Page 1449 of 2000

DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLYDF–45
DF
(d) Slowly raise the transmission jack, fix the nuts in
place and install the 3 bolts.
Torque: 86 N*m (877 kgf*cm, 63 ft.*lbf) for bolt A
140 N*m (1,428 kgf*cm, 103 ft.*lbf) for
bolt B
NOTICE:
Tighten the bolts, not the nuts.
(e) Connect the connector.
(f) Install the breather tube.
(g) Connect the harness clamp.
4. INSTALL REAR SUSPENSION MEMBER BRACE LH
(a) Install the member brace to the suspension member
with the 2 bolts.
Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf)
5. INSTALL REAR SUSPENSION MEMBER BRACE RH
HINT:
Use the same procedures described for the LH side.
6. TEMPORARILY INSTALL PROPELLER WITH
CENTER BEARING SHAFT ASSEMBLY (See page
PR-5)
7. TIGHTEN PROPELLER WITH CENTER BEARING
SHAFT ASSEMBLY (See page PR-6)
8. INSPECT JOINT ANGLE (See page PR-4)
9. INSTALL CENTER EXHAUST PIPE ASSEMBLY (See
page EX-5)
10. INSTALL TAILPIPE ASSEMBLY (See page EX-6)
11 . I N S TA L L R E A R WH E E L
Torque: 103 N*m (1,050 kgf*cm, 76 ft.*lbf)
12. ADD DIFFERENTIAL OIL
(a) Add differential oil (see page DF-3).
13. CHECK FOR DIFFERENTIAL OIL LEAKAGE
14. CHECK FOR EXHAUST GAS LEAKAGE
If gas is leaking, tighten the areas necessary to stop the
leak. Replace damaged parts as necessary.
C129479E01
C127575
Page 1450 of 2000

AXLE – FRONT AXLE HUBAH–9
AH
REMOVAL
(2006/01- )
HINT:
• Use the same procedures for the RH side and LH side.
• The procedures listed below are the LH side.
1. REMOVE FRONT WHEEL
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Drain the automatic transaxle fluid for U140F (see
page AX-147).
(b) Drain the automatic transaxle fluid for U241E (see
page AX-146).
(c) Drain the automatic transaxle fluid for U151E (see
page AX-172).
(d) Drain the automatic transaxle fluid for U151F (see
page AX-173).
3. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
4. REMOVE FRONT AXLE HUB LH NUT
(a) Using SST and a hammer, unstake the staked part
of the nut.
SST 09930-00010
NOTICE:
Loosen the staked part of the nut completely,
otherwise the screw of the drive shaft may be
damaged.
(b) While applying the brakes, remove the lock axle hub
nut.
5. REMOVE FRONT SPEED SENSOR LH (See page BC-
191)
6. REMOVE FRONT DISC BRAKE CYLINDER
ASSEMBLY LH (See page BR-40)
7. REMOVE FRONT DISC (See page BR-42)
8. DISCONNECT TIE ROD END SUB-ASSEMBLY LH
(See page PS-42)
9. DISCONNECT FRONT SUSPENSION NO. 1 LOWER
ARM SUB-ASSEMBLY LH
(a) Remove the bolt and 2 nuts.
(b) Disconnect the lower arm from the ball joint.
C129483E01
C127531
Page 1451 of 2000
AH–10AXLE – FRONT AXLE HUB
AH
10. REMOVE STEERING KNUCKLE WITH AXLE HUB
(a) Remove the 2 bolts and 2 nuts, and disconnect the
shock absorber from the steering knuckle.
HINT:
While fixing the nuts in place, loosen and remove
the bolts.
(b) Put matchmarks on the drive shaft and axle hub.
(c) Using a plastic-faced hammer, remove the steering
knuckle with axle hub.
NOTICE:
Be careful not to damage the boot and speed
sensor rotor. Do not excessively push out the
drive shaft from the axle assembly.
11. REMOVE FRONT LOWER BALL JOINT ASSEMBLY
LH (See page SP-27)
12. REMOVE FRONT AXLE HUB SUB-ASSEMBLY LH
(a) Remove the 4 bolts and axle hub from the steering
knuckle.
NOTICE:
Do not place the hub and bearing's magnet rotor
side so that it is facing downward, and do not
allow the magnet rotor side to become damaged
or contact foreign matter.
(b) Remove the dust cover from the steering knuckle.
C127533
C129488E01
C127536
Page 1452 of 2000

AXLE – FRONT AXLE HUBAH–11
AH
INSTALLATION
(2005/11-2006/01)
HINT:
• Use the same procedures for the RH side and LH side.
• The procedures listed below are for the LH side.
1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH
(a) Install the dust cover to the steering knuckle.
(b) Install the axle hub with the 4 bolts.
Torque: 96 N*m (979 kgf*cm, 1 ft.*lbf)
NOTICE:
Do not place the hub and bearing's magnet rotor
side so that it is facing downward, and do not
allow the magnet rotor side to become damaged
or contact foreign matter.
2. INSTALL FRONT LOWER BALL JOINT ASSEMBLY
LH (See page SP-28)
3. INSTALL STEERING KNUCKLE WITH AXLE HUB
(a) Align the shaft splines and drive in the drive shaft.
(b) Install the steering knuckle with axle hub with the 2
bolt and 2 nuts.
Torque: 240 N*m (2,447 kgf*cm, 177 ft.*lbf)
NOTICE:
Do not tighten the nuts.
4. CONNECT FRONT SUSPENSION NO. 1 LOWER ARM
SUB-ASSEMBLY LH
(a) Connect the lower arm to the ball joint with the 2
bolts and nut.
Torque: 92 N*m (938 kgf*cm, 68 ft.*lbf)
5. CONNECT TIE ROD END SUB-ASSEMBLY LH (See
page PS-45)
6. INSTALL FRONT SPEED SENSOR LH (See page BC-
193)
7. CHECK FRONT AXLE HUB BEARING
(a) Check the axle hub bearing (see page AH-6).
8. INSTALL FRONT DISC (See page BR-43)
9. INSTALL FRONT DISC BRAKE CYLINDER
ASSEMBLY LH (See page BR-46)
10. INSTALL FRONT AXLE HUB NUT
(a) Install a new hub nut.
Torque: 216 N*m (2,203 kgf*cm, 159 ft.*lbf)
C127536
Page 1453 of 2000
AH–12AXLE – FRONT AXLE HUB
AH
(b) Using a chisel and hammer, stake the hub nut.
11. INSTALL FRONT WHEEL
Torque: 103 N*m (1,050 kgf*cm, 6 ft.*lbf)
12. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT
(a) Inspect and adjust the wheel alignment (see page
SP-3).
13. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
14. CHECK SPEED SENSOR SIGNAL
(a) Check the speed sensor signal (see page BC-44).
C129484
Page 1454 of 2000

