Page 1433 of 2389

TOYOTA CAMRY V20 1986 Service Information TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±4 14 Wire Harness Repair Manual (RM1022E) Step 1. Identify the connector and the terminal type. Confirm whether the connector you require is the

Page 1434 of 2389

TOYOTA CAMRY V20 1986 Service Information Example: Back of the Connector Body P/N 90980±10854 B±5 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 15 Wire Harness Repair Manual (RM1022E) NOTICE: When the terminal used is gold plated, b

Page 1435 of 2389

TOYOTA CAMRY V20 1986 Service Information Hole Plug Connector Body Terminal Packing Small (Red) Large (Yellow) Medium (Blue) Medium (Blue) 1.0±2.0 mm Large (Yellow) 3.0±5.0 mmWire Outside DiameterSleeve Size (Color) Small (Red) 0.2±1.0 mm

Page 1436 of 2389

TOYOTA CAMRY V20 1986 Service Information 0.3 0.5 0.85 1.25 2 3 5S M M M M L L 0.3 M M M M M L L 0.5 M M M M L L L 0.85 M M M M L L L 1.25 M M L L L L ±±2 L L L L L L ±±3 L L L L ±± ±± ±±5 * Nominal size of the wire ** Twist EvenlyC

Page 1437 of 2389

TOYOTA CAMRY V20 1986 Service Information Example: Press DownPress DownPull Up Pull Up Refereance: (mm) Example: Up Tool Terminal Retainer TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±8 18 Wire Harness Repair Manual (RM1022E) Step 2

Page 1438 of 2389

TOYOTA CAMRY V20 1986 Service Information Raise Up Terminal RetainerSpecial Tool Terminal Retainer [Retainer at Full Lock Position] Stopper [Retainer at Temporary Lock Position]Terminal Retainer Good Bad Good Bad [Male] [Female] Special Tool

Page 1439 of 2389

TOYOTA CAMRY V20 1986 Service Information Access Hole Ta b Open * * * *Open [Male][Female] * Double Locking Device. Retainer Side Lock TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±10 20 Wire Harness Repair Manual (RM1022E) (1)Press

Page 1440 of 2389

TOYOTA CAMRY V20 1986 Service Information Special tool Lock * * * * * Double Locking Device.Special Tool B±11 TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT 21 Wire Harness Repair Manual (RM1022E) (2)Inset the special tool into the chin
