Page 1361 of 2000

TOYOTA RAV4 2006 Service Repair Manual GF1A TRANSFER – ACTIVE TORQUE CONTROL 4WD SYSTEMTF–33 TF DESCRIPTION The 4WD control ECU receives signals from each sensor to control clutch fluid pressure for limiting the center differential

Page 1362 of 2000

TOYOTA RAV4 2006 Service Repair Manual TF–34GF1A TRANSFER – ACTIVE TORQUE CONTROL 4WD SYSTEM TF (a) Disconnect the E57 ECU connector. (b) Measure the resistance of the wire harness side connector. Standard resistance NG OK 2CHECK

Page 1363 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD)DS–7 DS REMOVAL (2005/11-2006/01) 1. REMOVE FRONT WHEEL 2. DRAIN AUTOMATIC TRANSAXLE FLUID (a) Drain the automatic transaxle fluid for U140F (se

Page 1364 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–8DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD) DS 14. DISCONNECT TIE ROD END SUB-ASSEMBLY LH (See page PS-42) 15. DISCONNECT TIE ROD END SUB-ASSEMBLY RH HINT: Use the same procedures de

Page 1365 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD)DS–9 DS REMOVAL (2006/01- ) 1. REMOVE FRONT WHEEL 2. DRAIN AUTOMATIC TRANSAXLE FLUID (a) Drain the automatic transaxle fluid for U140F (se

Page 1366 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–10DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD) DS 13. DISCONNECT STEERING KNUCKLE WITH AXLE HUB RH HINT: Use the same procedures described for the LH side. 14. DISCONNECT TIE ROD END S

Page 1367 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD)DS–11 DS DISASSEMBLY (2005/11-2006/01) 1. REMOVE FRONT AXLE INBOARD JOINT BOOT NO. 2 CLAMP LH (a) One touch type: (1) Using a screwdriver, remo

Page 1368 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–12DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 2WD) DS (d) Using a snap ring expander, remove the shaft snap ring. (e) Put matchmarks on the outboard joint shaft and tripod joint. NOTICE:
