Page 2993 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MX04G±02 Z18142FIPG ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY MX±11 1861 Author: Date: DISASSEMBLY 1. REMOVE RELEASE FORK AND BEARING 2. REMOVE BACK±UP LIGHT SWITCH Torque: 44 N´m (450

Page 2994 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q02530 Q05696 Install Remove Q05200 SST Z00455 SSTSST Q02695 MX±12 ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY 1862 Author: Date: 9. REMOVE OUTPUT SHAFT LOCK NUT (a) Unstake the nut. (b) Eng

Page 2995 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q02696 Q02726 SST Socket Wrench ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY MX±13 1863 Author: Date: 13. MEASURE 5TH GEAR RADIAL CLEARANCE Using a dial indicator, measure the radial clearanc

Page 2996 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q02682 SST Q05785 x 5 Q05826 x 17 x 6 Q09474FIPG MX±14 ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY 1864 Author: Date: HINT: At the time of installation, please refer to the following item.

Page 2997 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Q05827 Q03065 ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY MX±15 1865 Author: Date: 21. REMOVE REVERSE IDLER GEAR AND SHAFT (a) Pull out the shaft. (b) Remove the idler gear and thrust washer

Page 2998 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MT0781 MX±16 ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY 1866 Author: Date: 28. REMOVE NO.5 SYNCHRONIZER RING WITH KEY SPRING FROM NO.3 CLUTCH HUB (a) Remove the No.5 synchronizer ring with

Page 2999 of 4592

TOYOTA CAMRY 1999 Service Repair Manual MX05M±01 WM0066 Z00409 SSTSST Z00410 SST SST Z00411 SSTSST ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY MX±17 1867 Author: Date: INSPECTION 1. INSPECT NO.5 SYNCHRONIZER RING (a) Check for we

Page 3000 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Z00593 SSTSST Front Z00413 SST0 ± 0.5mm Z00596 13.5 ± 0.5mm MX±18 ± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE ASSEMBLY 1868 Author: Date: (c) Using SST, press in a new bearing. SST 09310±35010 (d)
