LIGHTING – BACK DOOR COURTESY SWITCHLI–145
LI
INSTALLATION
HINT:
• Use the same procedures for the RH and LH sides.
• The procedures listed below are for the LH side.
• A bolt without a torque specification is shown in the
standard bolt chart (see page SS-2).
1. INSTALL BACK DOOR COURTESY LIGHT SWITCH
ASSEMBLY
(a) Connect the connector.
(b) Install the switch with the bolt.
2. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
B131446
Page 1890 of 2000

WW–10WIPER AND WASHER – FRONT WIPER MOTOR AND LINK
WW
INSPECTION
1. INSPECT WINDSHIELD WIPER MOTOR ASSEMBLY
(a) Check the LO operation.
(1) Connect the battery's positive (+) lead to
terminal 5 (+1) and the negative (-) lead to
terminal 4 (E), and check that the motor
operates at low speed (LO).
OK:
Motor operates at low speed (LO).
(b) Check the HI operation.
(1) Connect the battery's positive (+) lead to
terminal 3 (+2) and the negative (-) lead to
terminal 4 (E), and check that the motor
operates at high speed (HI).
OK:
Motor operates at high speed (HI).
(c) Check the automatic stop operation.
(1) Connect the battery's positive (+) lead to
terminal 5 (+1) and the negative (-) lead to
terminal 4 (E). With the motor rotating at low
speed (LO), disconnect terminal 5 (+1) to stop
the wiper motor operation at any position other
than the automatic stop position.
(2) Using SST, connect terminals 1 (+S) and 5
(+1). Then connect the battery's positive (+)
lead to terminal 2 (B) and the negative (-) lead
to terminal 4 (E) to restart the motor operation
at low speed (LO).
SST 09843-18040
(3) Check that the motor stops automatically at the
automatic stop position.
OK:
Refer to illustration.
If the result is not as specified, replace the
motor assembly.
INSTALLATION
1. INSTALL WINDSHIELD WIPER MOTOR ASSEMBLY
(a) Install the wiper motor with the 3 bolts.
Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
E034081E21
B131458E01
B136374
Page 1891 of 2000
WIPER AND WASHER – FRONT WIPER MOTOR AND LINKWW–11
WW
(b) Align the matchmarks on the crank arm and motor.
(c) Apply MP grease to the sliding parts of the wiper
motor and the rod of the wiper link.
(d) Connect the rod of the wiper link to the wiper motor.
2. INSTALL WINDSHIELD WIPER MOTOR AND LINK
ASSEMBLY
(a) Move the wiper motor and link in the direction
shown by the arrow in the illustration to attach the
wiper cushion to the body, and install the wiper
motor and link.
(b) Install the 2 bolts.
Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
(c) Connect the connector.
3. INSTALL COWL TOP VENTILATOR LOUVER
(a) Attach the 12 claws to install the louver.
(b) Install the 2 clips.
4. INSTALL FRONT FENDER TO COWL SIDE SEAL LH
(a) Attach the claw to install the front fender to cowl
side seal.
5. INSTALL FRONT FENDER TO COWL SIDE SEAL RH
(a) Attach the claw to install the front fender to cowl
side seal.
B131466E01
B133583E01
B131453
E125248E01
B133588
Page 1892 of 2000
WW–12WIPER AND WASHER – FRONT WIPER MOTOR AND LINK
WW
6. INSTALL FRONT WIPER ARM AND BLADE
ASSEMBLY RH
(a) Stop the wiper motor at the automatic stop position.
(b) Clean the wiper arm serration with a round file or
equivalent.
(c) Clean the wiper pivot serration with a wire brush.
(d) Install the arm and blade with the nut. Make sure
that the arm and blade comes to the position shown
in the illustration.
Torque: 21 N*m (214 kgf*cm, 23 ft.*lbf)
HINT:
Hold down the arm hinge with your hand while
tightening the nut.
7. INSTALL FRONT WIPER ARM AND BLADE
ASSEMBLY LH
(a) Clean the wiper arm serration with a round file or
equivalent.
(b) Clean the wiper pivot serration with a wire brush.
