TOYOTA CAMRY 1999 Service Repair Manual SEAT BELT EXTENDER: 99 ± 01 MODEL YEAR ± BO020±00 August 11, 2000
Page 4 of 7
REAR SEAT ± EXTENDER APPLICATION
MODELTYPE010099
RAV4W/TOKAI RIKAR±5R±5*1R±5*1
RAV4W/QSSÐQ±4*2Q±4*2
ECHOÐ

Page 3730 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SEAT BELT EXTENDER: 99 ± 01 MODEL YEAR ± BO020±00 August 11, 2000
Page 5 of 7
PART NUMBER PREFIX: 73399±
SERIESLENGTHSERIES6 INCH9 INCH12 INCH15 INCH18 INCH
R±5±16060±16070±16080±16090±16

Page 3731 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SEAT BELT EXTENDER: 99 ± 01 MODEL YEAR ± BO020±00 August 11, 2000
Page 6 of 7
Failure to follow the recommendations indicated below could result in less effectiveness
of the seat belt restraint s

SEAT BELT EXTENDER: '99 ± '01 MODEL YEAR ± BO020±00 August 11, 2000
Page 6 of 7
Failure to follow the recommendations indicated below could result in less effectiveness
of the seat belt restraint system in case of vehicle collision, causing personal injury.
The Seat Belt Extender must not be used:
a. By anyone other than for whom it was provided (name recorded on seat belt
extender).
b. In any vehicle and/or seat position other than the one for which it was
provided.
c. When the Seat Belt Extender is provided for rear seat positions (with
automatic locking retractor), make sure the retractor is locked when in use.
If your seat belt cannot be fastened securely because it is not long enough, a
personalized seat belt extender is available from your Toyota dealer free of charge.
Please contact your local Toyota dealer so that the dealer can order the proper required
length for the extender. Bring the heaviest coat you expect to wear for proper
measurement and selection of length. Additional ordering information is available at your
Toyota dealer.
CAUTION:
When using the seat belt extender, observe the following. Failure to follow these
instructions could result in less effectiveness of the seat belt restraint system in case
of vehicle accident, increasing the chance of personal injury.
Never use the Seat Belt Extender if you can comfortably fasten the seat belt
without it.
The Seat Belt Extender must never be used with any child safety seats.
Remember that the extender provided for you may not be safe when used on a
different vehicle, or for another person or at a different seating position than the
one originally intended for.
To connect the extender to the seat
belt, insert the tab into the seat belt
buckle so that the ªPRESSº signs on
the buckle±release buttons of the
extender and the seat belt are both
facing outward as shown.
You will hear a click when the tab locks
into the buckle.
When releasing the seat belt, press on
the buckle±release button on the
extender, not
on the seat belt. This helps
prevent damage to the vehicle interior
and extender itself.
When not in use, remove the extender and
store in the vehicle for future use.
Owner
Instructions
Seat Belt Extender
Seat Belt Release

Page 3732 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SEAT BELT EXTENDER: 99 ± 01 MODEL YEAR ± BO020±00 August 11, 2000
Page 7 of 7
SEAT BELT EXTENDER WORKSHEET
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTION:
�To minimize the c

SEAT BELT EXTENDER: '99 ± '01 MODEL YEAR ± BO020±00 August 11, 2000
Page 7 of 7
SEAT BELT EXTENDER WORKSHEET
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTION:
To minimize the chance and/or severity of injury in an accident, the seat belt
extender must only be used:
1 By the person for whom it was provided
2 In the seat position for which it was provided
The seat belt extender must never be used with any child safety seats.
When the seat belt extender is provided for rear seat positions (with automatic
locking retractor), make sure the retractor is locked when extender belt is in use.
DEALER
SEAT BELT EXTENDER APPLICATIONAPPLICANT
DEALER CODEDEALER NAMEAPPLICANT NAME
ADDRESSADDRESS
CITY & STATEZIPCITY & STATEZIPPHONE
EMPLOYEE NAMEMODEL YEARBODY TYPESEATING POSITIONVEHICLE IDENTIFICATION NUMBER
DIRECTIONS FOR DETERMINING PROPER EXTENDER LENGTH
1.Place the seat in the position the applicant normally uses
2.With applicant in the seat, wearing thickest coat expected to be worn, pull belt all the way out and try to buckle
belt
If the belt latches into buckle and feels comfortable against upper chest area, an extender is not needed.
If belt does not buckle continue with step 3
If buckle latches but belt has no slack remaining, continue with step 3
3.Measure distance between applicant's navel and seat belt buckle (dimension A) and enter on worksheet
4.With belt all the way out, measure distance between latch tip and buckle tip (dimension B) and enter on
worksheet
NOTE: If belt latches but there is no slack enter zero as dimension B
5.Subtract dimension B from dimension A and record number in check number box on worksheet
6.Seat belt extender length is dimension B rounded up to next extender length (without exceeding check number)
NOTE: If extender length exceeds check number, an extender can not be provided to the
customer
Dimension A:
NAVEL TO BUCKLEDimension B:
LATCH TO BUCKLE
BuckleBuckle NavelLatch
A
B
SEAT BELT EXTENDER CALCULATION
DIMENSION A:DIMENSION B:CHECK NUMBER:
SEAT BELT EXTENDER AUTHORIZATION
The same seat belt extender can be used for right and left seating applications. Each seat belt extender will have
a label identifying the owner, VIN and seating position. Seat belt extenders are available only in black.
Applicant's Signature: _________________________________________ Date: ______________________
(Actual user of seat belt extender)

Page 3733 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 7
BO020-01Title:
SLIDING ROOF DIAGNOSTIC TIPS
Models:
97 ± 01 TMMK Camry
Technical Service
BULLETIN
August 17, 2001

The 1997 ± 2001 model year TMMK Ca

Page 3734 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001
Page 2 of 7
REFPART NUMBERPART NAMEQTY
1963287±AA010Cap, Sliding Roof Housing Drain End, RH1
2063288±AA010Cap, Sliding Roof Housing Drain End

Page 3735 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001
Page 3 of 7
227
19
28
20
16
29
30 15
22
CONDITIONPOSSIBLE CAUSECOMMON REPAIR
Guide pin mis±adjustedRe±adjust guide pin
Mechanism unlatchedRe�

Page 3736 of 4592

TOYOTA CAMRY 1999 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001
Page 4 of 7
CONDITIONPOSSIBLE CAUSECOMMON REPAIR
Guide pin mis±adjustedRe±adjust guide pin
Mechanism unlatchedRe±adjust guide pin
Damaged dr
