Floor Jack

1. Block the rear wheels when raising the front of the

vehicle; block the front wheels when raising the rear

of the vehicle.

Place the blocks behind and ahead of the wheels.

2. Raise the vehicle high enough to insert the safety

stands.

3. Adjust and place the safety stands so the vehicle

will be approximately level, then lower the vehicle

onto them.
Always use safety stands when working on or under

any vehicle that is supported by only a jack.

Never attempt to use a bumper jack for lifting or

supporting the vehicle.

Front

Center the jack

bracket in the middle

of the jack lift platform.
JACK LIFT PLATFORM

Rear

Center the jack

bracket in the middle

of the jack lift platform.
JACK LIFT PLATFORMProCarManuals.com

Towing
If th e vehicl e need s t o b e towed , cal l a professiona l tow -
in g service . Neve r to w th e vehicl e behin d anothe r vehi -
cl e wit h jus t a rop e o r chain . I t i s ver y dangerous .
Emergenc y Towin g
Ther e ar e thre e popula r method s o f towin g a vehicle .
Flat-be d Equipmen t — Th e operato r load s th e vehicl e o n
th e bac k o f a truck . Thi s is th e bes t wa y o f transportin g th e
vehicle .
Whee l Lif t Equipmen t — Th e to w truc k use s tw o pivotin g
arm s tha t g o unde r th e tire s (fron t o r rear ) an d lift s the m
off th e ground . Th e othe r tw o wheel s remai n o n th e
ground .
Sling-typ e Equipmen t — Th e to w truc k use s meta l cable s
wit h hook s o n th e ends . Thes e hook s g o aroun d part s o f
th e fram e o r suspensio n an d th e cable s lif t tha t en d o f
th e vehicl e of f th e ground . Th e vehicle' s suspensio n an d
bod y ca n b e seriousl y damage d i f thi s metho d o f towin g
i s attempted .
I f th e vehicl e canno t b e transporte d b y flat-bed , i t shoul d
b e towe d wit h th e fron t wheel s of f th e ground . I f du e t o
damage , th e vehicl e mus t b e towe d wit h th e fron t
wheel s o n th e ground , d o th e following .
Release th e parkin g brake .
Star t th e engine .
Shift t o position , the n position .
Tur n of f th e engine .
Leav e th e ignitio n switc h in Accessor y (I ) s o th e steer -
in g whee l doe s no t look .
CAUTION : Imprope r towin g preparatio n wil l damag e
th e transmission . Follo w th e abov e procedur e exactly . I f
yo u canno t shif t th e transmissio n o r star t th e engine ,
th e vehicl e mus t b e transporte d o n a flat-bed .
I t i s bes t t o to w th e vehicl e n o farthe r tha n 5 0 mile s
(8 0 km) , an d kee p th e spee d belo w 35 mp h (5 5 km/h) .
CAUTION : Tryin g to lif t o r to w th e vehicl e b y th e bumper s
wil l caus e seriou s damage . Th e bumper s ar e no t designe d
t o suppor t th e vehicle' s weight .
Front:
TOWIN G HOOK S an dTIE DOW N BRACKET S
Rear:
TIE DOW N BRACKE T
ProCarManuals.com

Service Precautions

Handling of Special Nuts and Bolts

Because the front sub frame sections on this vehicle are

constructed with aluminum alloys, use only the special

"Dacro" type nuts and bolts recommended by Acura.

NOTE:

Dacro finish can be identified by gray plating.

Some Dacro finish bolts have a green coating on the

thread section of the bolt for easier application. This

type of bolt is called a "Torquer" bolt.

Use of other types of nuts and bolts may cause elec-

trolysis and corrosion which in turn could cause the

bolt to loosen.

Gray plating

Green coating

on the threads

of some bolts.

Gray plating: "Dacro" type

Gray plating + Green coating on the threads:

"Torquer" type
1. When replacing nuts and bolts, use only the same

type.

2. Tighten the nuts and bolts with a torque wrench to

the specifications provided in this manual.

3. Clean all thread ridges with a non-wire-type bristle

brush. Foreign matter in the threads may cause the

bolt to loosen.

4. Sections on this vehicle requiring the use of Dacro

nuts and bolts will be indicated by a ( ) in this

manual.ProCarManuals.com
