1996 ACURA RL KA9 Service Repair Manual

Pistons
Inspectio n
1. Chec k th e pisto n fo r distortio n o r cracks .
2. Measur e th e pisto n diamete r a t a poin t 14. 0 m m
(0.5 5 in ) fro m th e botto m of th e skirt .
NOTE : Ther e ar e tw o standard-siz e piston s (N o let -
te r o r A , an d B) . Th e lette r i s stampe d o n th e to p o f
th e piston . Letter s ar e als o stampe d o n th e cylinde r
bloc k a s cylinde r bor e sizes .
Standar d Pisto n Diamete r
Oversiz e Pisto n Diamete r
0.25 : 90.23 0 - 90.24 0 m m (3.552 4 - 3.552 7 in )
0.50 : 90.48 0 - 90.49 0 m m (3.562 2 - 3.562 6 in )
SKIR T DIAMETE R14.0 mm(0.5 5 in)
89.98 0 - 89.99 0 m m
(3.542 5 - 3.542 9 in )
89.97 0 - 89.98 0 m m
(3.5421 - 3.542 5 in )
B
No Lette r
(A)
89.97 0 m m
(3.542 1 in )
Servic
e Limi t
89.96 0 m m
(3.541 7 in ) 3
. Calculat e th e differenc e betwee n cylinde r bor e diame -
te r (se e pag e 7-15 ) an d pisto n diameter .
Piston-to-Bloc k Clearanc e
Standar d (New) : 0.0 2 - 0.0 4 m m
(0.00 1 - 0.00 2 in )
Servic e Limit : 0.0 8 m m (0.00 3 in )
SERVIC E LIMI T0.08 m m (0.00 3 in )
ProCarManuals.com

Cylinder Bloc k
Inspectio n
1. Measur e wea r an d tape r i n direction s X an d Y at
thre e level s i n eac h cylinde r a s shown .
CYLINDE R BOR E SIZE S ( A o r I , B or Il )NOTE : T o maintai n prope r pisto n
clearance , matc h thes e letter s wit h
the letter s o n th e pistons . Th e let -ters o n th e bloc k rea d fro m fron t t orear . No . 1 throug h No . 3 cylinder son th e firs t line , an d No . 4 throug hNo. 6 cylinder s o n th e secon d line .
CYLINDE RBOREGAUG E
Cylinde r Bor e Siz e
Standar d (New ) Service Limi t
90.07 0 m m
(3.546 1 in )
90.07 0 m m
(3.546 1 in )
90.01
0 - 90.02 0 m m
(3.543 7 - 3.544 1 in )
90.00 0 - 90.01 0 m m
(3.543 3 - 3.543 7 in )
B o r Il
A o r I
Oversiz e
0.25: 90.25 0 - 90.27 0 m m (3.553 1 - 3.553 9 in )
0.50 : 90.50 0 - 90.52 0 m m (3.563 0 - 3.563 8 in )
Bor e Tape r
Limit : (Differenc e betwee n firs t an d thir d measure -
ment ) 0.0 5 m m (0.00 2 in )
Reborin g Limit : 0. 5 m m (0.0 2 in )
• I f measurement s i n an y cylinde r ar e beyon d th e
oversiz e bor e servic e limit , replac e th e cylinde r
block.
• I f th e bloc k i s t o b e rebored , refe r t o Pisto n Clear -
anc e Inspectio n (se e pag e 7-14 ) afte r reboring .
NOTE : Score d o r scratche d cylinde r bore s mus t b e
honed .
2 . Chec k th e to p o f th e cylinde r bloc k fo r warpage .
Measur e alon g th e edge s an d acros s th e cente r a s
shown .
SURFACE S T O B E MEASURE D
Cylinder Bloc k Warpage :
Standar d (New) : 0.0 7 m m (0.00 3 in ) max .
Servic e Limit : 0.1 0 m m (0.00 4 in )
PRECISIO N STRAIGH T EDG E
ProCarManuals.com

Cylinder Bloc k
Bore Honin g
1. Measur e th e cylinde r bore s a s show n o n pag e 7-15 .
I f th e cylinde r bloc k i s t o b e reused , hon e th e cylin -
der s an d remeasur e th e bores .
2 . Hon e th e cylinde r bore s wit h honin g oi l an d a fin e
(40 0 grit ) ston e in a 60 degre e crosshatc h pattern .
NOTE:
• Us e onl y a rigi d hon e wit h a 40 0 gri t o r fine r
stone , suc h a s Sunnen , Ammco , o r equivalent .
• D o no t us e stone s tha t ar e wor n o r broken .
3 . Whe n honin g i s complete , thoroughl y clea n th e
cylinde r bloc k o f al l meta l particles . Was h th e cylin -
de r bore s wit h ho t soap y water , the n dr y an d oi l
the m immediatel y t o preven t rusting .
NOTE : Neve r us e solvent , i t wil l onl y redistribut e
th e gri t o n th e cylinde r walls .
4 . I f scorin g o r scratche s ar e stil l presen t i n th e cylin -
de r bore s afte r honin g t o th e servic e limit , rebor e
th e cylinde r block .
NOTE : Som e ligh t vertica l scorin g an d scratchin g is
acceptabl e if i t i s no t dee p enoug h t o catc h you r fin -
gernai l an d doe s no t ru n th e ful l lengt h o f th e bore .
CYLINDE R BLOC KCYLINDE R HON E(Commerciall y available )
NOTE:
• Afte r honing , clea n th e cylinde r thoroughl y wit h
ho t soap y water .
• Onl y score d o r scratche d cylinde r bore s mus t b e
honed .
ProCarManuals.com

Piston Pins

Removal

1. Apply engine oil to the piston pin snap rings, and

turn them in the ring grooves until the end gaps are

lined up with the cutouts in the piston pin bores.

NOTE: Take care not to damage the ring grooves.

SNAP RING

Cutout in the

piston pin bore

2. Remove both snap rings. Start at the cutout in the

piston pin bore.

NOTE: Remove the snap rings carefully so they do

not go flying or get lost. Wear eye protection.

SNAP RINGProCarManuals.com
