Page 3177 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS012±19 ± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE RS±25 2170 Author: Date: REPLACEMENT REPLACEMENT REQUIREMENTS In the following cases, replace the steering wheel pad, s

Page 3178 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS013±15 RS±26 ± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE 2171 Author: Date: INSTALLATION HINT: For step 1 to 4, refer to page SR±16. 1. INSTALL SPIRAL CABLE 2. INSTALL U

Page 3179 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS014±21 H08321 Front Passenger Airbag Assembly 20 (205, 15) N´m (kgf´cm, ft´lbf) : Specified torqueGlove Compartment Door Finish PlateGlove Compartment Box Cowl Side Trim RH Front Door Scuff Pla

Page 3180 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS02P±03 H03287 W03509 RS±28 ± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY 2173 Author: Date: REMOVAL NOTICE: If the wiring connector of the SRS is disconnected and the ignition

Page 3181 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS02Q±03 W03511 W03517 W03510 W03511 ± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY RS±29 2174 Author: Date: INSPECTION 1. VEHICLE NOT INVOLVED IN COLLISION (a) Do a diagnostic sy

Page 3182 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS±30 ± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY 2175 Author: Date: 3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED (a) Do a diagnostic system check. (See page DI±626)

Page 3183 of 4592

TOYOTA CAMRY 1999 Service Repair Manual RS05F±02 AB0152 SST ± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY RS±31 2176 Author: Date: DISPOSAL HINT: When scrapping vehicle equipped with an SRS or disposing of a front pass

Page 3184 of 4592

TOYOTA CAMRY 1999 Service Repair Manual AB0158 SSTBattery H03287 H08317SST R13455 10 m (33 ft) or more H03286 RS±32 ± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY 2177 Author: Date: 1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE
