(g) Install a new transaxle housing oil seal RH.
(1) Coat the lip of a new oil seal with MP grease.
(2) Using SST and a hammer, tap in the oil seal.
SST 09309-37010
Standard depth:
6.0 +-0.5 mm (0.236 +-0.020 in.)
(h) Install the transfer assembly (see page TF-75).
(i) Install the engine mount bracket RR with the 3 bolts.
Torque: 64 N*m (652 kgf*cm, 47 ft.*lbf)
(j) Install the drive shaft bearing bracket with the 3
bolts.
Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf)
(k) Install the engine with transaxle (see page EM-105).
(l) Add automatic transaxle fluid.
Fluid type:
Toyota Genuine ATF WS
(m) Inspect the fluid level (see page AX-102).
D025837E01
Page 978 of 2000
AX–150U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE ASSEMBLY
AX
INSTALLATION
1. INSPECT TORQUE CONVERTER CLUTCH
ASSEMBLY
(a) Inspect the torque converter (see page AX-153).
2. INSTALL TORQUE CONVERTER CLUTCH
ASSEMBLY
(a) Install the torque converter clutch to the automatic
transaxle.
(b) Using a vernier caliper, measure dimension A
between the transaxle and the end surface of the
drive plate.
(c) Using a vernier caliper and straightedge, measure
the dimension B shown in the illustration and check
that B is greater than A.
Standard dimension:
A + 1.0 mm (0.039 in.) or more
3. INSTALL NO. 1 TRANSMISSION CONTROL CABLE
BRACKET
(a) Install the cable bracket with the 2 bolts.
Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
4. INSTALL TRANSMISSION OIL FILLER TUBE SUB-
ASSEMBLY
(a) Install the filler tube with the bolt.
(b) Install the filler tube with the bolt.
Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
(c) Install the ATF dipstick.
C083051E01
C065911E01
C127845
C127846
Page 979 of 2000

U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE ASSEMBLYAX–151
AX
5. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY
(a) Install the automatic transaxle with the 5 upper side
mounting bolts to the engine.
Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for bolt A
46 N*m (469 kgf*cm, 34 ft.*lbf) for bolt B
(b) Install the 4 lower side mounting bolts.
Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf)
(c) Install the 6 torque converter clutch mounting bolts.
Torque: 41 N*m (418 kgf*cm, 30 ft.*lbf)
HINT:
First install the green colored bolt and then the 5
bolts.
(d) Install the flywheel housing under cover.
6. INSTALL TRANSFER ASSEMBLY
(a) Install the transfer (see page TF-75).
7. INSTALL ENGINE MOUNTING BRACKET LH
(a) Install the mounting bracket with the 3 bolts.
Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf)
8. INSTALL ENGINE MOUNTING BRACKET FR
(a) Install the mounting bracket with the 4 bolts.
Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) for 14
mm head bolt
Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) for 12 mm
head bolt
C127822E01
C127820
C129381
C129380
C130912
Page 980 of 2000

AX–152U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE ASSEMBLY
AX
9. INSTALL ENGINE MOUNTING BRACKET RR
(a) Install the mounting bracket with the 3 bolts.
Torque: 45 N*m (459 kgf*cm, 33 ft.*lbf)
10. INSTALL TRANSMISSION OIL COOLER
(a) Install the oil cooler (see page AX-127).
11. CONNECT WIRE HARNESS
(a) Connect the wire harness clamps.
(b) Connect the 2 speed sensor connectors.
(c) Connect the transaxle wire connector.
(d) Connect the park/neutral position switch connector.
12. INSTALL STARTER ASSEMBLY
(a) Install the starter with the 2 bolts.
Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf)
(b) Connect the starter wire with the nut.
Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf)
(c) Connect the starter connector.
(d) Install the terminal nut and cover the nut with the
cap.
Torque: 9.8 N*m (100 kgf*cm, 7 in.*lbf)
13. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE
(a) Install the engine with transaxle. (see page EM-
105).
14. ADD AUTOMATIC TRANSAXLE FLUID
Fluid type:
Toyota Genuine ATF WS
15. INSPECT AUTOMATIC TRANSAXLE FLUID
(a) Inspect the automatic transaxle fluid (see page AX-
102).
16. PERFORM RESET MEMORY
(a) Perform the RESET MEMORY procedures (A/T
initialization) (see page AX-18).
C130913
C127821
A124921
A124920
Page 981 of 2000
U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–187
AX
REASSEMBLY
1. BEARING POSITION
C126590E01
Page 982 of 2000

AX–188U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
Standard bearing position
2. INSTALL DIFFERENTIAL GEAR LUBE APPLY TUBE
(a) Install the apply tube and clamp to the transaxle
housing with the bolt.
Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
NOTICE:
Make sure to insert the pipe to the stopper.
3. INSTALL UNDERDRIVE OUTPUT SHAFT OIL SEAL
RING
(a) Install a new oil seal ring to the transaxle housing.
4. INSTALL UNDERDRIVE CYLINDRICAL ROLLER
BEARING
(a) Using SST and a press, press in the underdrive
cylindrical roller bearing.
SST 09950-60020 (09951-00810), 09950-70010
(09951-07100)
NOTICE:
Do not apply excessive pressure.
Mark Front Race Diameter
Inside / OutsideThrust Bearing Diameter
Inside / OutsideRear Race Diameter
Inside / Outside
A - 57.2 mm (2.252 in.) / 84.96 mm
(3.3449 in.)56.4 mm (2.220 in.) / 83.0 mm
(3.268 in.)
B - 37.73 mm (1.4854 in.) / 58.0 mm
(2.283 in.)29.9 mm (1.177 in.) / 55.5 mm
(2.185 in.)
C - 33.85 mm (1.3327 in.) / 52.2 mm
(2.055 in.)-
D - 23.5 mm (0.925 in.) / 44.0 mm
(1.732 in.)-
E - 36.3 mm (1.429 in. ) / 52.2 mm
(2.055 in.)34.5 mm (1.358 in.) / 48.5 mm
(1.909 in.)
F - 34.6 mm (1.362 in.) / 52.2 mm
(2.055 in.)-
G 40.3 mm (1.587 in.) / 58.0 mm
(2.283 in.)38.6 mm (1.520 in.) / 60.0 mm
(2.362 in.)38.6 mm (1.520 in.) / 58.0 mm
(2.283 in.)
H - 53.6 mm (2.110 in.) / 69.6 mm
(2.740 in.)-
I - 33.8 mm (1.331 in.) / 48.2 mm
(1.898 in.)30.3 mm (1.193 in.) / 46.0 mm
(1.811 in.)
J - 53.6 mm (2.110 in.) / 70.18 mm
(2.763 in.) or 69.6 mm (2.740 in.)-
D003607E01
D003915E07
D003807E01
Page 983 of 2000
U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–189
AX
5. INSTALL UNDERDRIVE CLUTCH DRUM OIL SEAL
RING
(a) Install 2 new oil seal rings to the transaxle.
6. INSTALL UNDERDRIVE BRAKE PISTON
(a) Wind a vinyl tape around SST at the place 4.0 mm
(0.157 in.) above from the bottom end until the
thickness of the wound tape is about 5.0 mm (0.197
in.)
SST 09950-60010 (09951-00320)
NOTICE:
Clean SST to remove deposited oil before
winding a vinyl tape.
(b) Using SST and a press, press in the needle-roller
bearing to the transaxle until the wound vinyl tape
contacts the transaxle case.
SST 09950-60010 (09951-00320), 09950-70010
(09951-07100)
(c) Coat 2 new O-rings with ATF, and install them to the
underdrive brake piston.
(d) Install the underdrive brake piston to the transaxle.
D003914E04
D003809E03
D003810E01
D003794E02
D003609E01
Page 984 of 2000
AX–190U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
(e) Using SST, a snap ring expander and press, press
in the piston return spring and snap ring to the
transaxle.
SST 09387-00020
NOTICE:
Do not apply excessive pressure.
7. INSTALL NO. 2 BREATHER PLUG
8. INSTALL COUNTER DRIVE GEAR HOLE SNAP RING
(a) Using a screwdriver, press in the snap ring to the
transaxle.
9. INSTALL COUNTER DRIVE GEAR
(a) Using SST and a press, press in the 2 bearings
outer races to the transaxle.
SST 09950-60020 (09951-00890), 09950-70010
(09951-07150)
(b) Using SST and a press, press in the tapered roller
bearing to the counter drive gear until the bearing
race contacts with the snap ring.
NOTICE:
Do not apply excessive pressure.
SST 09649-17010
D003610E01
D003604E01
D003611E02
D003613E01
