Crankshaft

Installation (cont'd)

10. Apply liquid gasket to the cylinder block mating sur-

face of the rear cover, then install the cover on the

cylinder block.

REAR COVER

Apply liquid gasket

along the broken line.

Do not apply liquid gasket

to O-ring groove.

NOTE:

• Use liquid gasket, Part No. 08718 - 0001 or 08718

- 0003.

• Check that the mating surfaces are clean and dry

before applying liquid gasket.

• Apply liquid gasket evenly, being careful to cover

all the mating surface.

• To prevent oil leakage, apply liquid gasket to the

inner threads of the bolt holes.

• Do not apply liquid gasket to O-ring grooves.

• Do not install the parts if five minutes or more

have elapsed since applying liquid gasket.

Instead reapply liquid gasket after removing old

residue.

• After assembly, wait at least 30 minutes before

filling the engine with oil.

Apply liquid gasket

along the broken line.
O-RING GROOVE
NOTE:

• Apply a light coat of oil to the crankshaft and to the

lip of the oil seal.

• Use a new O-ring and apply oil when installing it.

REAR COVER
DOWEL PINS

6 x 1.0 mm

12 N-m (1.2 kgf-m,

8.7 Ibf-ft)
O-RING

Replace.

11. Apply liquid gasket to the cylinder block mating sur-

face of the oil pump.

NOTE: Do not apply liquid gasket to the O-ring

grooves.

OIL PUMP

HOUSINGProCarManuals.com

12. Instal l th e oi l pum p wit h ne w O-rings .
NOTE:
• Appl y a ligh t coa t o f oi l t o th e crankshaf t an d t o
th e li p o f th e seal .
• Us e ne w O-ring s an d appl y oi l whe n installin g
them.
DOWE L PI N
O-RING S
Replace .
OIL PUM P
DOWE L PI N
6 x 1. 0 m m12 N- m (1. 2 kgf-m ,
8. 7 Ibf-ft )
8 x 1.2 5 mm22 N- m (2. 2 kgf-m ,
1 6 Ibf-ft ) DOWE
L PI N DOWE
L PI N
OIL PA NASSEMBL Y
NOTE: D o no t appl y liqui d gaske t t o th e O-rin g
grooves .
13. Appl y liqui d gaske t t o th e cylinde r block , the n instal l
the oi l pan .
CYLINDE RBLOCK
Apply liqui d gaske talong th e broke n line .
O-RIN GGROOV E
(cont'd)
ProCarManuals.com

BALANCERSHAFT
Crankshaf t
Installation (cont'd )
14. Tighte n th e oi l pa n bolt s a s shown .
OIL PA N BOL T TIGHTENIN G SEQUENC E
8 x 1.2 5 mm : 2 2 N- m (2. 2 kgf-m , 1 6 Ibf-ft )
15. Appl y engin e oi l t o th e balance r shaft , the n inser t
th e balance r shaft .
NOTE : Tak e car e no t t o damag e th e journal s whe n
installin g th e balance r shaft . 16
. Instal l th e balance r shaf t holde r (se e pag e 7-3 ).
NOTE : Appl y liqui d gaske t aroun d th e oi l hol e t o
th e bloc k matin g surface .
17 . Instal l th e rea r balance r weight .
18 . Hol d th e balance r shaf t a s show n below , the n tighte n
the bolt .
8 x 1.2 5 mm25 N- m (2. 5 kgf-m ,
1 8 Ibf-ft )
19. Instal l th e balance r shaf t rea r cover .
BALANCE R SHAF TREAR COVE R6 x 1. 0 m m12 N- m (1. 2 kgf-m ,
8. 7 Ibf-ft )
O-RIN GReplace .
