Page 2713 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM1628 EM2011 EM2538 A05236 EM±48 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD 1334 Author: Date: 13. INSPECT CAMSHAFT FOR RUNOUT (a) Place the camshaft on V±blocks. (b) Using a dial indicator, mea

Page 2714 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P13009 Plastigage P12892 P13004 P12891 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD EM±49 1335 Author: Date: 17. INSPECT CAMSHAFT JOURNAL OIL CLEARANCE (a) Clean the bearing caps and camshaft journa

Page 2715 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12960 EM3322 Free Distance P12685 EM6368 EM±50 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD 1336 Author: Date: (c) Remove the camshafts. 19. INSPECT CAMSHAFT GEAR BACKLASH (a) Install the camshafts

Page 2716 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12400 Z09167 Cylinder Head Side Air Intake Chamber Side Z09168 RH Side LH Side ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD EM±51 1337 Author: Date: 22. INSPECT AIR INTAKE CHAMBER Using a precision

Page 2717 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12496 EM±52 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD 1338 Author: Date: 25. INSPECT 12 POINTED HEAD CYLINDER HEAD BOLTS Using vernier calipers, measure the tension portion diameter of the bolt.

Page 2718 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM0YQ±01 P12688 80 ± 100°C P12803 SST P12956 Bushing sizeBushing bore diameter mm (in.) 10.295 ± 10.313 (0.4053 ± 0.4060)Both intake and exhaust Use STD 10.345 ± 10.363 (0.4073 ± 0.4080)Use O/S

Page 2719 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P12802 SST Z09124 P13235 P13236 P13224 SST EM±54 ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD 1340 Author: Date: (f) Using SST and a hammer, tap in a new guide bushing to the specified protrusion he

Page 2720 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM04V±04 P1151110 ± 15 mm (0.39 ± 0.59 in.)Adhesive P12572 Protrusion P12869 Flush P12719 SST ± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD EM±55 1341 Author: Date: REASSEMBLY HINT: Thoroughly c
