Page 1465 of 2389

TOYOTA CAMRY V20 1986 Service Information Bad Example: Terminal in Short Position Terminal Locking Clip Terminal Retainer [Case 1] Full Lock Position [Case 2] Full Lock Position Terminal Locking ClipTerminal Retainer at Temporary Lock Posi

Page 1466 of 2389

TOYOTA CAMRY V20 1986 Service Information Bad Example: Terminal in Short Position Terminal Locking Clip [Case 1] Full Lock Position [Case 2] Full Lock Position B±37 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 47 Wire Harness Repair M

Page 1467 of 2389

TOYOTA CAMRY V20 1986 Service Information Temporary Lock Position Full Lock Position Terminal Retainer TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±38 48 Wire Harness Repair Manual (RM1022E) Type C (For 0.64 Type Connector) (a)Inse

Page 1468 of 2389

TOYOTA CAMRY V20 1986 Service Information Upper lock Lower lock Rear Holder Housing rear endRear Holder B±39 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 49 Wire Harness Repair Manual (RM1022E) (b)Verify that Rear Holder is at unlocke

Page 1469 of 2389

TOYOTA CAMRY V20 1986 Service Information Lock check position, upper Lock normal engagement position Incomplete lock engagement TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±40 50 Wire Harness Repair Manual (RM1022E) Verify that the

Page 1470 of 2389

TOYOTA CAMRY V20 1986 Service Information Lock normal engagement position Incomplete lock engagement Lock check position, lower Insert Special Tool Special Tool hole (U shaped) B±41 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 51 Wir

Page 1471 of 2389

TOYOTA CAMRY V20 1986 Service Information TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±42 52 Wire Harness Repair Manual (RM1022E) (g)Verify that Terminal retainer is inserted to the specified position. NOTICE: If Terminal retainer

Page 1472 of 2389

TOYOTA CAMRY V20 1986 Service Information A A AB B±43 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 53 Wire Harness Repair Manual (RM1022E) SPECIAL EXAMPLE First fit the section A. Install the lock of the section A first. Install th
