Page 3945 of 4592
TRANSMISSION OIL COOLER INSTALLATION ± TC003±97 October 17, 1997
Procedure1. Parts removal in preparation for cooler
installation:
A. Remove the 9 bolts, 2 screws and
the center engine under cover.
B. Remove the engine coolant
temperature switch connector and
the wire clamp.
C. Remove battery and tray.
D. Disconnect the cooling fan
connector.
E. Disconnect the No.1 engine coolant
temperature switch wire connector.
F. Remove the 2 bolts and then the
cooling fan.
Page 2 of 6
Fig. 2Center Engine Under Cover
Fig. 3ClampSwitch
Fig. 4
Page 3946 of 4592
Page 3 of 6
TRANSMISSION OIL COOLER INSTALLATION ± TC003±97 October 17, 1997
Procedure2. Cooler Installation:
(Continued)
A. Install the 140 mm (5.51º) hose to
the oil cooler tube No. 1 as shown.
NOTE:
Install the hose clamp with the hose
clamp clip at the position shown, and
use pliers to pull off the clip in the
direction indicated by the arrow.
B. Install the tube bracket onto the left
side of the front suspension
member with the 2 bolts as shown.
Torque: 62 in±lbf
(7 N±m / 71 kgf±cm)
C. Install the 130 mm (5.12º) hoses
and the 180 mm (7.09º) hose to the
oil cooler tube No. 2 as shown.
NOTE:
Install the hose clamps with the hose
clamp clips at the positions shown,
and use pliers to pull off the clips in
the direction indicated by the arrows.
Fig. 5
Oil Cooler Tube No. 1
140 mm Hose
5 mm (0.20º)
Fig. 6
Fig. 7
5 mm (0.20º)
180 mm Hose Oil Cooler Tube No. 2
130 mm Hose
Page 3947 of 4592

TRANSMISSION OIL COOLER INSTALLATION ± TC003±97 October 17, 1997
ProcedureD. Remove the lower side clip of the
(Continued) radiator side LH deflector.
E. Install the tube bracket with the bolt
on the side member.
Torque: 62 in±lbf
(7 N±m / 71 kgf±cm)
F. Reinstall the lower side clip
of the radiator LH deflector.
G. Connect the hoses from the oil
cooler tube No. 2 to the oil cooler
tube No.1.
NOTE:
Install the hose clamps with the hose
clamp clips at the positions shown, and
use pliers to pull off the clips in the
direction indicated by the arrows.
H. Disconnect the hose from the oil
cooler pipe of the radiator LH side.
NOTE:
Place a container below vehicle to catch
any leaking ATF. Remove the other end
of this hose from transaxle and discard.
I. Connect the hose from oil cooler
tube No.1 to the oil cooler pipe of
the radiator LH side.
NOTE:
Install the hose clamps with the hose
clamp clips at the positions shown, and
use pliers to pull off the clips in the
direction indicated by the arrows.
Page 4 of 6
Fig. 8
Oil Cooler Tube No. 1
Front Suspension Member
5 mm (0.20º)
Fig. 9
Fig. 10
5 mm (0.20º)
Page 3948 of 4592
Page 5 of 6
TRANSMISSION OIL COOLER INSTALLATION ± TC003±97 October 17, 1997
ProcedureJ. Install the 190 mm (7.48º) hose
(Continued) between the oil cooler tube No.1
and transaxle oil cooler tube.
NOTE:
Install the hose clamps with the hose
clamp clips at the positions shown, and
use pliers to pull off the clips in the
direction indicated by the arrows.
K. Install the oil cooler onto the center
brace and front cross member
using the two bolts and nut as
illustrated in figure 12.
Torque: 65.5 in±lbf
(7.4 N±m/75.5 kgf±cm)
L. Connect the hoses to the pipes.
NOTE:
Install the hose clamps with the hose
clamp clips at the positions shown, and
use pliers to pull off the clips in the
direction indicated by the arrows.
Fig. 11
5 mm (0.20º)
190 mm Hose
5 mm (0.20º) Oil Cooler Tube No. 1
Fig. 13
Page 3949 of 4592

