TOYOTA RAV4 2006 Service Repair Manual U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–201 AX (b) Using SST and a press, press in the needle-roller bearing to the transaxle until the wound vinyl tape contacts the transaxle c

Page 1306 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–202U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 26. INSTALL NO. 2 UNDERDRIVE CLUTCH DISC (a) Install the 3 discs and 3 plates to the transaxle. Install in order: P - D - P - D - P

Page 1307 of 2000

TOYOTA RAV4 2006 Service Repair Manual U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–203 AX (b) Install the underdrive clutch assembly to the 1-way clutch. Rotate the underdrive clutch to check the rotating direction for t

Page 1308 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–204U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Temporarily install the parking lock pawl, shaft and spring to the transaxle case as shown in the illustration. (c) Install th

Page 1309 of 2000

TOYOTA RAV4 2006 Service Repair Manual U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–205 AX (g) As shown in the illustration, measure the 2 places of the transaxle housing. Calculate the dimension E using the formula. NOTI

Page 1310 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–206U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Install the forward clutch to the multiple clutch hub. NOTICE: Align the splines of all discs in the forward clutch with those

Page 1311 of 2000

TOYOTA RAV4 2006 Service Repair Manual U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–207 AX HINT: End play = Dimension E - Dimension D - thrust bearing thickness 3.28 mm (0.1291 in.) - underdrive thrust bearing race thickn

Page 1312 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–208U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 40. INSTALL TRANSAXLE HOUSING (a) Remove any packing material and be careful not to get oil on the contacting surfaces of the trans
