROGRAMFUNCTION SELECT FOR
NORTH AMERICA
B
*APPLICATION SELECT*
A
1: DIAGNOSISDIAGNOSTIC MENU
ENGINE
C
PRESS INJ VOL
A/F CONTROL
FUEL PMP SP CTL
A/C CUT SIG
CAN CTRL VSV
EVAP VSV (ALONE)
FUEL PUMP/SPD
LINE PRESS UPSELECT DATA
E
SELECT DATA
D
TANK BYPASS VSVUSER DATA
[ENTER]
F
G
TANK BYPASS VSV OFF
1: OBD/MOBD
3: CARB OBD II
4: BREAK±OUT BOX
5: NVH
6: AUTOPROBE
7: 02 RPM CHECK
8: SNAPSHOT REVIEW
9: SETUP
0: GAS ANALYSIS2: ENHANCED OBD1: DATA LIST
2: DTC INFO
4: SNAPSHOT
5: SYSTEM CHECK
6: RESET MEMORY
7: MONITOR STATUS
8: CHECK MODE
3: ACTIVE TEST
ALL
INJECTOR 0.0ms
IGN ADVANCE 5.0deg
CALC LOAD 0%
MAF 0gm/s
ENGINE SPD 0rpm
COOLANT TEMP 77.0F
INTAKE AIR 87.8F
THROTTLE POS 16%
CTP SW ON
VEHICLE SPD 0MPH
02S B1 S1 0.00V Figure 1: Testing Operation of Vapor Pressure Sensor VSV using ACTIVE TEST
TANK BYPASS VSV ON
NOTE:
Vapor Pressure Sensor VSV is listed as TANK BYPASS VSV on the Diagnostic Tester. Inspection &
Repair
Procedure

Toyota Supports ASE CertificationPage 1 of 9
SS001±99Title:
SCANTOOL IMMOBILIZER KEY CODE
UTILITY
Models:
'98 & '99 Avalon, Camry, Land Cruiser & Sienna
'99 Solara & 4Runner
Technical Service
BULLETIN
April 9, 1999

The Diagnostic Tester now incorporates a Key Code Utility Menu capable of performing
the following tasks for immobilizer functions:
Key Code Registration
Key Code Erasure
Auto±Registration Closure
The information contained in this bulletin will provide you with a detailed outline for the
use of immobilizer functions with the Diagnostic Tester.
1998 Avalon, Camry, Land Cruiser and Sienna.
1998 Avalon, Camry, Land Cruiser, Sienna, Solara and 4Runner.
PART NUMBERPART NAME
01001271Toyota Diagnostic Tester Kit
01001895±0056.0a Diagnostic Software Card
NOTE:
Replacement Diagnostic Tester Kits or Software Cards may be ordered by calling
OTC at 1±800±933±8335.
Key Registration
This function allows the registration of additional key codes for transponder keys
(Master/Sub Keys) using a Registered Master Key.
Key Code Erasure
This function allows the user to erase all the key codes for transponder keys except
the Registered Master Key used during this function.
Auto Registration Closure
This function allows the user to close ªAuto Registration Modeª when less than three
keys have been registered.
NOTE:
When a new ECU is installed, it is in the ªAuto Registration Modeº from the factory.
This allows Transponder Keys to automatically register as they are inserted into the
Ignition Cylinder. After three Transponder Keys are registered, the ECU closes ªAuto
Registration Modeº. See the Repair Manual for further details.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
SPECIAL SERVICE TOOLS
Introduction
Affected
Vehicles
Parts
Information
Function
Description
(Key Code
Utility)
Warranty
Information

SCANTOOL IMMOBILIZER KEY CODE UTILITY ± SS001±99 April 9, 1999
Page 2 of 9
This section provides the procedures necessary to access the IMMOBILIZER KEY CODE
UTILITY functions. Refer to the instructions below.
Before any IMMOBILIZER KEY CODE UTILITY function can be performed, the type of
Transponder Key must be verified. The following steps show how to verify the
Transponder Key type.
1. Connect the Diagnostic Tester to DLC3 and press the (ON) key.
2. Insert a Registered Master Key (Black Key Head) into the ignition key cylinder and
turn to the ON position.
HINT:
A Registered Master Key is required for KEY REGISTRATION, KEY CODE ERASURE,
and AUTO REGISTRATION CLOSURE. A Sub Key (Grey Key Head) will not perform
these functions.
3. ªFrom the ªFUNCTION SELECTº menu
(Screen A), select [1: OBD/MOBD].
4. From the ªOBD/MOBD MENUª (Screen
B), select [6: IMMOBILIZER].
5. From the ªDIAGNOSTIC MENU
IMMOBILIZERº (Screen C), select [1:
CURRENT DATA]
Operation
Procedures
Verify
Immobilizer
Key Type