TRANSMISSION OIL COOLER INSTALLATION ± TC003±97 October 17, 1997
Procedure3. Final Assembly:
(Continued)
A. Reconnect the coolant temperature
switch connector and wire clamp as
illustrated in figure 14.
B. Install the cooling fan with 2 bolts.
C. Reconnect the cooling fan
connector and the No.1 engine
temperature switch wire connector
as shown in figure 15.
D. Reinstall battery and tray.
E. Start the engine.
F. With the engine at idle and the
brake pedal depressed, shift the
selector into all positions from ªPº to
ªLº, and return it to the ªPº position.
G. Check for leaks from the hose joints.
H. Add new fluid type ATF D´II or
DEXRON´III (DEXRON´II).
NOTE:
Additional capacity with cooler will be
0.38 US quarts (0.36 liters).
I. Shift the selector into all positions
from ªPº to ªLº, and return to ªPº.
J. Check fluid level with engine idling
at normal operating temperature of
158 to 176F (70 to 80C) and add
more fluid if required.
CAUTION:
Do not overfill.
K. Shut off the engine and reinstall the
center engine under cover with 9
bolts and 2 screws as shown in
figure 18.
Page 6 of 6
Fig. 15
Fig. 16
Fig. 17
Fig. 18
Page 3950 of 4592
Toyota Supports ASE CertificationPage 1 of 1
TC003±98Title:
AUTOMATIC TRANSMISSION FLUID
TYPE T-IV
Models:
All Models
Technical Service
BULLETIN
June 19, 1998
The introduction of Automatic Transmission Fluid type T±IV makes type T±II obsolete.
Use type T±IV for all applications that specify ATF type T±II.
All vehicles with Automatic Transmissions specified to use ATF Types T±II or T±IV.
TYPE OF ATF
SPECIFIED ATFDextron®±IIITYPE TTYPE T±IITYPE T±IV
Dextron®±II or IIIOKXXX
TYPE TXOKXX
TYPE T±IIXXOKOK
TYPE T±IVXXXOK
X = NOT USABLE
SIZENEW PART NUMBERPART NAME
4 Liter08886±01705ATF type T±IV
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
TRANSMISSION & CLUTCH
Introduction
Applicable
Vehicles
Parts
Information
Warranty
Information
Page 3951 of 4592

Toyota Supports ASE CertificationPage 1 of 1
TC003±99Title:
AUTOMATIC TRANSMISSION FLUIDS
Models:
All Models
Technical Service
BULLETIN
May 21, 1999
REVISION NOTICE:
The information contained in this TSB updates TC003±98 dated June 19, 1998.
Automatic Transmission Fluid Type T±IV now replaces Type T±II fluid. Use Type T±IV for
all applications that specify ATF Type T±II.
Please refer to the following table for the interchangeability between each ATF.
All vehicles produced after 1993 with Automatic Transmissions specified to use
ATF Type T, T±II and T±IV.
SPECIFIED ATFTYPE OF ATFSPECIFIED ATFDEXTRON) II OR IIITYPE TTYPE T±IITYPE T±IV
DEXTRON) II OR IIIOKXXX
TYPE TXOKXOK
TYPE T±IIXXOKOK
TYPE T±IVXXXOK
X = NOT USABLE
NOTICE:
With the exception of mixing ATF Type T with Type T±IV fluids, different types of fluids
must not
be mixed.
SIZENEW PART NUMBERPART NAME
4 Liter08886±01705ATF Type T±IV
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
TRANSMISSION & CLUTCH
Introduction
Affected
Vehicles
Parts
Information
Warranty
Information
Page 3952 of 4592
Use the following tables to locate and read the original automatic transmission serial number.
Title: AUTOMATIC TRANSMISSION SERIAL NUMBERSPage 1 of 3
DECEMBER 20, 1996
TRANSMISSION &
CLUTCH
TC004-96
ALL MODELS
TRANSMISSION TRANSMISSION
LOCATION
MODEL SERIAL NUMBER
*See Model Code chart on Page 3.96 A E 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
96 A Y 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
96 A ZT 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
A4#D#
A34##
A131L
(AW Product)
A24##
