Page 1425 of 2000

TOYOTA RAV4 2006 Service Repair Manual DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLYDF–21 DF DISASSEMBLY 1. FIX DIFFERENTIAL CARRIER SUB-ASSEMBLY (a) Fix the rear differential carrier in place with the overhaul attachment. 2. RE

Page 1426 of 2000

TOYOTA RAV4 2006 Service Repair Manual DF–22DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLY DF 7. INSPECT RUNOUT OF TRANSMISSION COUPLING ASSEMBLY (a) Install a dial gauge so that it is perpendicular to the inner side of the tran

Page 1427 of 2000

TOYOTA RAV4 2006 Service Repair Manual DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLYDF–23 DF 10. REMOVE YOKE (a) Using a 5 mm socket hexagon wrench, remove the 3 bolts and yoke from the differential carrier. 11. REMOVE TRANSMISS

Page 1428 of 2000

TOYOTA RAV4 2006 Service Repair Manual DF–24DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLY DF 14. INSPECT DIFFERENTIAL DRIVE PINION PRELOAD (a) Using SST and a torque wrench, inspect the preload (starting torque) within the diffe

Page 1429 of 2000

TOYOTA RAV4 2006 Service Repair Manual DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLYDF–25 DF 18. REMOVE DRIVE PINION NUT (a) Using SST and a hammer, unstake the rear drive pinion nut. SST 09930-00010 NOTICE: • Use SST with the

Page 1430 of 2000

TOYOTA RAV4 2006 Service Repair Manual DF–26DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLY DF 21. REMOVE DIFFERENTIAL CASE SUB-ASSEMBLY (a) Remove the rear differential case from the rear differential carrier. 22. REMOVE DIFFEREN

Page 1431 of 2000

TOYOTA RAV4 2006 Service Repair Manual DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLYDF–27 DF 26. REMOVE REAR DRIVE PINION REAR TAPERED ROLLER BEARING (a) Using a brass bar and hammer, lightly and uniformly tap out the rear driv

Page 1432 of 2000

TOYOTA RAV4 2006 Service Repair Manual DF–28DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLY DF HINT: If the race is remains on the rear differential case, repeat the step above to remove the race. 29. REMOVE DIFFERENTIAL RING GEAR
