1996 ACURA RL KA9 Service Repair Manual

PCM Memory Setting

NOTE: The PCM reset procedure and disconnecting the

battery or the BACK UP RADIO (7.5 A) fuse cancels the

PCM memory for idle control. The following procedure

is needed after the PCM reset procedure and reconnect-

ing the battery or the BACK UP RADIO (7.5 A) fuse.

1. Start the engine. Hold the engine at 3,000 rpm with

no load (in Park or neutral) until the radiator fan

comes on.

2. Let the engine idle for approx. 5 minutes under the

following conditions:

• Transmission in Park or neutral

• A/C switch OFF

• Headlights OFF

• Rear defogger OFFProCarManuals.com

Fuel Supply System

Fuel Lines

Check fuel system lines, hoses, fuel filter, and other components for damage, leaks or deterioration, and replace if neces-

sary.

'96 - 99 models:

22 N-m

(2.2 kgf-m, 16 Ibf-ft)
22 N-m

(2.2 kgf-m,

16 Ibf-ft)

'00 - 01 models:
37 N-m

(3.8 kgf-m, 27 Ibf-ft)

22 N-m

(2.2 kgf-m, 16 Ibf-ft)
22 N-m

(2.2 kgf-m

16 Ibf-ft)

37 N-m

(3.8 kgf-m, 27 Ibf-ft)ProCarManuals.com

'96 - 99 models:

Check all hose clamps and retighten if necessary.

EVAPORATIVE EMISSION

(EVAP) TWO WAY VALVE

EVAPORATIVE EMISSION

(EVAP) CONTROL

CANISTER

10 -
15
mm

(0.39
-
0.59
in)
Clamp in the middle.
Clamp in the middle.
FUEL

TANK
FUEL

FILTER
To

FUEL

PRESSURE

REGULATOR
BASE

GASKET

Replace.
BASE GASKET

Replace.
FUEL PUMP

ASSEMBLY
FUEL GAUGE SENDING

UNIT ASSEMBLY

FUEL TANK EVAPORATIVE

EMISSION (EVAP)

VALVEProCarManuals.com
