AC–224AIR CONDITIONING – CONDENSER
AC
ON-VEHICLE INSPECTION
1. INSPECT COOLER CONDENSER ASSEMBLY
(a) If the fins of the cooler condenser are dirty, clean
them with water. Dry the fins with compressed air.
NOTICE:
Do not damage the fins of the condenser.
(b) If a fin of the cooler condenser is bent, straighten it
using a screwdriver or pliers.
2. CHECK CONDENSER FOR LEAKAGE OF
REFRIGERANT
(a) Using a halogen leak detector, check the pipe joints
for gas leakage.
(b) If gas leakage is detected in a joint, check the
torque of the joint.
Page 1666 of 2000

AIR CONDITIONING – CONDENSERAC–225
AC
REMOVAL
1. DISCHARGE REFRIGERANT FROM
REFRIGERATION SYSTEM (See page AC-172)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
3. REMOVE FRONT BUMPER COVER
(a) Remove front bumper cover (see page ET-4).
4. DISCONNECT NO. 1 COOLER REFRIGERANT
DISCHARGE HOSE
(a) Remove the bolt and disconnect the cooler
refrigerant discharge hose from the cooler
condenser.
(b) Remove the O-ring from the cooler refrigerant
discharge hose.
NOTICE:
Seal the openings of the disconnected parts
using vinyl tape to prevent moisture and foreign
matter from entering them.
5. DISCONNECT COOLER REFRIGERANT LIQUID PIPE
(a) Remove the bolt and disconnect the cooler
refrigerant liquid pipe from the cooler condenser.
(b) Remove the O-ring from the cooler refrigerant liquid
pipe.
NOTICE:
Seal the openings of the disconnected parts
using vinyl tape to prevent moisture and foreign
matter from entering them.
6. REMOVE RADIATOR SUPPORT UPPER BRACKET
(a) Remove the 2 bolts and 2 brackets.
H102042
H102043
E126555
Page 1667 of 2000
AC–226AIR CONDITIONING – CONDENSER
AC
7. REMOVE NO. 2 FAN SHROUD
(a) Remove the 2 bolts and fan shroud.
8. REMOVE COOLER CONDENSER ASSEMBLY
(a) Remove the cooler condenser.
9. REMOVE COOLER DRYER
(a) Using a 14 mm socket hexagon wrench, remove the
cap from the modulator.
(b) Remove the O-ring from the cap.
(c) Using pliers, remove the cooler dryer.
E126556
B135838
I030086E01
I032475E01
E050386E01
Page 1668 of 2000
AIR CONDITIONING – CONDENSERAC–227
AC
INSTALLATION
1. INSTALL COOLER DRYER
(a) Using pliers, install the cooler dryer.
(b) Apply a sufficient amount of compressor oil to the
contact surfaces of a new O-ring and the cap.
Compressor oil:
ND-OIL 8 or equivalent
(c) Install the O-ring to the cap.
(d) Using a 14 mm socket hexagon wrench, install the
cap to the modulator.
Torque: 2.9 N*m (29 kgf*cm, 25 in.*lbf)
2. INSTALL COOLER CONDENSER ASSEMBLY
(a) Install the cooler condenser.
3. INSTALL NO. 2 FAN SHROUD
(a) Install the fan shroud with the 2 bolts.
Torque: 10.5 N*m (107 kgf*cm, 8 ft.*lbf)
E050386E01
E055408E01
I030086E01
E126558
E126556
Page 1669 of 2000

AC–228AIR CONDITIONING – CONDENSER
AC
4. INSTALL RADIATOR SUPPORT UPPER BRACKET
(a) Install the 2 brackets with the 2 bolts.
Torque: 45 N*m (459 kgf*cm, 33 ft.*lbf)
5. INSTALL COOLER REFRIGERANT LIQUID PIPE
(a) Remove the attached vinyl tape from the pipe and
the connecting part of the cooler condenser.
(b) Sufficiently apply compressor oil to a new O-ring
and the fitting surface of the pipe joint.
Compressor oil:
ND-OIL 8 or equivalent
(c) Install the O-ring on the cooler refrigerant liquid
pipe.
(d) Install the cooler refrigerant liquid pipe on the cooler
condenser with the bolt.
Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
6. INSTALL NO. 1 COOLER REFRIGERANT
DISCHARGE HOSE
(a) Remove the attached vinyl tape from the hose and
the connecting part of the cooler condenser.
(b) Sufficiently apply compressor oil to a new O-ring
and the fitting surface of the hose joint.
Compressor oil:
ND-OIL 8 or equivalent
(c) Install the O-ring on the cooler refrigerant discharge
hose.
(d) Install the cooler refrigerant discharge hose on the
cooler condenser with the bolt.
Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
7. ADJUST HOOD SUB-ASSEMBLY (See page ED-5)
8. INSTALL FRONT BUMPER COVER
(a) Install the front bumper cover (see page ET-10).
9. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
10. CHARGE REFRIGERANT (See page AC-172)
11. WARM UP ENGINE (See page AC-173)
12. CHECK FOR LEAKAGE OF REFRIGERANT (See
page AC-173)
E126555
H102043
H102042
