TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
EG002±00
Title:
DIAGNOSTIC TROUBLE CODE P1133
Models:
97 ± 99 Camry: 1MZ±FE CA Spec.
Technical Service
BULLETIN
February 25, 2000

TSB Revision Noti

Toyota Supports ASE CertificationPage 1 of 1
EG002±00
Title:
DIAGNOSTIC TROUBLE CODE P1133
Models:
'97 ± '99 Camry: 1MZ±FE CA Spec.
Technical Service
BULLETIN
February 25, 2000

TSB Revision Notice:
The information updated in this TSB is red
and underlined.
Under certain driving conditions, some 1MZ±FE equipped 1997 ± 1999 Camry California
Emission specification vehicles can exhibit a M.I.L. ªONº DTC P1133. An improved
Air/Fuel Ratio Sensor has been developed to correct this condition.
1997 ± 1999 Camry (1MZ±FE) with California Emission Specification.
MODEL YEARENGINESTARTING VIN
1999 Camry1MZ±FE4T1BF2#K * XU088001
4T1BF2#K * XU933227
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
89467±4102089467±41021Sensor, Air/Fuel
Should a M.I.L. ªONº condition with DTC P1133 be encountered, perform diagnostic
procedures as described in the Repair Manual.
If the problem source cannot be identified after checking all affected areas according
to the Repair Manual, the cause may be an Air/Fuel Ratio Sensor malfunction. In this
case, replace the Air/Fuel Ratio Sensor with the current part number listed above.
If the Exhaust Manifold threads are damaged by removal of the sensor, they can be
repaired by the proper use of a M18 x 1.5 tap.
OP CODEDESCRIPTIONTIMEOPNT1T2
895131R & R Air/Fuel Ratio Sensor0.389467±410209999
Applicable Warranty*:
This repair is covered under the Toyota Basic Warranty. This warranty is in effect for
36 months or 36,000 miles, whichever occurs first, from the vehicle's in±service date.
Coverage is extended to 36 months or 50,000 miles, whichever occurs first, in the
states of California and Massachusetts due to state emissions warranty legislation.
NOTE:
Please enter the DTC in the condition/Cause/Remedy section when applying for
warranty reimbursement.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
ENGINE
Introduction
Applicable
Vehicles
Production
Change
Information
Parts
Information
Repair
Procedure
Warranty
Information

Page 3770 of 4592

TOYOTA CAMRY 1999 Service Repair Manual During vehicle processing by Dealers, care must be taken to avoid applying undercoating in the
area surrounding the Oxygen Sensors. Application of undercoating on or near the Oxygen Sensors
can cause

Page 3771 of 4592

TOYOTA CAMRY 1999 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 23
EG003-02Title:
READINESS MONITOR DRIVE PATTERNS
Models:
All 96 ± 02
Technical Service
BULLETIN
March 29, 2002

TSB REVISION NOTICE:
The information u

Toyota Supports ASE CertificationPage 1 of 23
EG003-02Title:
READINESS MONITOR DRIVE PATTERNS
Models:
All '96 ± '02
Technical Service
BULLETIN
March 29, 2002

TSB REVISION NOTICE:
The information updated in this TSB is red
and underlined.
The On±Board Diagnostic (OBDII) system is designed to monitor the performance of
emission±related components and report any detected abnormalities in the form of
Diagnostic Trouble Codes (DTCs). Since the various components need to be monitored
during different driving conditions, the OBDII system is designed to run separate
monitoring programs called Readiness Monitors. Many state Inspection and
Maintenance (I/M) programs require that vehicles complete their Readiness Monitors
prior to beginning an emissions test.
The current status of the Readiness Monitors can be seen by using the Toyota Diagnostic
Tester with version 9.0 software (or newer), or a generic OBDII Scantool.
To view the Readiness Monitor status using the Toyota Diagnostic Tester, select ªMonitor
Statusº from the Enhanced OBDII Menu.
A status of ªcompleteº indicates that the necessary conditions have been met to run the
performance tests for the related Readiness Monitor.
The Readiness Monitor will be reset to ªincompleteº if:
ECU has lost power (battery or fuse).
DTCs have been cleared.
The conditions for running the Readiness Monitor have not been met.
In the event that any Readiness Monitor shows ªincomplete,º follow the appropriate
Readiness Monitor Drive Pattern to change the readiness status to ªcomplete.º
Refer to the Readiness Monitor Drive Pattern Application Table to determine which
drive pattern should be followed.
SECTIONPAGE(S)
Readiness Monitor Drive Pattern Application Tables3±9
Readiness Monitor Drive Patterns
1EGR Monitor (All Except 1FZ±FE Engine)10
2EGR Monitor (For 1FZ±FE Engine)11
3Catalyst Monitor (O2S Type)12
4Catalyst Monitor (AF Sensor Type)13
5EVAP Monitor (Internal Pressure Monitor/Non±Intrusive Type)14±15
6EVAP Monitor (Vacuum Pressure Monitor/Intrusive Type)16±17
7EVAP Monitor (Without Leak Detection)18
8EVAP Monitor (For Prius)19±20
9Oxygen Sensor Monitor (Front and Rear O2S System)21
10Oxygen/AF Sensor Monitor (Front AF Sensor and Rear O2S System)22
11Oxygen/AF Sensor Heater Monitor23
All 1996 ± 2002 model year Toyota vehicles.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty±±±±
ENGINE
Introduction
Contents
Applicable
Vehicles
Warranty
Information

Page 3772 of 4592

TOYOTA CAMRY 1999 Service Repair Manual READINESS MONITOR DRIVE PATTERNS ± EG003-02 RevisedMarch 29, 2002
Page 2 of 23
J1930 TERMJ1930 DEFINITIONTOYOTA/LEXUS DIAGNOSTIC TESTER PARAMETER
IATIntake Air TemperatureIntake Air
ECTEngine Coolant

Page 3773 of 4592

TOYOTA CAMRY 1999 Service Repair Manual READINESS MONITOR DRIVE PATTERNS ± EG003-02 RevisedMarch 29, 2002
Page 3 of 23
DRIVE PATTERN NUMBER*
O2S/AF
MODELDRIVEEGRCATALYSTEVAPSENSORHTRMODELYEARMODELENGINEDRIVETRAINCATEGORY1234567891011
Terce

Page 3774 of 4592

TOYOTA CAMRY 1999 Service Repair Manual READINESS MONITOR DRIVE PATTERNS ± EG003-02 RevisedMarch 29, 2002
Page 4 of 23
DRIVE PATTERN NUMBER*
O2S/AF
MODELDRIVEEGRCATALYSTEVAPSENSORHTRMODELYEARMODELENGINEDRIVETRAINCATEGORY1234567891011
Terce

Page 3775 of 4592

TOYOTA CAMRY 1999 Service Repair Manual READINESS MONITOR DRIVE PATTERNS ± EG003-02 RevisedMarch 29, 2002
Page 5 of 23
DRIVE PATTERN NUMBER*
O2S/AF
MODELDRIVEEGRCATALYSTEVAPSENSORHTRMODELYEARMODELENGINEDRIVETRAINCATEGORY1234567891011
Terce

Page 3776 of 4592

TOYOTA CAMRY 1999 Service Repair Manual READINESS MONITOR DRIVE PATTERNS ± EG003-02 RevisedMarch 29, 2002