E058837E07
B133593E01
E058837E07
Page 1893 of 2000
WIPER AND WASHER – FRONT WIPER MOTOR AND LINKWW–13
WW
(c) Install the arm and blade with the nut. Make sure
that the arm and blade comes to the position shown
in the illustration.
Torque: 21 N*m (214 kgf*cm, 23 ft.*lbf)
HINT:
Hold down the arm hinge with your hand while
tightening the nut.
(d) Operate the front wipers while spraying water or
washer fluid on the windshield. Ensure that there is
no interference between the blades and pillar.
8. INSTALL FRONT WIPER ARM HEAD CAP
(a) Install the 2 caps.
9. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
B133594E01
Page 1894 of 2000
WW–20WIPER AND WASHER – REAR WIPER MOTOR
WW
(d) Remove the nut and arm and blade.
7. REMOVE REAR WIPER MOTOR GROMMET
8. REMOVE REAR WIPER MOTOR ASSEMBLY
(a) Disconnect the connector.
(b) Remove the 3 bolts and wiper motor.
INSPECTION
1. INSPECT REAR WIPER MOTOR
(a) Connect the battery's positive (+) lead to terminal 3
(+B) and the negative (-) lead to terminal 1 (LS).
(b) Check that the rear wiper motor operates.
OK:
Rear wiper motor operates.
NOTICE:
Check that the body ground is connected.
If the result is not as specified, replace the motor.
INSTALLATION
1. INSTALL REAR WIPER MOTOR ASSEMBLY
(a) Install the wiper motor with the 3 bolts.
Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
(b) Connect the connector.
2. INSTALL REAR WIPER MOTOR GROMMET
3. INSTALL REAR WIPER ARM AND BLADE
ASSEMBLY
(a) Stop the wiper motor at the automatic stop position.
B131464
B131460
E118528E01
B131460
Page 1895 of 2000
WIPER AND WASHER – REAR WIPER MOTORWW–21
WW
(b) Clean the wiper arm serration with a round file or
equivalent.
(c) Clean the wiper pivot serration with a wire brush.
(d) Install the arm and blade with the nut. Make sure
that the arm and blade comes to the position shown
in the illustration.
Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
HINT:
• Hold down the arm hinge by hand while
tightening the nut.
• Install the arm and blade so that the rear wiper
blade is aligned with the ceramic line.
(e) Install the cap.
4. INSTALL BACK DOOR TRIM BOARD ASSEMBLY
(See page ED-66)
5. INSTALL BACK DOOR SIDE GARNISH RH (See page
ED-67)
6. INSTALL BACK DOOR SIDE GARNISH LH (See page
ED-67)
7. INSTALL BACK DOOR CENTER GARNISH (See page
ED-67)
8. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
B117856E03
E125268E03
B136379
Page 1896 of 2000

WIPER AND WASHER – WIPER SWITCHWW–27
WW
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
2. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
3. REMOVE STEERING PAD ASSEMBLY (See page RS-
336)
4. REMOVE STEERING WHEEL ASSEMBLY (See page
SR-12)
5. REMOVE STEERING COLUMN COVER UPPER (See
page SR-12)
6. REMOVE STEERING COLUMN COVER LOWER (See
page SR-12)
7. REMOVE WIPER AND WASHER SWITCH ASSEMBLY
(a) Disconnect the connectors.
(b) Detach the claw and remove the wiper switch.
NOTICE:
Do not push the claw with excessive force as
damage may occur.
INSPECTION
1. INSPECT WINDSHIELD WIPER SWITCH ASSEMBLY
(a) Check the front wiper switch.
(1) Measure the resistance of the switch.
Standard resistance
If the result is not as specified, replace the
switch assembly.
(b) Check the front washer switch assembly.
(1) Measure the resistance of the switch.
Standard resistance
If the result is not specified, replace the switch
assembly.
B133131
E124704E01
Tester Connection Switch Condition Specified Condition
E10-1 (+S) - E10-3 (+1) INT Below 1
OFF
E10-2 (B) - E10-3 (+1) MIST
LO
E10-2 (B) - E10-4 (+2) HI
Tester Connection Switch Condition Specified Condition
E9-2 (EW) - E9-3 (WF) ON Below 1
OFF 10 k or higher
