Toyota Supports ASE CertificationPage 1 of 1
BO007±99
Title:
TMMK CAMRY/SIENNA HEADLIGHT
ALIGNMENT
Models:
'97±'99 Camry, '98±'99 Sienna
Technical Service
BULLETIN
April 16, 1999
To enhance headlamp performance on dark roads, the headlamp alignment process has
been modified.
1997±1999 TMMK Camrys produced before the following VINs:
Camry (4±Cyl) 4T1BG2 * K * XU453367
Camry (V±6) 4T1BF2 * K * XU079094
Camry (4±Cyl) 4T1BG2 * K * XU877828
Camry (V±6) 4T1BF2 * K * XU930732
1998±1999 Siennas produced before the following VIN:
Sienna 4T3ZF13C * XU119213
Headlight Aiming Device.
Refer to the '98 Camry Repair Manual
page BE±27. Adjust the headlight
nominal line 1'' higher. State and Federal
standards apply.
NOTE:
Vehicle lighting will remain within the
tolerances of all applicable federal and
state regulations.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot applicable to warranty±±±±
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
BODY
Introduction
Affected
Vehicles
Required
Tools and
Material
Repair
Procedure
New Nominal
cutline 1'' up
Warranty
Information
WARRANTY PARTS MARKING PROCEDURE ± PG006-03September 26, 2003
Page 2 of 3
Dealers are requested to mark the location of the failure of all warranty parts that are
listed below.
This list is not inclusive. There may be other components that can be
marked in the area of failure. All other parts that can be marked should be marked.
assist grip assy headlamps
audio (blemish) headliner
back door garnish hoses
bumper covers instrument panel safety pad sub±assy
cargo cover (retractable) Interior light assemblies and covers
carpet knobs, levers, handles
clutch disc l/pulley pump assy
clutch flywheel mirrors (side and rearview)
combination meter glass navigation or VES screens
console and components pillar garnish
cowl assy rack and pinion/power steering gear assy
cowl side trim sub±assy radiator
cupholders room partition board
cylinder head cover sub±assy rotors (mark where min. runout is exceeded or warped)
dash panel insulator assy seat covers/cushions
dashboard and trim seat tracks
disc wheel soft trim
display panels spare tire cover
door handle assy steering column cover
door moulding steering wheel
door trim panel & molding tail lamps and covers
emblems transmission oil pan
engine oil pan visor
exhaust manifold washer jar
floor and cargo mats wheel cap
gear shift knob wheels
grills
Parts
Marking
Requirement
Parts
Marking
List