SCANTOOL IMMOBILIZER KEY CODE UTILITY ± SS001±99 April 9, 1999
Page 3 of 9
6. From the ªCURRENT DATA MENU
IMMOBILIZERº (Screen D), select [1:
DATA LIST].
7. From the ªSELECT DATAª menu
(Screen E), select [ALL].
8. The Transponder Key Type in the ignition
cylinder will be displayed (Screen F).
[MASTER] = Registered Master Key
[SUB] = Registered Sub Key
[NO] = Not a Registered Key,
or Vehicle is not
equipped with
Immobilizer.
NOTE:
If the Transponder Key is a Master Key, proceed to [4: KEY CODE UTILITY] by
pressing the (EXIT) key back to the ªDIAGNOSTIC MENU IMMOBILIZERª (Screen C).
From the ªDIAGNOSTIC MENU IMMOBILIZERª (Screen C), select [4: KEY CODE
UTILITY] Verify
Immobilizer
Key Type
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 3 of 43
1. On the Diagnostic Tester* screen,
select the following menus:
DIAGNOSTICS
CARB OBD II
O2S TEST RESULTS
A list of the available oxygen sensors
will be displayed.
2. Select the desired oxygen sensor and
press Enter.
NOTE:
The monitor result of the A/F sensor will
not be displayed. If you select
ªBank 1±Sensor 1º or Bank 2±Sensor 1º
for a vehicle equipped with an A/F
sensor, the Diagnostic Tester will
display ªNo parameter to display.º
3. Compare the test results with the
values listed in the Failure
Threshold Chart.
* Although this procedure references the Toyota
Diagnostic Tester, the O2S test results can be
checked using a generic OBDII scantool.
Refer to your OBDII scantool operator's manual
for specific procedures.
Accessing
O2S Test
ResultsO2S TEST RESULT Screen
01 BANK 1 ± SENSOR 1
01 BANK 1 ± SENSOR 2
01 BANK 2 ± SENSOR 1
01 BANK 2 ± SENSOR 2
TEST DATA Screen
LOW SW V 0.400 V
HIGH SW V 0.550 V
MIN O2S V 0.100 V
MAX O2S V 0.900 V
TIME $81 17

M.I.L. ªONº 1MZ±FE ENGINE MISFIRE DTC P0300 ± P0306 ± EG008-04April 28, 2004
Page 3 of 3
2. Confirm if misfire is currently occurring on cylinder(s) identified by DTC(s) using the
Diagnostic Tester while engine is idling (see below).
FUNCTION SELECT FOR
NORTH AMERICA
B A
DIAGNOSTIC MENU
ENGINE
C
ALL
USER DATA
EXTEND DATA
AT M
02 SENSOR
FUEL SYS
CATALYTIC
EVAP
E
SELECT DATA
D
MISFIRE
1: OBD/MOBD
3: CARB OBD II
4: BREAK±OUT BOX
5: NVH
6: AUTOPROBE
7: 02 RPM CHECK
8: SNAPSHOT REVIEW
9: SETUP
0: GAS ANALYSIS2: ENHANCED OBD
2: DTC INFO
3: ACTIVE TEST
4: SNAPSHOT
5: SYSTEM CHECK
6: RESET MEMORY
7: MONITOR STATUS
8: CHECK MODE1: DATA LIST Examining Data List For Misfire Percent
NOTICE
ENHANCED OBDII
COVERS VEHICLES
THROUGH 2004MY.
EXCEPT SEQUOIA,
TUNDRA, TACOMA.
FOR OTHER VEHICLES
SELECT 2004 NEW
MODEL OR USE CARB
OBDII
PRESS [ENTER]
IGNITION 41
CYL #1 0%
CYL #2 0%
CYL #3 0%
CYL #4 Above 50%
CYL #5 0%
CYL #6 0%
MISFIRE RPM 0rpm
MISFIRE LOAD 0.00g/rev
# CODES 1
CHECK MODE OFF
MISFIRE TEST COMPL
Misfire on #4 Cylinder
Is the cylinder(s) identified by the DTC(s) misfiring?
If YES ± Go to Step 3.
If NO ± Follow normal diagnostics for applicable DTC in Technical Information System
(TIS) in applicable Repair Manual:
Diagnostics: SFI: P030#.
3. Swap suspect ignition coil(s) from cylinder that is misfiring to cylinder that is
not misfiring.
4. Using Diagnostic Tester, confirm that misfire is now occurring in cylinder that has
suspect ignition coil(s). Has misfire followed swapped ignition coil(s)?
If YES ± Replace ignition coil(s) and go to Step 5.
If NO ± Follow normal diagnostics in Technical Information System (TIS) for
applicable Repair Manual:
Diagnostics: SFI: P030#.
5. Confirm misfire has been eliminated (0% at all times) using Diagnostic Tester while
engine is idling.
NOTE:
If misfire percent is any value other than 0% at any time, then that cylinder is misfiring. Repair
Procedure
(Continued)
