1996 ACURA RL KA9 Service Repair Manual

Troubleshooting
Barometric Pressur e (BARO ) Signa l
Diagnosti c Troubl e Cod e (DTC ) 3-5 : Barometri c Pressur e (BARO ) Signa l Diagnosi s
With engin e running , TC S indi -cato r ligh t i s ON .MIL is OFF .With th e SC S servic e connec -
to r connecte d (se e pag e
19-159 ), DT C 3- 5 is indicated .
Chec k fo r a shor t t o bod y groun d
i n th e BAR O circuit :
1 . Disconnec t th e PC M connecto r
D (22P ) an d TC S contro l uni t20P connectors .2. Chec k fo r continuit y betwee n
th e PC M connecto r D (22P ) ter -
mina l No . 3 an d bod y ground .
I s ther e continuity ?
Chec k th e BAR O circui t insid e
the PCM :1. Connec t th e PC M connecto rD (22P) .2. Tur n th e ignitio n switc h O N (II) .3. Measur e th e voltag e betwee n
th e PC M connecto r D (22P ) ter -
mina l No . 3 an d bod y ground .
I s ther e abou t 3 V ?
Chec k fo r a n ope n i n th e BAR Ocircuit :Measur e th e voltag e betwee n th eTC S contro l uni t 20 P connecto rterminal No . 1 3 an d bod y ground .
I s ther e abou t 3 V ?
Th e syste m is O K at thi s time .If th e proble m recurs , replac e
th e TC S contro l unit . NOTE
: Whe n bot h th e TC S indicato r
light an d th e MI L ar e ON , troubleshoo tthe PGM-F I syste m first .
PCM CONNECTO R D (22P )
Wir e sid e o f femal e terminal s
Repai r shor t t o bod y groun d in
th e wir e betwee n th e PC M an d
TC S contro l unit .
Chec k fo r loos e PC M connectors .If necessary , substitut e a known -good PC M an d recheck .
TCS CONTRO L UNI T 20 P CONNECTO R
Repai r ope n in th e wir e betwee n
th e PC M an d TC S contro l unit . Wir
e sid e o f femal e terminal s
