Page 2737 of 4592

TOYOTA CAMRY 1999 Service Repair Manual S04497 B00881 Connector Bracket EM±72 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT 1358 Author: Date: (k) Disconnect the brake booster vacuum hose from the air intake chamber. (l) Disconnect the engi

Page 2738 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P18775 S05393 M/T Z18907 A/T P18752 A05426 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT EM±73 1359 Author: Date: 18. DISCONNECT PS PUMP FROM ENGINE (a) Remove the 2 nuts, and disconnect the PS pressur

Page 2739 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P18755 P19478 Engine Hanger S04501 S05451 EM±74 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT 1360 Author: Date: 22. DISCONNECT FRONT ENGINE MOUNTING INSULATOR FROM FRONT FRAME Remove the 3 bolts holdi

Page 2740 of 4592

TOYOTA CAMRY 1999 Service Repair Manual S04754 S04993 Lift ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT EM±75 1361 Author: Date: 26. REMOVE ENGINE MOVING CONTROL ROD AND NO.2 RH ENGINE MOUNTING BRACKET Remove the 3 bolts, control rod and mo

Page 2741 of 4592

TOYOTA CAMRY 1999 Service Repair Manual EM04Z±04 S04992 Lower S04754 S05451 S04501 EM±76 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT 1362 Author: Date: INSTALLATION 1. ASSEMBLE ENGINE AND TRANSAXLE E153 M/T (See page MX±4) A541E A/T (See

Page 2742 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P18755 A05426 P18752 S05393 M/T Z18907 A/T ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT EM±77 1363 Author: Date: 8. CONNECT FRONT ENGINE MOUNTING INSULATOR Connect the mounting insulator with the 3 bo

Page 2743 of 4592

TOYOTA CAMRY 1999 Service Repair Manual P18775 B00881 ConnectorBracket A B A A C S04497 EM±78 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT 1364 Author: Date: 14. INSTALL PS PUMP (a) Install the PS pump with the 2 bolts. Torque: 43 N´m (440

Page 2744 of 4592

TOYOTA CAMRY 1999 Service Repair Manual S05048 ± ENGINE MECHANICAL (1MZ±FE)ENGINE UNIT EM±79 1365 Author: Date: (f) Connect the 2 ground strap connectors to the LH fender apron. (g) Connect the DLC1 to the RH fender apron. (h) Connect