AXLE – FRONT AXLE HUBAH–13
AH
INSTALLATION
(2006/01- )
HINT:
• Use the same procedures for the RH side and LH side.
• The procedures listed below are the LH side.
1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH
(a) Install the dust cover to the steering knuckle.
(b) Install the axle hub with the 4 bolts.
Torque: 96 N*m (979 kgf*cm, 71 ft.*lbf)
NOTICE:
Do not place the hub and bearing's magnet rotor
side so that it is facing downward, and do not
allow the magnet rotor side to become damaged
or contact foreign matter.
2. INSTALL FRONT LOWER BALL JOINT ASSEMBLY
LH (See page SP-28)
3. INSTALL STEERING KNUCKLE WITH AXLE HUB
(a) Align the shaft splines and drive in the drive shaft.
(b) Install the steering knuckle with axle hub with the 2
bolts and 2 nuts.
Torque: 240 N*m (2,447 kgf*cm, 177 ft.*lbf)
NOTICE:
Do not tighten the bolts.
4. CONNECT FRONT SUSPENSION NO. 1 LOWER ARM
SUB-ASSEMBLY LH
(a) Connect the lower arm to the ball joint with the bolt
and 2 nuts.
Torque: 92 N*m (938 kgf*cm, 68 ft.*lbf)
5. CONNECT TIE ROD END SUB-ASSEMBLY LH (See
page PS-45)
6. INSTALL FRONT SPEED SENSOR LH (See page BC-
193)
7. CHECK FRONT AXLE HUB BEARING
(a) Check the axle hub bearing (see page AH-6).
8. INSTALL FRONT DISC (See page BR-43)
9. INSTALL FRONT DISC BRAKE CYLINDER
ASSEMBLY LH (See page BR-46)
10. INSTALL FRONT AXLE HUB LH NUT
(a) Install a new hub nut.
Torque: 216 N*m (2,203 kgf*cm, 159 ft.*lbf) for
26 for 2AZ-FE
292 N*m (2,978 kgf*cm, 215 ft.*lbf) for
30 for 2GR-FE
C127536
Page 1455 of 2000
AH–14AXLE – FRONT AXLE HUB
AH
(b) Using a chisel and hammer, stake the hub nut.
11. ADD AUTOMATIC TRANSAXLE FLUID
(a) Add the automatic transaxle for U140F (see page
AX-152).
(b) Add the automatic transaxle for U241E (see page
AX-151).
(c) Add the automatic transaxle for U151E (see page
AX-177).
(d) Add the automatic transaxle for U151F (see page
AX-178).
12. CHECK FOR AUTOMATIC TRANSAXLE FLUID
LEAKAGE
13. INSTALL FRONT WHEEL
Torque: 103 N*m (1,050 kgf*cm, 76 ft.*lbf)
14. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT
(a) Inspect and adjust the front wheel alignment (see
page SP-3).
15. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
16. CHECK SPEED SENSOR SIGNAL
(a) Check the speed sensor signal (see page BC-44).
C129484
Page 1456 of 2000

AH–16AXLE – REAR AXLE HUB AND BEARING
AH
ON-VEHICLE INSPECTION
1. REMOVE REAR WHEEL
2. DISCONNECT REAR DRIVE SHAFT ASSEMBLY LH
(for 4WD)
(a) Disconnect the drive shaft (see page DS-69).
3. REMOVE REAR DISC BRAKE CYLINDER ASSEMBLY
LH (See page BR-55)
4. REMOVE REAR DISC (See page BR-57)
5. CHECK BEARING BACKLASH AND AXLE HUB
DEVIATION
(a) Using a dial indicator, measure the backlash near
the center of the axle hub.
Maximum backlash:
0.05 mm (0.0020 in.)
If the backlash is greater than the maximum,
replace the axle hub.
(b) Using a dial indicator, measure the disc runout 10
mm (0.39 in.) inside the outer edge of the disc.
Maximum deviation:
0.08 mm (0.0031 in.) for 2WD
0.06 mm (0.0024 in.) for 4WD
NOTICE:
If the runout exceeds the maximum, change the
installation positions of the rear disc and axle
hub so that the runout will be as low as
possible. If the runout exceeds the maximum
even when the installation positions are
changed, shave the rear disc. If the rear disc
needs to be shaved to less than the minimum,
replace the rear disc. If the rear disc is replaced,
perform the runout inspection again. If the
runout still exceeds the maximum, replace the
hub and bearing with a new one.
C141999
C129314
